Marvel MLCR215-IS01B Owner's Manual
Undercounter refrigeration
Hide thumbs
Also See for MLCR215-IS01B:
- Owner's manual (6 pages) ,
- Quick reference manual (24 pages) ,
- Owner's service manual (35 pages)
Subscribe to Our Youtube Channel
Related Manuals for Marvel MLCR215-IS01B
Summary of Contents for Marvel MLCR215-IS01B
- Page 1 OWNER’S GUIDE & SERVICE MANUAL M A R V E L U N D E R C O U N T E R R E F R I G E R AT I O N Model: MLCR215-IS01B...
- Page 2 Got a Marvelous Design? located inside the cabinet on the left side near the top. We would love to see how your Marvel product looks in its new home. You can send us photos of your installed prod- uct at marketing@marvelrefrigeration.com, and we might...
- Page 3 TABLE OF CONTENTS Tip: Click on any section below to jump directly there Installation Integrated Panel Dimensions Integrated Panel Installation...
- Page 4 INTEGRATED PANEL DIMENSIONS NOTE Due to differences in surrounding cabinetry, the panel may not perfectly align with the door. The procedure below is designed to provide a finished overlay panel that seamlessly integrates with surrounding cabinetry. The door panel must not weigh more than 20 lbs (10 kg). It is important to ensure that all drilled holes are drilles to the correct depth in order to avoid splits in the wood when hardware is installed.
- Page 5 A channel. robust tape may also be used. Marvel recommends the use of 4. Upon removal, lay gasket down on a flat surface. bar clamps to secure the panel 5. Partially loosen the 3 screws, securing the top hinge to to the door.
- Page 6 INTEGRATED PANEL INSTALLATION 12. Using a Phillips screwdriver, place one screw into each of the 6 pilot holes and screw down. Do not overtighten screws. 13. Be sure the screws force their way past the opening on the gasket channel and sit flish against the bottom of the channel.
