- Page 1 CDB6LESi User Manual □Please read the product instructions carefully before the installation and operation of the product, and keep those instructions properly for reference later.
- Page 2 Safety Notice Please carefully read this manual before the installation, operation, run, maintenance, and inspection of the product, and install and operate this product properly according to the product instructions. Danger: It is prohibited to operate the circuit breaker with your wet hands; ...
-
Page 3: Table Of Contents
Table of Contents 1. Main Purposes and Scope of Application……………………………………………….......... 1 2. Product Model and Meanings……………………………………………………………........1 3. Normal Use, Installation and Transportation Conditions.…………………………………........1 4. Technical Characteristics…………………………………………………………………........2 4.1 Classification……………………………………………………………………… ........2 4.2 Main Technical Performance Parameters………………………………………… ........…2 5. -
Page 4: Main Purposes And Scope Of Application
CDB6LESi residual current circuit breaker is used in the AC 50Hz/60Hz lines with rated voltage 230V/400V and rated current to 63A and below for indirect contact protection of people and for overcurrent protection of buildings and similar purposes. -
Page 5: Normal Use, Installation And Transportation Conditions
1. Wire inlet 2 Company logo 3 Trip curve and rated current (see Table 1) 4 ON/OFF indicator window 5 Product specification rated voltage (see Table 1) 6. Product model (overvoltage model is CDB6LESi G) 7. Certification mark reference standard 8 ON/OFF handle 9 ON/OFF mark 10 Load end mark and wire outlet... -
Page 6: Technical Characteristics
d) Installation conditions: The external magnetic field near the installation site of the residual current operated circuit breaker should not exceed 5 times of the geomagnetic field in any direction; the installation position should be vertical, and the inclination in any direction should not exceed 10° ; installed in a place without shock vibration and rain and snow attacks;... -
Page 7: Outline And Installation Dimensions
4.3 Main Technical Parameters a) The protection characteristics of the overcurrent release are listed in Table below: Table 2: Protection characteristics of overcurrent releases Type of Rated overcurrent Test current Expected Reference current In Starting state Test time Remarks instantaneous result temp. -
Page 8: Installation And Use, Maintenance
Fig. 1 Outline and installation dimensions 6. Installation and Use, Maintenance a) Check whether the product mark is consistent with the working conditions before installation: b) Correct the wire at the inlet and outlet ends according to the product identification (the load current should be less than the rated current of the product);... -
Page 9: Troubleshooting
d) When installation, the residual current operated circuit breaker is inserted into the mounting rail, so that the residual current operated circuit breaker is fixed on it without looseness and drop. To remove the residual current operated circuit breaker, pull out the stopper. e) The rated tightening torque is 2.0N. -
Page 10: Unpacking Inspection
Table 5 Troubleshooting and solution Fault Cause Solution Mis-operation caused by If the zero line is earthed on the Connect the earth wire to the zero the zero line earthed on the load side of the residual current line on the power side of the load side of the residual operated circuit... - Page 11 Inspector: Check 06 Date of production: See the label in the inner box DELIXI ELECTRIC LTD DELIXI ELECTRIC LTD Delixi High-Tech Industrial Park, Liushi Town, Y ueqing City, Zhejiang Province P/C.: 325604 Tel: (86-577) 61778888 Fax: (86-577) 61778000 Customer Service Hotline: 400-826-8008 www.delixi-electric.com...
