- Page 1 R130C 8-Port 2-Channel PNP IO-Link Hub Instruction Manual Original Instructions p/n: 236035 Rev. D 18-Nov-24 © Banner Engineering Corp. All rights reserved.
-
Page 2: Table Of Contents
Industry Canada ICES-003(B)..................................10 Dimensions ........................................10 Chapter 6 Accessories Cordsets ........................................11 Quick-Disconnect Caps ....................................12 Chapter 7 Product Support and Maintenance Repairs ........................................13 Contact Us ........................................13 Banner Engineering Corp Limited Warranty..............................13 © Banner Engineering Corp. All rights reserved. -
Page 3: Chapter 1 Features
Overview The R130C-8P22-KQ hub connects two discrete Input/Output channels to each of the eight unique ports, providing access to monitoring and configuring those ports with an IO-Link master. Host mirroring is available where a selected port input/output discrete signal can be routed to Pin 2 (male) on the PLC/Host connection. -
Page 4: Chapter 2 Configuration
The figure below details the logic flow for each of the eight ports, while the tables define the configuration for each pin. For more information, see P/N 236036 R130C-8P22-KQ IO-Link Data Reference Guide and P/N 236037 R130C-8P22-KQ IODD Files . - Page 5 Configuration R130C 8-Port 2-Channel PNP IO-Link Hub Instruction Manual Continued from page 4 Port 1-Port 8 Pin Number: Description Name Values Discrete On Delay, One-shot, Pulse- Discrete Delay Timer 1 Stretcher Time, or Totalizer Count Discrete Delay Timer 2 Discrete Off Delay or Totalizer Time •...
-
Page 6: Io-Link
IO-Link® is a point-to-point communication link between a master device and a sensor and/or light. It can be used to automatically parameterize sensors or lights and to transmit process data. For the latest IO-Link protocol and specifications, please visit www.io-link.com. For the latest IODD files, please refer to the Banner Engineering Corp website at: www.bannerengineering.com. page 6 of 14 18-Nov-24... -
Page 7: Chapter 3 Mechanical Installation
Fasteners must be of sufficient strength to guard against breakage. The use of permanent fasteners or locking hardware is recommended to prevent the loosening or displacement of the device. The mounting hole (4.5 mm) in the R130C accepts M4 (#8) hardware. -
Page 8: Chapter 4 Status Indicators
R130C 8-Port 2-Channel PNP IO-Link Hub Instruction Manual Chapter Contents Chapter 4 Status Indicators The R130C 8-Port 2-Channel PNP IO-Link Hub has two matching amber LED indicators. There is also an additional amber LED specific to the IO-Link communications and a green power indication LED. IO-Link Power Indicator Communication Green LED Amber LED Discrete IN/OUT Status LEDs... -
Page 9: Chapter 5 Specifications
R130C 8-Port 2-Channel PNP IO-Link Hub Instruction Manual Chapter Contents FCC Part 15 Class B for Unintentional Radiators ..............................9 Industry Canada ICES-003(B).................................... 10 Dimensions......................................... 10 Chapter 5 Specifications Supply Voltage Required Overcurrent Protection 18 V DC to 30 V DC at 400 mA maximum (exclusive of load) -
Page 10: Industry Canada Ices-003(B)
R130C 8-Port 2-Channel PNP IO-Link Hub Instruction Manual Specifications (Part 15.21) Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. Industry Canada ICES-003(B) This device complies with CAN ICES-3 (B)/NMB-3(B). Operation is subject to the following two conditions: 1) This device may not cause harmful interference; and 2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 11: Chapter 6 Accessories
R130C 8-Port 2-Channel PNP IO-Link Hub Instruction Manual Chapter Contents Cordsets ..........................................11 Quick-Disconnect Caps...................................... 12 Chapter 6 Accessories Cordsets 4-Pin Double-Ended M12 Female to M12 Male Cordsets Model Length Style Dimensions Pinout MQDEC-401SS 0.31 m (1 ft) Female MQDEC-403SS 0.91 m (2.99 ft) 40 Typ. -
Page 12: Quick-Disconnect Caps
R130C 8-Port 2-Channel PNP IO-Link Hub Instruction Manual Accessories Quick-Disconnect Caps ACC-CAP M12-10 • 10 Caps • Seal and protect exposed, unterminated cascade quick-disconnect connectors page 12 of 14 18-Nov-24 © Banner Engineering Corp. All rights reserved. -
Page 13: Chapter 7 Product Support And Maintenance
Engineering Corp. will repair or replace, free of charge, any product of its manufacture which, at the time it is returned to the factory, is found to have been defective during the warranty period. This warranty does not cover damage or liability for misuse, abuse, or the improper application or installation of the Banner product. - Page 14 LinkedIn X (formerly Twitter) Facebook © 2024. All rights reserved. www.bannerengineering.com...
