LateralX LX5+: Why is the console pausing during a workout?
Follow this troubleshooting guide to help resolve issues with the console pausing and direction arrows not changing on
the BowFlex LateralX LX5+.
Some common complaints may include:
Console pauses mid-workout
Console pausing while working out
Direction arrows don't change
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver
Flathead screwdriver
6mm, 10mm hex/Allen wrench, or the wrench from the
hardware card included with your machine
Lateral link puller (if removing lateral links for
troubleshooting)
1.
Unplug your machine from power and inspect the cables at the console mast. Remove the console mast end
cap and inspect the cables inside for damage (reference 1). One at a time, disconnect the cables and inspect
the connectors and visible cables for damage.
the connectors are oriented in the proper direction. The tabs should line up and click into place once secured
Test to see if the issue persists [13297.A]. If the cables coming from the console are
Console [13297.B]. If the cables coming from the mast are damaged,
about:blank
LateralX LX5+:  Why is the console pausing during a workout?
If the cables are undamaged, firmly reconnect them, ensuring
(Reference 1)
damaged, order a
order Mast Cables [13297
ID: 13297.1
.C].
