Delixi NAVIGATOR Series User Manual
Moulded-case circuit breaker
Hide thumbs
Also See for NAVIGATOR Series:
- User manual (12 pages) ,
- User manual (11 pages) ,
- User manual (12 pages)
Subscribe to Our Youtube Channel
Related Manuals for Delixi NAVIGATOR Series
Summary of Contents for Delixi NAVIGATOR Series
- Page 1 CDM3S Series NAVIGATOR MOULDED-CASE CIRCUIT- Series BREAKER User Manual Standards: GB/T 14048.2 IEC 60947-2 □Before the installation and use of this product, please carefully read this manual and keep it properly for reference.
-
Page 2: Safety Notice
Safety Notice Please carefully read this manual before the installation, operation, service, maintenance and inspection of this product, and install and operate this product properly in accordance with the instructions. Danger: ● Do not operate the circuit breaker with wet hands; ●... - Page 3 Between the contacts of circuit breaker, between the phases, and between the phase and the housing (the housing is covered with metal foil); Connected to the under-voltage release located between the incoming inlet and the circuit breaker housing of main circuit;...
- Page 4 2. Operation and debugging CDM3S Turn the handle of circuit breaker to the “Trip” position before shipment Turn the operating handle to the “OFF” position before trip Turn the circuit breaker to the “ON” position With the Trip button pressed, the handle of circuit breaker shall return to the “Trip” position Trip 3.
- Page 5 CDM3S-1600 wiring dimensions...
- Page 6 Unit: mm Outline dimensions Installation dimensions Product model CDM3S poles 4. Install CDM3S 4.1 Safety distance of circuit breaker Unit: mm Product model CDM3S- Amin Bmin Cmin Dmin 63/100 C 12.5 125b S/F 160/250 S/F/N 42.5 400 F/N 630F, 630b F/N 800 F/N 1600 F/N...
- Page 7 Conductive material Distance from the non-conductive material Attention: When the circuit breakers are installed in parallel, an insulation distance between the terminals shall be kept. A long terminal cover or an extra phase partition is recommended between two products for insulation protection;...
- Page 8 Inlet terminal Inlet terminal Outlet terminal Outlet terminal Exposed front cover and toggle handle Exposed toggle handle 4.3 Size of hole on the mounting plate Unit: mm Product model Number of Ø D CDM3S- poles 63/100 C 55.5 125b S/F 64.5 160/250 S/F/N 400 F/N...
- Page 9 4.4 Recommended values of wiring capacity Rated current Recommended sectional area of wire (mm Rated current (A) 1000 1250 1600 Recommended sectional area of wire 150× 2 185× 2 240× 2 Recommended sectional area of 150× 2 200× 2 250× 2 300×...
- Page 10 4.5 Recommended values of the wiring screw tightening torque Product model 63/100 125b 160/250 630b 1600 400 F/N 630 F 800 F/N CDM3S- S/F/N Socket hex wiring screw Torque (N.m) 7-10 7-10 11-14 11-14 15-19 15-19 11-14 Attention: 1. Please tighten the wiring screws of product according to the recommended torque, because too large or too small tightening torque will cause poor contact or damage to the housing.
- Page 11 Mountable accessories in all cavities Left accessory cavity: Left shunt, left under-voltage, left single assist, left dual assist, left alarm, and left assist larm Right accessory cavity: right shunt, right single assist, right dual assist, right alarm, and right assist alarm Note: 1600 product’s left accessory cavity accommodates left shunt, and left under-voltage releases;...
- Page 12 Electrical parameters of alarm and assist Resistive current Use category (GB/T 14048.5-1) AC15 DC13 AC400V 0.3A Working voltage 50/60Hz DC220V 0.15A Test requirements for internal accessories Under-voltage release: 1.1) Under 35% ~ 70% rated working voltage, the under-voltage release can work to trip the circuit breaker; 1.2) Under 85% ~ 110% rated working voltage, the under-voltage release can work to power on the circuit breaker reliably;...
- Page 13 If the requirements of the above table cannot be satisfied, it is recommended that the shunt release control circuit is designed according to the following figure: Power input The continuous power-on time of shunt release shall not exceed 5s, otherwise the shunt release will be burnt out.
-
Page 14: Maintenance And Service
Attention: The product without this function has no overload protection. After the overload fault disappears, the product will be kept in the alarm state within some time due to thermal effect. The product has a lead-wire structure by default, and the default wire length is about 220mm. 6. - Page 15 8. Company’s commitment Under the premise that users follow the use and storage conditions and the product are well sealed, within 36 months from the production date, our company will provide repair and replacement service free of charge for any damage or abnormal use due to poor manufacture quality.
- Page 16 Production date: See the label of the inner box For more information, please subscribe the WeChat official account Address: Delixi High-Tech Industrial Park, Liushi Town, Leqing City, Zhejiang Zip: 325604 Tel: (86-577) 6177 8888 Fax: (86-577) 6177 8000 Customer service hotline: 400-826-8008 www.delixi-electric.com...
