O W N E R S G U I D E
OWNER'S GUIDE
M A R V E L U N D E R C O U N T E R R E F R I G E R A T I O N
M ARVEL UNDERCOUNTER REFRIGERATION
F O R M O D E L # M L C L 2 1 5
F O R M O D E L # M L R E 2 2 4
T H E O R I G I N A L R E F R I G E R A T I O N E X P E R T S S I N C E 1 8 9 2
T H E O R I G I N A L R E F R I G E R A T I O N E X P E R T S S I N C E 1 8 9 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MLCL215 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Marvel MLCL215

  • Page 1 O W N E R S G U I D E OWNER'S GUIDE M A R V E L U N D E R C O U N T E R R E F R I G E R A T I O N M ARVEL UNDERCOUNTER REFRIGERATION F O R M O D E L # M L R E 2 2 4 F O R M O D E L # M L C L 2 1 5...
  • Page 2 Got a Marvelous Design? We would love to see how your Marvel product looks in its new home. Send us photos at marketing@marvelrefrigera- tion.com, and we might feature your Marvel home design...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Tip: Click on any section below to jump directly there Safety Important Safety Instructions Installation Unpacking Your Appliance Electrical Cutout & Product Dimensions Side-by-Side & Stacking Installations Integrated Panel Installation Installing The Water Supply Maintenance Stainless Steel Maintenance Service Obtaining Service Product Liability...
  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Important Safety Instructions Warnings and safety instructions appearing in this guide are not meant to cover all possible conditions and situa- tions that may occur. Common sense, caution, and care must be exercised when installing, maintaining, or operat- ing this appliance.
  • Page 5: Unpacking Your Appliance

    UNPACKING YOUR APPLIANCE WARNING CAUTION If the appliance was shipped, handled, or stored in other EXCESSIVE WEIGHT HAZARD than an upright position for any period of time, allow the ap- Use two or more people to move product. pliance to sit upright for a period of at least 24 hours before Failure to do so can result in personal injury.
  • Page 6: Electrical

    ELECTRICAL Electrical Connection A grounded 115 volt, 15 amp dedicated circuit is required. This product is factory equipped with a power supply cord that has a three-pronged, grounded plug. It must be plugged into a mating grounding type receptacle in ac- cordance with the National Electrical Code and applicable Do not remove local codes and ordinances (see figure below).
  • Page 7: Cutout & Product Dimensions

    CUTOUT AND PRODUCT DIMENSIONS ROUGH-IN OPENING DIMENSIONS CABINET DIMENSIONS "A" "B" "C" "D" "E" "F" "G" "H" "J" 16 /8" 15" 24" 14 7/8" 34 1/4" to 35 1/4" 23 /8" 25 /2" 37 / " 34" to 35" " (38.1 cm) (61 cm) (37.8 cm)
  • Page 8 CUTOUT AND PRODUCT DIMENSIONS PRODUCT DATA ELECTRICAL PRODUCT REQUIREMENTS # WEIGHT "H" 105 lbs 115V/60Hz/15A (47.6 kg) "J" "G" "D" "F" "E" " (8.9 cm) Glass door " Minimum (54.6 cm) shown ** Minimum rough-in opening required is to be larger than the adjusted height of the cabinet.
  • Page 9: Side-By-Side & Stacking Installations

    SIDE-BY-SIDE AND STACKING INSTALLATIONS Side-by-Side Installation Hinge-by-Hinge Installation (Mullion) When installing two units hinge-by-hinge, 13/16" (22 mm) Other Site Requirements is required for integrated models. Additional space may be Units must operate from separate, properly grounded elec- needed for any knobs, pulls or handles installed. trical receptacles placed according to each unit's electrical specifications requirements.
  • Page 10: Integrated Panel Installation

    INTEGRATED DOOR PANEL INSTALLATION Step 2: Remove the Door Gasket Cut and prepare panels according to the information provided in the Integrated Panel Dimensions section. With the door laying on a flat surface and starting at a corner of the door, remove the magnetic door gasket from the interior side of the door.
  • Page 11 INTEGRATED DOOR PANEL INSTALLATION Step 4: Install the Door If reversing the door swing, reinstall hinges per Door Reversal Instructions. Carefully slide lower hinge bushing over bottom hinge pin. Install the new upper hinge bushing into adaptor plate. Align hinge bushing with top hinge and reinstall upper hinge pin using 1/8”...
  • Page 12 CAUTION CAUTION FIlter head 3/8" NPT, WARNING...
  • Page 13: Stainless Steel Maintenance

    STAINLESS STEEL MAINTENANCE Background NOTE Stainless steel does not stain, corrode, or rust as easily as ordinary steel, but it is not stain or corrosion proof. Stain- less steels can discolor or corrode if not maintained prop- Stainless steel products should never be installed, or stored erly.
  • Page 14: Obtaining Service

    OBTAINING SERVICE If Service is Required: • If the product is within the first year warranty period please contact your dealer or call Marvel Customer Service at 616.754.5601 for directions on how to obtain warranty coverage in your area. •...
  • Page 15: Product Liability

    The part that caused the damage must be returned to Marvel in its entirety. The part must be clearly labeled with the serial number of the unit it was removed from, the date, and the servicer who removed the part.
  • Page 16: Warranty Claims

    Claims must be submitted online at • Final billing - Remodel www. marvelservice . co m Warranty parts will be shipped at no charge after Marvel • 60 day submittal d eadline from date of completed confirms warranty status. Please provide the model, serial service number, part number and part d escription.
  • Page 17: Ordering Replacement Parts

    Warranty parts will be shipped at no charge after Marvel confirms warranty status. Please provide the model, serial number, part number and part description. Some parts will require color or voltage information.
  • Page 18: System Diagnosis Guide

    System Diagnosis Guide REGRIGERATION SYSTEM DIAGNOSIS GUIDE System Suction Suction Compressor Condenser Capillary Evaporator Wattage Condition Pressure Line Discharge Tube Normal Normal Slightly Very hot Very hot Warm Cold Normal below room temperature Overcharge Higher than Very cold Slightly warm Hot to warm Cool Cold...
  • Page 19: Compressor Specifications

    Compressor Specifications EMY45HER REFRIGERANT R134A DANGER VOLTAGE 115-127 VAC FREQUENCY 60 Hz START WINDING 11 Ohm at 77 ° Electrocution can cause death or serious injury. RUN WINDING 5 Ohm at 77 ° Burns from hot or cold surfaces can cause serious 126 Ohm at 77 °...
  • Page 20 For designated Marvel Professional product, Marvel offers a one year extension of the two year warranty coverage from the date of purchase, free of charge. To take advantage of this third year warranty, you must register your product with Marvel within 60 days from the date of purchase at marvelrefrigeration.com and provide proof of purchase.
  • Page 21 Marvel Refrigeration 1260 E. Van Deinse St. Greenville MI 48838 616.754.5601 All specifications and product designs subject to change without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, replacements or compensation for previously purchased products.
