GE T TING STARTED
QUICK REFERENCE GUIDE
M ARVEL UNDERCOUNTER REFRIGERATION
M L C R 2 1 5 - S S 0 1 B
M L C R 2 1 5 - I S 0 1 B
M O C R 2 1 5 - S S 0 1 B
M A C R 2 1 4 - B S 0 1 B
M A C R 2 1 4 - S S 0 1 B
M A C R 2 1 5 - S S 0 1 B
T H E O R I G I N A L R E F R I G E R AT I O N E X P E R T S S I N C E 1 8 9 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOCR215-SS01B and is the answer not in the manual?

Questions and answers

Summary of Contents for Marvel MOCR215-SS01B

  • Page 1 GE T TING STARTED QUICK REFERENCE GUIDE M ARVEL UNDERCOUNTER REFRIGERATION M L C R 2 1 5 - S S 0 1 B M L C R 2 1 5 - I S 0 1 B M O C R 2 1 5 - S S 0 1 B M A C R 2 1 4 - B S 0 1 B M A C R 2 1 4 - S S 0 1 B M A C R 2 1 5 - S S 0 1 B...
  • Page 2: Table Of Contents

    WARNING Got a Marvelous Design? State of California Proposition 65 Warning: We would love to see how your Marvel product looks in its This product contains one or more chemicals known new home. Send us photos at marketing@marvelrefriger- to the State of California to cause birth defects or ation.com, and we might feature your Marvel home design...
  • Page 3: Unpacking Your Appliance

    Keep your carton and packaging until your appliance has been thoroughly inspected and found to be in good condi- tion. If there is damage, the packaging will be needed as proof of damage in transit. Afterwards please dispose of all items responsibly. MARVEL WARNING XXXXXXXXXXXX XXXXXXXXXXXX WARNING -...
  • Page 4: Installing Your Appliance

    CAUTION floor and level from side to side and front to back. The over- all height of your Marvel appliance may be adjusted higher (by turning the leveling leg out, CCW) and lower (by turning Front Grille the leveling leg in, CW).
  • Page 5 INSTALLING YOUR APPLIANCE General Installation Leveling Information 1. Use a level to confirm the unit is level. Level should be placed along top edge and side edge as shown. Figure 3 2. If the unit is not level, adjust the legs on the corners of the unit as necessary.
  • Page 6: Electrical

    ELECTRICAL Electrical Connection A grounded 115 volt, 15 amp dedicated circuit is required. This product is factory equipped with a power supply cord that has a three-pronged, grounded plug. It must be plugged into a mating grounding type receptacle in accor- dance with the National Electrical Code and applicable Do not remove local codes and ordinance.
  • Page 7: Cutout Dimensions

    CUTOUT DIMENSIONS PREPARE SITE CAUTION Your product has been designed for either free-standing or built-in installation. When built-in, your unit does not require additional air space for top, sides, or rear. However, the front grille must NOT be obstructed, and clearance is required for an electrical connection in the rear.
  • Page 8: Product Dimensions

    PRODUCT DIMENSIONS MLCR215-IS01A MLCR215-SS01A Includes 3/4”(20mm) Overlay Panel Not Including Handle 22 5/16” 22 5/16” (567mm)* (567mm)* 34 1/16” 34 1/16” (865mm) (865mm) 3 3/8” (85mm) 14 7/8” 3 3/8” (378mm) (85mm) 14 7/8” (378mm) *Add 3/4” to depth for water line clearance *Add 3/4”...
  • Page 9 PRODUCT DIMENSIONS MOCR215-SS01A MACR215-SS01A Not Including Handle Not Including Handle 22 5/16” 22 5/16” (567mm)* (567mm)* 34 1/16” (865mm) 32” (813mm) 3 3/8” (85mm) 14 7/8” (378mm) 3” *Add 3/4” to depth for water line clearance (76mm) 14 7/8” (378mm) *Add 3/4”...
  • Page 10: Installing The Water Supply

    INSTALLING THE WATER SUPPLY Water Hookup MLCR215, MACR215 & MOCR215 PREPARE PLUMBING 1. Turn off water supply and disconnect electrical supply product prior to attempting installation. The water valve uses a standard 1/4” (6.35 mm) compression fitting. 2. Remove the back panel. 3.
  • Page 11 INSTALLING THE WATER SUPPLY MACR214 1. Turn off water supply and disconnect electrical supply product prior to attempting installation. 2. Remove the grille and access panel (if equipped) along with the back panel. 3. Locate water valve in the front of the unit and thread water supply line through.
  • Page 12: Door Adjustments

    DOOR ADJUSTMENTS Door Adjustments Door Adjustments (MLCR215, MOCR215 & MACR215) (MACR214) HINGE COVER CHECKING DOOR ALIGNMENT The unit’s door is aligned at the factory before shipment. Hinge cover included with the literature bag is optional. However, its alignment could have been disturbed during To install hinge cover: shipment.
  • Page 13: Door Reversal

    DOOR REVERSAL Reversing the Door MLCR215, MACR215 & MOCR215 Location of the unit may make it desirable to mount the door on the opposite side of the cabinet. The hinge hardware will be removed and reinstalled on the opposite side of the cabinet. TO REVERSE THE DOOR Figure 21 5.
  • Page 14 DOOR REVERSAL Install top hinge and door: Reversing the Door MACR214 1. Install the top hinge. Do not tighten. Location of the unit may make it desirable to mount the door on the opposite side of the cabinet. The hinge hardware will be removed and reinstalled on the opposite side of the cabinet.
  • Page 15 DOOR REVERSAL 5. Remove bottom hinge from cabinet (two screws). 9. Use the 3 screws to attach hinge to top of cabinet - long, straight edge of hinge should align to the outside edge of cabinet. Do not tighten screws. Figure 27 Figure 31 6.
  • Page 16: Installing The Anti-Tip Device

    INSTALLING THE ANTI-TIP DEVICE Anti-Tip Bracket 1. Slide unit out so screws on top of unit are easily accessible. 2. Remove the two screws from the opposite side of the hinge assembly using a T-25 Torx driver (see below). Figure 32 Figure 33 3.
  • Page 17: Panel Installation

    6. Secure overlay panel to door using NOTE clamps. A robust tape may also be used. Marvel recommends the use of bar Custom Panel (not included): clamps to secure the panel to the door. If using tape, be certain the tape will not •...
  • Page 18: Cleaning Your Ice Machine

    NOTE ice dropping into the ice bucket. Marvel recommends discarding the ice produced during the CAUTION first two to three hours of operation to avoid possible dirt or scale that may dislodge from the water line.
  • Page 19 CLEANING YOUR ICE MACHINE Ice Maker Adjustment Adjusting Ice Harvest Ice Cube Thickness Adjustment 1. Remove the front grille Interval - As Required 2. Using a flat tip screwdriver, turn the adjusting screw (3) a small increment clockwise for a COLDER setting On ice maker equipped models, adjust the cube size by (slower ice production) or counterclockwise for a WARMER changing water amount injected into the ice maker assem-...
  • Page 20: Care And Cleaning

    CARE AND CLEANING Cleaning If any surface discoloring or rusting appears, clean it quickly with Bon-Ami® or Barkeepers Friend Cleanser® EXTERIOR CLEANING and a nonabrasive cloth. Always clean with the grain. Al- ways finish with Claire® Stainless Steel Polish and Cleaner Black Models or comparable product to prevent further problems.
  • Page 21 CARE AND CLEANING Cleaning Condenser Defrosting INTERVAL - EVERY SIX MONTHS Manual Defrost Models To maintain operational efficiency, keep the front grille free This unit is a manual defrost model and will require occa- of dust and lint, and clean the condenser when necessary. sional defrosting.
  • Page 22: Obtaining Service

    800.223.3900 for directions on how to obtain warranty 616.754.5601 coverage in your area. • If the product is outside the first year warranty period, Marvel Customer Service can provide recommendations of service centers in your area. A listing of authorized service centers is also available at www.marvelrefrigeration.com under the...
  • Page 23: Warranty

    For designated Marvel Professional product, Marvel offers a one year extension of the two year warranty coverage from the date of purchase, free of charge. To take advantage of this third year warranty, you must register your product with Marvel within 60 days from the date of purchase at marvelrefrigeration.com and provide proof of purchase.
  • Page 24 Marvel Refrigeration 1260 E. Van Deinse St. Greenville MI 48838 616.754.5601 All specifications and product designs subject to change without notice. Such revisions do not entitle 30691 Rev B the buyer to corresponding changes, improvements, additions, replacements or compensation for previously purchased products.
