Summary of Contents for Dabi Atlante New Versa Water Unit
- Page 1 English OWNER'S MANUAL New Versa Water Unit...
-
Page 2: Manual Overview
Owner’s Manual – New Versa Water Unit MANUAL OVERVIEW EQUIPMENT MANUAL (INSTRUCTIONS FOR USE) Technical Name: Dental Spitter Brand: Dabi Atlante Commercial Name: New Versa Water Unit Supplier/ Manufacturer: Alliage S/A Indústrias Médico Odontológica C.N.P.J. 55.979.736/0001-45 - Insc. Est. 582.002.897.114 Rod. -
Page 3: Table Of Contents
TABLE OF CONTENTS EQUIPMENT IDENTIFICATION ................4 Principles and fundamentals applied to the product operation......... 5 Equipment Description ....................5 Equipment Indication ....................5 MODULES, ACCESSORIES, OPTIONS AND CONSUME MATERIALS ......6 6 ........................6 EQUIPMENT OPERATION ..................7 TECHNICAL SPECIFICATIONS ................9 Technical features .................... -
Page 4: Equipment Identification
EQUIPMENT IDENTIFICATION Dear Client Congratulations on your excellent choice. For buying equipment with “Dabi Atlante” quality, you can be absolutely sure that you are purchasing products with technology compatible with the best in class in the world. This manual gives you an overview of your equipment. It describes important details that can guide you in its correct use, as well as in solving small problems that may eventually arise. -
Page 5: Principles And Fundamentals Applied To The Product Operation
Owner’s Manual – New Versa Water Unit EQUIPMENT IDENTIFICATION Principles and fundamentals applied to the product operation Auxiliary waste collection unit, has suckers whose suction is caused by a venturi system or vacuum pump with compressed air. Equipment Description Water unit for dental use, for auxiliary works such as water supply for the collection of waste and spitter activation. -
Page 6: Modules, Accessories, Options And Consume Materials
MODULES, ACCESSORIES, OPTIONS AND CONSUME MATERIALS The content of this page is for information purposes and the equipment may be different from the one illustrated. Therefore, when purchasing the product, check the technical compatibility between the equipment, coupling and accessories. 1 - Basin 2 - Water pipe for cleaning the basin 3 - Basin drain... -
Page 7: Equipment Operation
Owner’s Manual – New Versa Water Unit EQUIPMENT OPERATION * Using the High Speed and Micromotor (Ortho Unit) Connect the hose end to the rear of the High Speed or Micromotor, making the largest hole in the tap coincide with the largest hole in the hand piece. - Page 8 EQUIPMENT OPERATION Supplying reservoirs for Flush, Hand piece and Jet/ Ultrasound systems Hold the reservoir firmly by its base and turn it to the left by 1/4 turn allowing the pressurized air to escape through the grooves. Then finish unscrewing it to the end and discard the remaining liquid at the bottom of the bottle.
-
Page 9: Technical Specifications
Owner’s Manual – New Versa Water Unit TECHNICAL SPECIFICATIONS Technical features General Model New Versa Water Unit Equipment Classification according to ANVISA: Class II Equipment Classification according to IEC 60601-1: Protection Against Electric Shock - Type B and Class I Equipment (IEC 60601-1) -
Page 10: Electromagnetic Emissions
The parts of this equipment are not subject to degradation due to wear, corrosion, fatigue or aging of materials, during its shelf-life. Electromagnetic emissions Electromagnetic emissions New Versa Water Unit é destinada a ser utilizada nos ambientes eletromagnéticos New Versa Water Unit especificados abaixo. O cliente ou o usuário da deverá... - Page 11 Owner’s Manual – New Versa Water Unit TECHNICAL SPECIFICATIONS Manufacturer's guidelines and declaration - Electromagnetic immunity New Versa Water Unit is intended for use in the electromagnetic environments specified below. The customer or the user of the New Versa Water Unit should ensure that it is used in such an environment.
- Page 12 Manufacturer's guidelines and declaration - Electromagnetic immunity The New Versa Water Unit is intended for use in the electromagnetic environments specified below. The customer or the user of the New Versa Water Unit should ensure that it is used in such an environment.
- Page 13 Recommended separation distances between mobile, portable RF communication equipment and the New Versa Water Unit The New Versa Water Unit is intended for use in an electromagnetic environment in which RF disturbances are controlled. The customer or user of the New Versa Water Unit can help prevent...
-
Page 14: Dimensions (Mm)
TECHNICAL SPECIFICATIONS Dimensions (mm) -
Page 15: Packing Symbols
Owner’s Manual – New Versa Water Unit TECHNICAL SPECIFICATIONS Packing symbols Maximum stacking, It determines that the determines maximum packaging must be stored or amount of cartons that can be transported protected from stacked during transportation humidity (do not expose it to storage “according... -
Page 16: Equipment Installation
Maintenance Manual that is in the possession of the authorized technical representative Dabi Atlante. - This equipment can only be unpacked and installed by an authorized Dabi Atlante technician, under penalty of loss of warranty, since only he/ she has the information, the appropriate tools and the training necessary to perform this task. -
Page 17: Precutions, Restrictions And Warnings
- Room temperature range recommended by Dabi Atlante + 10ºC to + 35ºC. WARNING: The equipment must be used only with the power input cable supplied by Dabi Atlante, otherwise it may cause an increase in emissions or a decrease in the equipment immunity. -
Page 18: Recommendations For Equipment Maintenance
- The equipment must be operated only by duly qualified and trained technicians (Dental Surgeons, Trained Professionals) - If any maintenance is needed, use only Dabi Atlante Authorized Technical Assistance services. - The equipment was manufactured to withstand continuous and intermittent operation;... -
Page 19: Precautions And Warnings During Equipment "Cleaning And Disinfection
(failures, causes and solutions). If it is not possible to solve the problem, turn off the equipment, unplug the power cable from the outlet and contact your representative (Dabi Atlante). Precautions to be taken against foreseeable or unusual risks,... -
Page 20: Conservation And Corrective And Preventive Maintenance
Owner’s Manual – New Versa Water Unit CONSERVATION AND CORRECTIVE AND PREVENTIVE MAINTENANCE Additional procedures for reuse The equipment is reusable in indeterminate quantities, i.e., unlimited, requiring only cleaning and disinfection. Cleaning and disinfection Important: To perform cleaning or any type of maintenance, make sure that the equipment is disconnected from the mains. -
Page 21: Preventive Maintenance
If the equipment shows any abnormality, check if the problem is related to any of the items listed in item Unforeseen Events (situation, cause and solution). If it is not possible to solve the problem, turn off the equipment, and request Dabi Atlante technical assistance. -
Page 22: Unforeseen Events - Troubleshooting
UNFORESEEN EVENTS - TROUBLESHOOTING If you encounter any problem in the operation, follow the instructions below to check and fix the problem, and/or contact your representative. Unforeseen Events Probable Cause Solutions - Lack of water. - Check the water supply. - Activation of water in the basin and coaster does not - Closed water register. -
Page 23: Equipment Warranty
Whenever you need it, request the presence of a Dabi Atlante representative technician at the nearest retailer, or request it through Dabi Atlante Customer Service: + 55 (16) 3512-1212.
