Alliance Laundry Systems X Control Plus Programming Manual
  1. Manuals
  2. Brands
  3. Alliance Laundry Systems Manuals
  4. Washer
  5. X Control Plus
  6. Programming manual
Alliance Laundry Systems X Control Plus Programming Manual

Alliance Laundry Systems X Control Plus Programming Manual

Washer-extractors
Hide thumbs

Advertisement

Quick Links

Download this manual
Original Instructions
Keep These Instructions for Future Reference.
CAUTION: Read the instructions before using the machine.
(If this machine changes ownership, this manual must accompany machine.)
Washer-Extractors
Refer to Page 10 for Model Identification
www.alliancelaundry.com
X Control Plus Control
Part No. D1605ENR14
April 2023

Advertisement

loading
Need help?

Need help?

Do you have a question about the X Control Plus and is the answer not in the manual?

Questions and answers

Related Manuals for Alliance Laundry Systems X Control Plus

Summary of Contents for Alliance Laundry Systems X Control Plus

  • Page 1 Washer-Extractors X Control Plus Control Refer to Page 10 for Model Identification Original Instructions Keep These Instructions for Future Reference. CAUTION: Read the instructions before using the machine. (If this machine changes ownership, this manual must accompany machine.) Part No. D1605ENR14 www.alliancelaundry.com...

  • Page 3: Table Of Contents

    Programming the Wash Speed ......................43 Programming Extraction Speed ......................44 © Copyright 2024, Alliance Laundry Systems LLC All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher.
  • Page 4 The No Drain Sequence ........................78 The Static Drain Sequence.........................78 The Reversing Drain Sequence......................78 Operation Menu Operation Menu ..................................................80 80 Starting Up ............................80 Switching On the Power........................80 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 5 Eco Warm Wash 140°F 60°C......................96 Eco Color Wash 104°F 40°C ......................97 Eco Bright Wash 86°F 30°C ......................98 Extraction - Low Speed ........................98 Extraction - High Speed........................99 Sport 140°F 60°C..........................99 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 6 Wash Program 36: All in One Reg + ....................127 Wash Program 37: Wedding Gowns ....................128 Wash Program 38: Wool Blanket.....................128 Wash Program 51: Wool 50% Regular ....................129 Wash Program 52: Wool 50% Delicate....................130 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 7 Failure 35: Wrong Software Version ....................153 Failure 36: The Linen is Not Correctly Distributed in the Stage Before the Start Up of the Spinning Sequence ............................153 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 8 Failure 560: USB Not Found ......................166 Failure 561: File Not Found......................166 Failure 562: Export Failed .......................166 Failure 563: Import Failed .......................166 Failure 600-628: Software Errors ....................167 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 9 Service Information ..............................................168 Maintenance ............................168 Information for Service ........................168 Programmer Circuit Board ........................168 Instructions for Replacing the Programmer Boards................168 Instructions for Installing New Software ....................169 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 10: Safety Information Safety Information

    A nominal voltage, if loaded or not must work in tion of the machine type letters. the range ±10% with a maximum permanent frequency devi- © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 11: Introduction

    AR350_X_CONTROL_PLUS LYU280T PHU0240T AR520_X_CONTROL_PLUS LYU335T PHU0280T AR80M_X_CONTROL_PLUS LYU400T PHU180T AR80N_X_CONTROL_PLUS LYU800T PHU240T FS1000_X_CONTROL_PLUS LYX065T PHU280T FS1200_X_CONTROL_PLUS LYX080T PHX180T FS33_X_CONTROL_PLUS LYX105T PHX240T FS40_X_CONTROL_PLUS LYX10XT PHX280T continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 12 LAC332T MWFS100 PYE180T LAC520T MWFS125 PYE240T LAE080T MWFS125_X_CONTROL_PLUS PYE280T LAE105T MWFS175 PYG10XT LAE135T MWFS225 PYG12XT LAE180T MWFS260 PYG335T LAE240T MWFS75 PYG400T LAE280T MWFS75_X_CONTROL_PLUS PYG520T continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 13 LAY105T NX280M_X_CONTROL_PLUS PYU10XT LAY135T NX80M_X_CONTROL_PLUS PYU12XT LAY180T PA120_X_CONTROL_PLUS PYU135T LAY240T PA20_X_CONTROL_PLUS PYU180T LAY280T PA25_X_CONTROL_PLUS PYU240T LAY332T PA30_X_CONTROL_PLUS PYU335T LAY520T PA40_X_CONTROL_PLUS PYU400T LH1000_X_CONTROL_PLUS PA55_X_CONTROL_PLUS PYU520T continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 14 LYC180T PAN025T RX105M_X_CONTROL_PLUS LYC240T PAN030T RX105N_X_CONTROL_PLUS LYC280T PAN040T RX135M_X_CONTROL_PLUS LYC335T PAN055T RX135N_X_CONTROL_PLUS LYC400T PAN070T RX180M_X_CONTROL_PLUS LYC800T PAN080T RX180N_X_CONTROL_PLUS LYE065T PAN120T RX240M_X_CONTROL_PLUS LYE080T PAX080T RX240N_X_CONTROL_PLUS continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 15 PYC350T PYH350T PYY350T PYC450T PYH450T PYY450T PYC600T PYH600T PYY600T FX350_X_Control _Plus PMC360T PMY360T FX450_X_Control_Plus PMC500T PMY500T FX600_X_Control_Plus PMC700T PMY700T MXB360_X_CONTROL_PLUS PYX600T RX105_BUPA_X_CONTROL_PLUS MXB500_X_CONTROL_PLUS MXB700_X_CONTROL_PLUS continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 16: Machine Type In Configuration Menu

    24 kg / 55 lb / 240 L (200 G) RX240M AR240M 28 kg / 70 lb / 280 L (100 G) RX280N AR280N continues... Table 1 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 17 28 kg / 70 lb / 280 L FXB280 AFB280 36 kg / 360 L MXB360 50 kg / 500 L MXB500 70 kg / 700 L MXB700 continues... Table 1 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 18: Control Identification

    Control Identification Control Identification Symbols Used Buttons CHM1611R1 Figure 1 Buttons PY*350-600, PM*360-700 CZB1R Figure 2 Decal START (ADVANCE function) CHM1612R continues... Table 2 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 19 SERVICE INFORMATION (servicing information) CHM1621R DELAYED START FUNCTION (the delay starts running upon the pressing of the "start" button) CZB6R 0 to 9 NUMERIC KEYPAD continues... Table 2 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 20: Main Menu

    Confirming a menu i tem and go to the n ext menu i tem ENTER but ton Inse rt a value or Select another List eleme nt CZW40R Figure 3 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 21: Basic Description Of Controls Basic Description Of Controls

    The ADVANCED Menu is Designated for : • Inspecting the wash program by the view function. • Special optional applications. The CONFIGURATION Menu is Designated for : © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 22: How To Get Into The Setup Mode

    2. Then you will return to "Run Mode" and "SELECT CYCLE" 3. Press 0 (the Zero button). You will see the Main Menu is shown. Screen. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 23: 99 Wash Programs - 99 Steps

    Step 99 Wash Wash Sequence Sequence Drain/ Drain/ Extraction Extraction Sequence Sequence Tumble Tumble Tumble . . . Tumble Sequence Sequence Sequence Sequence CHM1624R Figure 6 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 24: Available Wash Sequences

    • The tumble sequence takes 30 Seconds, then the program is finished and the door can be opened. • SPRAY • The Tumble sequence cannot be skipped. • No WASH © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 25: Programming The Functions

    • Inlet Valve 8 corresponds with soap box for a Wash - liquid soap. soap. • Inlet Valve 7 corresponds with soap box for a Final Rinse. The Hot Water Inlet Valves © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 26: Front Or Side Soap Dispenser Washing Machines

    In other cases, the pro- gram will give poor washing quality. • Refer to Table 11 . The values are different for each machine type. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 27: Cabinet Freestanding 6.5-28 Kg / 14-70 Lb / 65-280 L

    9.51 gal [36 l] 10.17 gal 11.10 gal [42 13.74 gal [52 14.53 gal [55 19.28 gal [73 21.13 gal [80 [38.5 l] continues... Table 4 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 28: Cabinet Freestanding 35-60 Kg / 350-600 L

    6.40 gal [24.23 l] 8.18 gal [30.97 l] 14.76 gal [55.87 l] 7.03 gal [26.63 l] 9.08 gal [34.37 l] 15.90 gal [60.17 l] continues... Table 5 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 29: Machine Capacity

    40.92 gal [154.90 l] 50.46 gal [191.03 l] 68.94 gal [260.97 l] 42.49 gal [160.87 l] 52.32 gal [198.07 l] 71.29 gal [269.87 l] continues... Table 5 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 30 91.98 gal [348.20 l] 118.57 gal [448.83 l] (1) Economic Low Level (2) Economic High Level (3) Normal Low Level (4) Normal High Level continues... Table 5 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 31: Cabinet Freestanding 33-120 Kg / 75-275 Lb / 335-1200 L

    (3) 26.15 gal [99 (3) 30.38 gal 80.57 gal [305 l] (4) 83.48 gal 92.46 gal [350 l] [115 l] [316 l] continues... Table 6 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 32 147.94 gal [560 43.06 gal [163 l] 54.16 gal [205 l] 65.51 gal [248 l] 130.77 gal [495 138.69 gal [525 152.16 gal [576 continues... Table 6 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 33 77.14 gal [292 l] 96.69 gal [366 l] - (1) Economic Low Level (2) Economic High Level (3) Normal Low Level (4) Normal High Level continues... Table 6 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 34: Cabinet Hardmount 7.5-52 Kg / 20-120 Lb / 80-520 L

    19.44 gal 13.47 gal 19.02 gal [37.5 l] [42.5 l] [49.5 l] [53.9 l] [68.5 l] [73.6 l] [51 l] [72 l] continues... Table 7 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 35 52.57 gal [130 l] [199 l] 35.80 gal 54.95 gal [135.5 l] [208 l] 37.12 gal 57.06 gal [140.5 l] [216 l] continues... Table 7 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 36 [327 l] 88.76 gal [336 l] (1) Economic Low Level (2) Economic High Level (3) Normal Low Level (4) Normal High Level continues... Table 7 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 37: Hygienic Barrier 18-28 Kg / 40-65 Lb / 180-280 L

    22.30 gal [84.4 l] 26.60 gal [100.7 l] 29.91 gal [113.24 l] 23.46 gal [88.8 l] 28.03 gal [106.1 l] 31.46 gal [119.08 l] continues... Table 8 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 38: Barrier Machines 36-70 Kg / 360-700L

    (4) 26.68 gal [101.01 l] 38.67 gal [146.37 l] 56.89 gal [215.34 l] 28.43 gal [107.62 l] 41.07 gal [155.48 l] 59.90 gal [226.77 l] continues... Table 9 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 39 115.62 gal [437.67 l] 169.72 gal [642.46 l] 84.45 gal [319.6875 l] 118.60 gal [448.9425 l] 173.92 gal [658.325 l] (1) Economic Low Level continues... Table 9 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 40: Programmable Water Level

    7.5 kg / 20 lb / 80 L 10.5 kg / 25 lb / 105 L 13.5 kg / 30 lb / 135 L continues... Table 10 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 41: Speed Of Machines With Frequency Inverter

    13.5 kg / 30 lb / 135 L 1035 91-149 1075 (G-factor 400) 18 kg / 40 lb / 180 L (G- 91-149 factor 400) continues... Table 11 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 42: Spin Speed

    13.5 kg / 30 lb / 135 L 91-149 (G-factor 100) 13.5 kg / 30 lb / 135 L 91-149 (G-factor 200) continues... Table 11 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 43: Programming The Wash Speed

    • Standard reversing wash speed is between 40 and 50 RPM. Speed Limits Exact values can be found in Table 11 . • The minimum programmable wash speed is 10 RPM. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 44: Programming Extraction Speed

    Pro- gram A "NO DRAIN" between the two sequences to avoid draining the water. Set temperature the same for both parts. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 45: Initializing The Machine Initializing The Machine

    Buzzer Time 5 seconds The time the Buzzer is beeping at end of wash cycle while "Unload" is 0 - 99 displayed. continues... Table 12 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 46 - 80 °C] The value of the hot water supply temperature is required to obtain a correct bath temperature at the water fill process. continues... Table 12 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 47 Cabinet Freestanding: 33-40-55 kg / 75-90-125 lb / 335-400-520 L: 10 units Cabinet Freestanding: 80-100-120 kg / 180-230-275 lb / 800-1000- 1200 L: 25 units continues... Table 12 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 48 Wash Liquid Soap Selection whether the information on liquid soap dosage for the main No / Yes Info wash should be shown or not. continues... Table 12 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 49: Configuration Menu

    • Switch the machine to the setup mode. Refer to section How Figure 11 to Get into the Setup Mode . • The Main Menu is now available. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 50: Passwords

    NOTE: The washing machine can only operate correctly if the correction inverter (same as washing machine) has been set in the Configuration menu. continues... Table 13 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 51 Depending on this selection other inlet valves will be programmed when the standard programs are loaded. Cabinet Freestanding: 33-40-55-80-100-120 kg / 75-90-125-180-230-275 lb / 335-400-520-800-1000- 1200 L : 3 continues... Table 13 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 52 No / Yes and others do not. To program External Liquid soap supplies at the Program Menu, this selection must be Yes. continues... Table 13 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 53 No / Yes Hygienic Barrier Machines only. If the second display is installed on hygienic side (unloading side) then Yes must be selected. continues... Table 13 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 54: Advanced Menu

    • Switch the machine to the setup mode. Refer to section How • Select the Advanced Menu after turning it on in the Configu- to Get into the Setup Mode . ration Menu. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 55: Hygienic Cycle Menu

    The access to the Program Mode can be locked by a password. It means that without password you can't have access to the Main Menu Screen. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 56: Program Lock Menu

    It avoids that programs once created get changed by somebody else. 1 HOT 194°F [90°C] INTENS (Unlocked) 2 WARM 140°F [60°C] INTENS (Locked) Unlocked 99 Program 99 continues... Table 16 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 57: Traceability Menu

    Err 81 and Err 82 can be switched off if they disturb to often the wash No / Yes Errors process. Exit Return to Advanced Menu. continues... Table 17 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 58: Weighing Menu

    This will reduce the water consumption of the washing machine. continues... Table 18 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 59: Weighing Menu - Ultra System

    Thus, the liq- uid soap consumption is reduced. Exit Return to Advanced Menu continues... Table 19 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 60: Tilting System

    This item activates communication with dispensing PLC system. No / Yes Show Customer ID Displays the customer ID at the start of a cycle No/Yes continues... Table 22 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 61 If the external wait signal is set for soap and the signal is high, the No/Yes communication will be stopped until the signal is low before transmit- ting again. Exit Return to Advanced Menu continues... Table 22 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 62 Initializing the Machine How to Create and Adjust a Wash Program Figure 15 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 63: Programming

    With the ARROW UP and DOWN button you can select the desired charac- ter. By pressing the ENTER button, the dashes will disappear. continues... Table 23 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 64: Display Message

    A confirmation is asked first to delete the old program. Exit Return to Main Menu. continues... Table 23 Step 3: Program Step Function Figure 17 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 65 An existing Step in the program disappears when it's deleted. A confirmation is asked first before deleting the Old Step. Exit Return to Program Menu. continues... Table 24 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 66: Step 4: Programming The Wash Part

    Refer to section Basic Descrip- • Wash tion of Controls for a general explanation concerning the cre- • Cooldown ation of wash programs. • Rinse • Final Rinse © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 67: The Prewash Sequence

    Setting of water in liters or liters per kilogram must be activated in weighing menu. The suggested RPM depends on the machine Type. Refer to Table 11 continues... Table 25 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 68: The Wash Sequence

    NOTE: If you insert other inlet valves than the suggested ones, problems can occur at the water fill process. (top soap dispenser) I1-I2-I3-I5-I6-I8 I1...I8 continues... Table 26 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 69 Wash Step. This allows the operator to add soap for the next step. A buzzer signal warns the operator that the cycle has been inter- rupted. continues... Table 26 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 70: The Cooldown Sequence

    The wash action (motor "Off" Time). Gentle wash action : 12 sec- onds. (The suggested default values can be adjusted at the Initialization menu) continues... Table 27 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 71: The Rinse Sequence

    NOTE: If you insert other inlet valves than the suggested ones, problems can occur at the water fill process. (top soap dispenser) I1-I2-I7 I1,2,3,4,7 (front soap dis- I1-I2 penser) continues... Table 28 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 72: The Final Rinse Sequence

    A buzzer signal warns the operator that the cycle has been inter- rupted. continues... Table 28 The Final Rinse Sequence Washing Machines with Top Soap Dispenser • Prewash • Cooldown • Wash • Rinse © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 73 The Final Rinse Sequence Time. (for 0 Minutes the Final Rinse sequence will be skipped) (program- mable in steps of 0.5 Minutes) continues... Table 29 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 74: The Soak Sequence

    Setting of water in liters or liters per kilogram must be activated in weighing menu. Refer to Table 11 The suggested RPM depends on the machine Type. continues... Table 30 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 75: The Spray Sequence

    Refer to Table 11 Drain Valve Only available on washing machines with both : a normal Open and 1 - 2 normal Closed Drain valve. continues... Table 31 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 76: The No Wash Sequence

    The Drain Sequence • Drain • Static Drain • Extract • Reversing Drain • No Drain © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 77: The Extract Sequence

    The Extract Sequence Time. (for 0 Minutes the Extract sequence will be skipped) (programmable in steps of 0.5 Minutes) Exit Return to Edit Program Menu. continues... Table 33 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 78: The No Drain Sequence

    (tilt) function will be activated. The drum is reversing while the water is drained. C051 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 79 (for 0 Minutes the Static Drain sequence will be skipped) (program- mable in steps of 0.5 Minutes) Exit Return to Edit Program Menu. continues... Table 36 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 80: Operation Menu Operation Menu

    • The Delay Time Sequence can be interrupted by pressing the Stop button. The program will return to the Start Up menu: SELECT CYCLE. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 81: The Active Program

    2. The extra time for taking water. C065 3. The extra time for draining (if the water is not drained in 30 sec and the extended drain time is started) © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 82: Water Fill Process

    • Then the message "CLOSE SOAP DOOR" is displayed. Programmed Cooldown • Once the soap dispenser door is closed again, the message CONTINUE ? will be displayed. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 83: Wait State

    • The actual wash machine states at the running wash cy- cle. • By pressing the ARROW DOWN button you will see all the menu items. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 84: External Liquid Soap Boxes

    • If the door is open there is shown "0kg" as the linen load weight on the display. Enter the weight value. When you close the door, you will be able to select a wash cycle. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 85: Automatic Weighing System (Ultrabalance)

    (and amount of dispensed soap) will be set for the same val- machine. ues as for a fully loaded machine. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 86: Pre-Programmed Programs Pre-Programmed Programs

    Inlet Valve 3: Hot Soft water continues... Inlet Valve 8: Hot Soft Wa- Soap Dis- Wash - liquid penser Com- Table 39 partment "III" continues... Table 37 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 87: Wash Program Legend Water Levels

    W (normal) 1-2-7 Spin 1 minute Step 5 Rinse 3 4 minutes W (normal) 3=30 seconds 1-4-7 1-7* Final spin/Spin 9 minutes Slowdown continues... Table 40 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 88: Warm Wash Intensive 140°F 60°C

    W (normal) 1-2-7 Spin 1 minute Step 5 Rinse 3 4 minutes W (normal) 3=30 seconds 1-4-7 1-7* Final spin/Spin 9 minutes Slowdown continues... Table 41 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 89 Soap Supply Tumble W (5 seconds / 30 seconds 5 seconds) (Models with- out pump drain) 5 minutes (Models with pump drain) continues... Table 41 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 90: Colored Wash Intensive 104°F 40°C

    Bright Wash Intensive 86°F [30°C] Wash Program 4: Bright Wash Intensive 86°F [30°C] Sequence Inlet Temperature Level Time R.P.M (x) Soap Supply No Prewash continues... Table 43 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 91: Woolens 59°F 15°C

    59°F [15°C] 6 minutes W (gentle) 2=30 seconds 1-2-3-5 2-5* Drain 30 seconds Step 2 Rinse 1 2 minutes W (gentle) 1-2-7 continues... Table 44 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 92: Hot Wash 194°F 90°C

    Rinse 1 4 minutes W (normal) 1-2-7 Spin 1 minute Step 3 Rinse 2 4 minutes W (normal) 1-2-7 Spin 1 minute continues... Table 45 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 93: Warm Wash 140°F 60°C

    W (normal) 1-2-7 Spin 1 minute Step 4 Rinse 3 6 minutes W (normal) 3=30 seconds 1-4-7 1-7* Final spin/Spin 9 minutes Slowdown continues... Table 46 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 94: Colored Wash 104°F 40°C

    9 minutes Slowdown Tumble W ( 5seconds / 30 seconds 5 seconds) (Models with- out pump drain) 5 minutes (Models with pump drain) continues... Table 47 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 95: Bright Wash 86°F 30°C

    R.P.M (x) Soap Supply No Prewash Step 1 Main wash 185°F [85°C] 14 minutes W (normal) 2=30 seconds 1-2-3-5-6-8 2-3-5* Drain 1 minute continues... Table 49 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 96: Eco Warm Wash 140°F 60°C

    1-2-7 Spin 1 minute Step 3 Rinse 2 EL(1) 4 minutes W (normal) 3=30 seconds 1-4-7 1-7* Final spin/Spin 9 minutes Slowdown continues... Table 50 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 97: Eco Color Wash 104°F 40°C

    (1) EH – Cabinet Freestanding 10.5 kg / 25 lb / 105 L models, Cabinet Hardmount 10.5 kg / 25 lb / 105 L (G-factor 200) models continues... Table 51 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 98: Eco Bright Wash 86°F 30°C

    Level Time R.P.M (x) Soap supply Step 1 Rinse 3 minutes W (normal) 3=30 seconds 1-4-7 1-7* Final spin/Spin 5.5 minutes Slowdown continues... Table 53 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 99: Extraction - High Speed

    Soap Supply No Prewash Step 1 Main wash 129.2°F [54°C] NL 6 minutes W (normal) 2=30 seconds 1-2-3-5-6-8 2-3-5* Drain 1 minute continues... Table 55 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 100: Mops 140°F 60°C

    10 minutes W (normal) 2=30 seconds 1-2-3-5-6-8 2-3-5* Drain 1 minute Step 3 Rinse 1 2 minutes W (normal) 1-2-7 Spin 1 minute continues... Table 56 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 101: Mops 140°F 60°C (Fxb)

    Rinse 1 2 minutes W (normal) 1-2-7 Spin 1 minute Step 4 Rinse 2 2 minutes W (normal) 1-2-7 Spin 1 minute continues... Table 57 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 102: Horse Cloths 104°F 40°C

    Rinse 1 2 minutes W (normal) 1-2-7 Spin 1 minute Step 4 Rinse 2 2 minutes W (normal) 1-2-7 Spin 1 minute continues... Table 58 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 103: Jeans 140°F 60°C

    W (normal) 1-2-7 Spin 1 minute Step 3 Rinse 2 3 minutes W (normal) 3=30 seconds 1-4-7 1-7* Final spin/Spin 6 minutes Slowdown continues... Table 59 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 104: Starching

    6 minute Slowdown Tumble W (5 seconds / 30 seconds 5 seconds) (Models with- out pump drain) 5 minutes (Models with pump drain) continues... Table 60 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 105: Wash Programs For Washing Machines With Front Soap Dispenser

    140°F [60°C] 10 minutes W (normal) B=30 seconds Drain 30 seconds Step 3 Rinse 1 2 minute W (normal) Spin 1 minute continues... Table 62 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 106: Colored Wash 104°F 40°C

    2 minutes W (normal) Spin 1 minute Step 5 Rinse 3 1(2) 3 minutes W (normal) D=30 seconds Final spin/Spin 5.5 minutes Slowdown continues... Table 63 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 107: Bright Colored Wash 86°F 30°C

    4 minute Slowdown Tumble W (5 seconds / 30 seconds 5 seconds) (Models with- out pump drain) 5 minutes (Models with pump drain) continues... Table 64 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 108: Woolens 59°F 15°C

    4 minutes W (normal) Drain 1 minute Step 4 Rinse 3 1(2) 6 minutes W (normal) D=30 seconds Final spin/Spin 5.5 minutes continues... Table 66 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 109: Eco Warm Wash 140°F 60°C

    5.5 minutes Slowdown Tumble W (5 seconds / 30 seconds 5 seconds) (Models with- out pump drain) 5 minutes (Models with pump drain) continues... Table 67 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 110: Eco Colored Wash 104°F 40°C

    4 minutes W (normal) Drain 1 minute Step 4 Rinse 3 1(2) 6 minutes W (normal) D=30 seconds Final spin/Spin 4 minutes continues... Table 69 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 111: Super Eco Hot Wash 194°F 90°C

    Super Eco Warm Wash 140°F [60°C] Wash Program 11: Super Eco Warm Wash 140°F [60°C] Sequence Inlet Temp. Level Time R.P.M (x) Soap supply No Prewash continues... Table 71 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 112: Super Eco Color Wash 104°F 40°C

    5.5 minutes Slowdown Tumble W (5 seconds / 30 seconds 5 seconds) (Models with- out pump drain) 5 minutes (Models with pump drain) continues... Table 72 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 113: Super Eco Bright Color Wash 86°F 30°C

    D=30 seconds Final spin/Spin 5.5 minutes Slowdown Tumble W (normal) 30 seconds (Models with- out pump drain) 5 minutes (Models with pump drain) continues... Table 74 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 114: Extraction - High Speed

    6 minute Slowdown Tumble W (5 seconds / 30 seconds 5 seconds) (Models with- out pump drain) 5 minutes (Models with pump drain) continues... Table 76 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 115: Mops 140°F 60°C

    Rinse 1 2 minutes W (normal) Spin 1 minute Step 4 Rinse 2 2 minutes W (normal) 3=30 seconds Final spin/Spin 1 minute continues... Table 78 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 116 4 minutes Slowdown Tumble W (5 seconds / 30 seconds 5 seconds) (Models with- out pump drain) 5 minutes (Models with pump drain) continues... Table 78 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 117: Jeans 140°F 60°C

    30 seconds 5 seconds) (Models with- out pump drain) 5 minutes (Models with pump drain) continues... Table 80 Wash Programs for Wet Cleaning Soap Supply Information © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 118 / 135 L lb. / 180 L lb. / 240 L lb. / 280 L Spin A Spin B Spin C continues... Table 83 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 119: Wash Program 21: Wool Regular

    2, 3, 6, 8 71.6 °F [22 °C] Level G 4 minutes Speed A Static drain 30 seconds No wash Softspin 1.5 minutes Spin A continues... Table 85 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 120: Wash Program 22: Wool Delicate

    2 Drain Wash 2 2, 3, 6, 8 71.6 °F [22 °C] Level G 3.5 minutes Speed A Static drain 30 seconds continues... Table 86 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 121: Wash Program 23: Silk Regular

    2, 3, 6, 8 68 °F [20 °C] Level L 3 minutes Speed A Static drain 30 seconds No wash Softspin 3 minutes Spin B continues... Table 87 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 122: Wash Program 24: Silk Delicate

    Level E 30 seconds Speed B Drain Prewash 3 1, 5, 2, 6 68 °F [20 °C] Level I 30 seconds Speed B continues... Table 89 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 123: Wash Program 26: All In One Delicate

    2, 3, 6, 8 73.4 °F [23 °C] Level I 2.5 minutes Speed C Static drain 30 seconds No wash Softspin 4 minutes Spin D continues... Table 90 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 124: Wash Program 27: Rinse Drum

    Applicable to models of: 18 kg / 40 lb. / 180 L; 24 kg / 55 lb. / 240 L Applicable to models of: 28 kg / 70 lb. / 280 L continues... Table 92 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 125: Wash Program 29: Spin Modest

    2, 3, 6, 8 68 °F [20 °C] Level F 3 minutes Speed A Static drain 30 seconds No wash Softspin 4 minutes Spin E continues... Table 95 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 126: Wash Program 32: Rinse Low

    Num- (Refer to (Refer to (Refer to Table Table 179) Table 171 and Table 176) No wash Softspin 3 minutes Spin C continues... Table 98 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 127: Wash Program 35: Rinse With Condit

    2, 3, 6, 8 73.4 °F [23 °C] Level M 2.5 minutes Static drain 30 seconds No wash Softspin 4.5 minutes Spin G continues... Table 100 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 128: Wash Program 37: Wedding Gowns

    1 Drain Prewash 2 1, 5, 2, 6 68 °F [20 °C] Level F 30 seconds Speed C Drain continues... Table 102 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 129: Wash Program 51: Wool 50% Regular

    2, 3, 6, 8 71.6 °F [22 °C] Level D 4 minutes Speed A Static drain 30 seconds No wash Softspin 1.5 minutes Spin A continues... Table 103 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 130: Wash Program 52: Wool 50% Delicate

    2 Drain Wash 2 2, 3, 6, 8 71.6 °F [22 °C] Level D 3.5 minutes Speed A Static drain 30 seconds continues... Table 104 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 131: Wash Program 53: Silk 50% Regular

    Applicable to models of: 13.5 kg / 30 lb. / 135 L; 18 kg / 40 lb. / 180 L; 24 kg / 55 lb. / 240 L; 28 kg / 70 lb. / 280 L continues... Table 105 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 132: Wash Program 54: Silk 50% Delicate

    Level C 30 seconds Speed B Drain Prewash 3 1, 5, 2, 6 68 °F [20 °C] Level E 30 seconds Speed B continues... Table 107 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 133: Wash Program 56: Aio 50% Delicate

    2, 3, 6, 8 73.4 °F [23 °C] Level E 2.5 minutes Speed C Static drain 30 seconds No wash Softspin 4 minutes Spin D continues... Table 108 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 134: Roubleshooting

    • Pressing the SERVICE INFORMATION button. • Pressing the STOP or START button. • Switching the power off/on. • Opening the door (fault 4 and 41). © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 135 "Drum door not locked" appears, the calibration procedure • Skip + continue: the actual cycle step is skipped and the pro- must be executed. gram continues with the next step. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 136: Failure Message Overview

    Communication fault inverter Full stop + safety time Whole cycle THT time THT Time out Full stop + safety time At spin sequence continues... Table 109 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 137 Incorrect signal for liquid de- Full stop + tumble Whole cycle tergent dispensing No Reheat Heating Failure Full stop + tumble Wash Step (Traceability only) continues... Table 109 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 138 E137 Wrong Signal From Wrong switch signal. Positioning system, don't start Drum positioning procedure. SDL3 or finish. continues... Table 109 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 139: Service Menu

    The SERVICE menu can only be accessed when the machine is in standby (the power is switched on, but no program is started). • SELECT CYCLE is displayed. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 140: Faults Menu (Service Faults)

    • Invert Alarm : E26 + E28 + E29 + E72 + E73 + E74 + E75 • Invert OV Alarm : E303 + E304 + E305 continues... Table 110 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 141: Toolbox Menu

    3. Close correctly drum door and machine door. 4. Start wash program 1. 5. Calibration will takes about 15 seconds and then message “Door System Calibration OK” is shown. continues... Table 111 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 142: Diagnostic Program

    Diagnostic Pr og … • Test of outputs for external liquid detergent pumps. • Water fill, heating and drain test. CFD1438R_SVG • BASIC Diagnostic Wash program. Figure 31 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 143 Inlet I8 The machine takes water by inlet 8 Drain 1 The water is drained by drain valve 1 Tumble The tumble sequence continues... Table 112 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 144 The water is drained by drain valve 1 Inlet I3 The machine takes water by inlet 3 Supply A Supply A is activated for 30 seconds continues... Table 113 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 145: Basic Diagnostic Wash Program

    Rinse seconds R=3 seconds utes Spin Spin 4.5 min- utes Slowdown 1 minute - Tumble A=12 seconds 30 sec- R=3 seconds onds continues... Table 114 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 146: Troubleshooting

    This error occurs when the linen is incorrectly distributed in the machine when it switches from distribution revolutions in- to high revolutions or during the spinning sequence at low rev- olutions. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 147: Failure 5: Safety Switch Activated At High Revolutions

    Table 118 door is not locked correctly after pressing the Start button. Failure message 8 will be generated each time the door locking sequence fails. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 148: Failure 9: Failure Of Door Lock Opening At The End Of Cycle

    Table 123 Table 122 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 149: Failure 12: Overfill Failure

    If the heating elements are not pressing the Service Button on the keypad. ments are heating. heating: Repair the wiring or replace the defective heater elements. continues... Table 125 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 150: Failure 18: Failure Of Door Lock Closing

    If during the wash cycle the electronic wash computer detects that the door lock switch is not closed, then the machine immediately stops all its func- © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 151: Failure 21: Overflow Failure

    2. Check the temperature sen- If the temperature sensor is Table 133 sor. broken: replace the tempera- ture sensor. continues... Table 132 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 152: Failure 28: Tht (Mitsubishi) Time Out

    4. Check if the drum rotates Repair / clean what is neces- continues... normally by hand. sary. Table 136 continues... Table 134 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 153: Failure 32: Verification Fault Inverter

    Machine . Table 139 Failure 38: No Recycle Water Failure 38 occurs when the electronic timer detects that the Water Recycle tank is empty. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 154: Failure 39: Empty Soap Supply Box

    Failure 42 occurs when there is No Network Connection avail- replace the drain valve. able. For more information about networking, refer to Trace- continues... ability Software Manual. Table 142 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 155: Failure 43: Wrong Voltage Range Selection

    Table 149 sensor. The rotation speed sensor check is performed during the wash cycle, before the spinning sequence. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 156: Failure 61: Inner Door Calibration

    1. Check the frequency in- If the frequency inverter does verter. not turn on, the failure is on the frequency inverter side. continues... Table 151 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 157: Failure 77: Time For Heating Blocking Is Out

    Detergents is Out the water fill system. Failure 80 occurs when the On Hold Signal of the Liquid Sup- Diagnosing Failure 82 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 158: Failure 83: Cycle Fail

    335-400-520L: load on each load cell must be in range 20 - Machines with weighing system only. Failure 101 occurs when 30%. the measured weight is much smaller then in normal operation. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 159: Failure 104: Weigh Overload

    Failure 106 occurs, when the calibration result does not corre- spond to the pre-set intervals. A different value is required for each machine model and power supply type. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 160 Table 166 3. Check DC electric motor Check wiring and power sup- ply to DC motor. There must be 12V DC power. continues... Table 165 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 161: Failure 142: Drum Rotation Error

    LED place it. In the unlocked position, drum position changes. SDL3 is switched. continues... continues... Table 172 Table 170 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 162: Failure 300-353: Mitsubishi Inverter Alarm Message

    Err 316 in the error log. Err CPU CPU Fault Communication error of built in CPU. Replace inverter. continues... Table 173 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 163 Err ILF* Input phase failure 1 phase of the 3-ph input was lost for more than 1 second. Repair the 3-phase power supply. continues... Table 173 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...
  • Page 164 * This option or function is not used. If you have this error anyway do the following : 1. Reload the inverter parameters. 2. If the fault is persistent, contact Technical Support. continues... Table 173 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 165: Failure 300-301-302: Oc Errors (Overcurrent)

    In such case the contactor must not be replaced. The In- mal high friction. verter must be reset by a longer power interruption. continues... Table 176 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 166: Failure 335: Fin-Error (Cooling Fin Inverter Overheat)

    The error message is displayed when an attempt to read from a write the Traceability into the internal memory. Change the USB flash disk fails. CPU control board. © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 167: Failure 600-628: Software Errors

    Troubleshooting Failure 600-628: Software Errors occurs inform the manufacturer. Software errors must never occur. If a software error message © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 168: Service Information

    6. Insert a new electronic programmer into the machine and se- cure it by the screws. C083 © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

  • Page 169: Instructions For Installing New Software

    • All Custom Settings will be lost. 3. Insert a flash drive containing the software into the USB con- nector E (of the CPU board). © Copyright, Alliance Laundry Systems LLC - Part No. D1605ENR14 DO NOT COPY or TRANSMIT...

This manual is also suitable for:

Af105 x control plusAf135 x control plusAf180 x control plusAf240 x control plusAf280 x control plusAf65 x control plus ... Show all
