LateralX LX5+: How do I adjust the lateral stride width?
Follow this troubleshooting guide to help resolve issues with lateral stride width on the BowFlex LateralX LX5+.
Some common complaints may include:
Lateral stride is too wide
Lateral stride is too narrow
Can't adjust stride width
Stride width doesn't change when adjusted
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver
Flathead screwdriver
6mm, 10mm hex/Allen wrench, or the wrench from the
hardware card included with your machine
Lateral link puller (if removing lateral links for
troubleshooting)
1.
Adjust the stride width using the increase/decrease buttons on the left handlebar (reference 1). Check if the
stride number changes on the console, even temporarily (reference 2). If the displayed stride number
changes (even temporarily) skip to Step 3. If the stride number does not change, unplug your machine from
power, wait 30 seconds, then reconnect power and test if the issue persists [13305.A].
about:blank
LateralX LX5+: How do I adjust the lateral stride width?
(Reference 1)
ID: 13305.1
1/7
Advertisement
Related Manuals for Bowflex LateralX LX5+
Summary of Contents for Bowflex LateralX LX5+
- Page 1 LateralX LX5+: How do I adjust the lateral stride width? LateralX LX5+: How do I adjust the lateral stride width? ID: 13305.1 Follow this troubleshooting guide to help resolve issues with lateral stride width on the BowFlex LateralX LX5+. Some common complaints may include: Lateral stride is too wide...
- Page 2 5/23/24, 6:44 AM LateralX LX5+: How do I adjust the lateral stride width? The lateral stride adjustment controls are located on the left handlebar arm (red). (Reference 2) The lateral stride width is displayed in the center of the console screen. If the display still does not change, remove the console mast end cap and inspect the cables inside for damage (reference 3).
- Page 3 5/23/24, 6:44 AM LateralX LX5+: How do I adjust the lateral stride width? (Reference 3) Remove the console mast cover and inspect the cables circled in red. If the stride number does change when adjusted, listen to the motor for movement. If the motor doesn't move, check for error messages and reset the console.
- Page 4 5/23/24, 6:44 AM LateralX LX5+: How do I adjust the lateral stride width? The lateral links are highlighted in red. If the issue persists, check for damage to the lower cable connections. Refer to the "Replace the Lower Data Cables" section of the service manual for instructions on accessing the lower cable connections.
- Page 5 5/23/24, 6:44 AM LateralX LX5+: How do I adjust the lateral stride width? 1-2: Remove the handlebars and set to the side. 3-4: Remove both upper shrouds and set to the side. (Reference 6) about:blank...
- Page 6 5/23/24, 6:44 AM LateralX LX5+: How do I adjust the lateral stride width? The servo motor is located on the right side of your machine. The lower data cable is highlighted in red. Reseat the circled connections and inspect for damage. (Reference 7) The PCBA Slim Control board is located on the left side of your machine.
- Page 7 5/23/24, 6:44 AM LateralX LX5+: How do I adjust the lateral stride width? Part Description Part SKU Engine 8014350 Link Puller 8018723 Lower Cable 8017917 Mast Cables 8018408 Static Handlebar 8014278 2 Contact Tech Team / Advanced Troubleshooting If the issue was not resolved in the steps listed, contact the Tech Team or send an Advanced Troubleshooting case.
