Treadclimber TC100: Why are the buttons not responding on the
console?
Follow this troubleshooting guide to help resolve issues with buttons not responding on the console of your Treadclimber TC100
Some common complaints may include:
Buttons don't respond
Buttons not responding
Buttons don't work
Can't adjust speed
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver
4mm hex/Allen wrench or the wrench from the hardware
card included with your machine
13mm open-ended wrench
1.
Check if the console display is blank. If it is blank, please continue troubleshooting here:
is there no power to my machine or console?
2.
If the display is not blank, look for any error codes that may be displayed. If an error code is displayed or was
displayed recently and cleared, please continue troubleshooting
error message displayed on my console?
3.
If the issue persists, check the input/output cables at the motor control board (MCB), the top of the right upright, and
at the back of the console.
4.
To access the MCB (reference 1), use a Phillips head screwdriver to remove the 6 screws attaching the rear step and
remove the rear step. Remove the 2 upper screws on the rear cover and loosen the 2 lower screws. Lift and slide the
rear cover off and set it to the side. Remove the 6 bolts on the motor compartment cover with a 4mm Allen wrench
and 13mm open-ended wrench and set the cover to the side. Inspect the input/output cable for damage. Unplug the
connection. Plug it back in and make sure that it is firmly secured in the MCB and oriented in the proper
direction [12970.A]. If damage is present,
about:blank
Treadclimber TC100:  Why are the buttons not responding on the console?
order a Lower Comm
(Reference 1)
Treadclimber TC100: Why
here: Treadclimber TC100: How can I clear an
Cable [12970.B].
ID: 12970.1
