- Page 1 OWNER’S GUIDE & SERVICE MANUAL M A R V E L U N D E R C O U N T E R R E F R I G E R AT I O N Model: MLCR215-IS01B...
-
Page 2: Warranty Registration
The serial number can be found on the serial plate which is located inside the cabinet on the left side near the top. We would love to see how your Marvel product looks in its new home. You can send us photos of your installed product at marketing@marvelrefrigeration.com, and we... - Page 3 TABLE OF CONTENTS Tip: Click on any section below to jump directly there Installation Integrated Panel Dimensions Integrated Panel Installation...
-
Page 4: Integrated Panel Dimensions
INTEGRATED PANEL DIMENSIONS Integrated Panel Dimensions BACK SURFACE MUST HAVE AMPLE FLAT SURFACE NOTE TO MOUNT OVERLAY PANEL FLAT AND WITHOUT 3/4" INTERFERENCE (20 mm) 14-3/4" (375 mm) 30-1/4" (768 mm) Integrated Panel Preparation Integrated Panel... -
Page 5: Integrated Panel Installation
A robust tape may also be used. 4. Upon removal, lay gasket down on a Marvel recommends the use of bar clamps to secure the panel to Door/Drawer 5. Partially loosen the 3 screws, securing the top hinge to the door. - Page 6 INTEGRATED PANEL INSTALLATION 11. Locate 6 of the #6x 1-1/4" screws provided with your unit. 12. Using a Phillips screwdriver, place one screw into each of the 6 pilot holes and screw down. Do not overtighten screws. 13. Be sure the screws force their way past the opening of the channel.
