Delixi NAVIGATOR Series User Manual
Motor circuit breaker
Hide thumbs
Also See for NAVIGATOR Series:
- User manual (16 pages) ,
- User manual (12 pages) ,
- User manual (11 pages)
Subscribe to Our Youtube Channel
Related Manuals for Delixi NAVIGATOR Series
Summary of Contents for Delixi NAVIGATOR Series
- Page 1 CDV2s NAVIGATOR Motor Circuit Breaker Series User Manual Please carefully read this User Manual before installing and operating the product, and keep this manual properly for future reference...
- Page 2 Safety Notice Please carefully read this instruction before the installation, operation, run, maintenance, and inspection, and follow the contents of the instruction to properly install and operate this product. Danger: ● Do not operate the contactor with your wet hands; ●...
- Page 3 About CDV2s ● Panel introduction Inlet terminal Setting current range Top aux. contact protective cover Setting button Start button 10. Product specification Lock ring 11. Certification mark and sandard Stop button 12. Rated voltage, rated insulation voltage, and screw Outlet terminal tightening torque Trip test 13.
- Page 4 Normal Operation, Installation, and Transport Conditions ● Normal Operation and Installation Conditions (1) The ambient air temperature is not higher than +40℃, and is not below -5℃; the average value within 24 hours does not exceed +35℃; (2) The altitude of the installation site does not exceed 2000m; (3) The relative humidity of the atmosphere does not exceed 50% at the maximum ambient temperature of +40℃, and a higher relative humidity is allowed lower temperatures, such as 90% at 20℃.
- Page 5 Outline and Installation Dimensions Installation and Disassembly Method ● Check that the working voltage, rated current, frequency and characteristics of the product meet the working requirements before installation. ● It is forbidden to use the circuit breaker if damage or loose assembly. ●...
- Page 6 Install Disassemble Accessory installation diagram...
- Page 7 Installation Max. Installation Model Name Spec. location quantity Instantaneous aux. contact AEV2s 2NO, 1NO+1NC Right above (front-mounted) Instantaneous aux. contact ANV2s 2NO, 1NO+1NC Left side (side-mounted) 110~115V, 220~240V, AUV2s Undervoltage release Right side 380~400V, 415V 110~115V, 220~240V, ASV2s Shunt release Right side 380~400V, 415V Shunt and undervoltage release...
- Page 8 Instantaneous Aux. Contact Install Disassembe When the circuit breaker is in the OFF state, hange Press the lower hook of auxiliary contact; the upper hook of auxiliary contact onto the circuit Rotate the auxiliary contact outwards; breaker, and align the connecting rod with the hook of Move the hook upwards after leaving the body to circuit breaker mechanism;...
- Page 9 Install AEV2s11 or AEV2s20 Installation 1. Pry the top auxiliary contact shield upwards; 2. Attach the flat side of the top auxiliary contact against the circuit breaker; 3. Align the installation position and insert it down.
- Page 10 Debugging and Operation (1) Check whether the setting current range of motor circuit breaker is consistent with the rated operating current of motor, and replace if necessary; (2) Confirm that the motor circuit breaker for damage or abnormal sound; manually operate it several times and check the mechanism works flexibly and reliably without blockage;...
- Page 11 Company Commitment Under the condition that users follow the use and storage conditions and the product are well sealed, within 36 months from the production date, our company will provide repair and replacement service free of charge for any damage or abnormal operation due to poor manufacture quality. A paid repair will be provided if the warranty period expires.
- Page 12 Inspector: Check 06 DELIXI ELECTRIC LTD Production date: See label on inner box DELIXI ELECTRIC LTD Address: Delixi High-Tech Industrial Park, Liushi Town, Leqing City, Zhejiang P/C: 325604 Tel: (86-577) 6177 8888 Fax: (86-577) 6177 8000 Customer Service hotline: 400-826-8008 www.delixi-electric.com...
