BXT8J Treadmill: Why is the belt not moving or stopping on its own?
Follow this troubleshooting guide to help resolve issues involving the walking belt on the BXT8J Treadmill.
Some common complaints may include:
Belt moves momentarily then stops
Belt doesn't move
Workout starts and stops
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver
6mm hex/Allen wrench or the wrench from the hardware
card included with your machine
1.
Check if the console powers on. If the console powers up and the start button beeps or causes the display to change,
the console is not defective. If the console does not power on, please visit
my machine or console?
2.
Next, power cycle your machine. Once the Welcome screen is displayed, press the Start button to begin a Manual
Workout. Watch the belt and console - select an option below to continue troubleshooting:
Workout appears to start (timer runs on console) - belt doesn't move at all
Workout starts - belt moves for several seconds then stops
Workout doesn't start - Safety Key Error
Workout doesn't start - BLT SPD Error
Workout appears to start (timer runs on console) but belt doesn't move at all
Important:
This issue is always caused by a communication issue between the console and MCB.
Most times, this is caused by a damaged cable/connector or an improperly installed cable.
We must check every input/output cable and their cable connections to accurately diagnose which cable is
causing the communication interruption.
1.
Inspect the input/output cables and connector pins. Refer to the "Replace the Middle I/O Cable" section of the
manual for instructions on accessing input/output cables at the console and upright. Unplug each connection
(reference 1) and inspect for damage, such as cuts, crimps, or bent pins (reference 2).
If the cable coming from the console is damaged,
If the cable coming from the upright is damaged,
If the cable coming from the base of your treadmill is damaged,
If no damage is present but the issue persists,
about:blank
BXT8J Treadmill:  Why is the belt not moving or stopping on its own?
to continue troubleshooting.
(Reference 1)
BXT8J Treadmill: Why is there no power to
order a Console [14452.A].
order an Upright Cable
order a Base Cable Assembly
order a Base Cable and an Upright Cable
ID: 14452.5
[14452.B].
[14452.C].
[14452.D].
