BowFlex IC Bike SE:  Machine rocks or has loose hardware
Common issue descriptions:
Unit rocks back and forth during use
Machine does not sit level on the ground
Loose hardware (fasteners/screws)
Noise issues
Bike is difficult to operate

Tools used in this guide:
Estimated time to complete:
stabilizer hardware.
Let's get started!
We will check each of the components below (in order) to determine which is causing the
issue.
1.
Leveler feet
2.
Hardware installed during assembly

Check the leveler feet
Tools Required:
None
If the workout area is not level or the stabilizer rests slightly off of the floor, adjust the
leveler feet:
1.
Place your machine in the desired workout area - an ideal location has a solid, level
surface [15655.A].
2.
For any levelers that need to be adjusted, loosen the locking nuts and adjust the
levelers until they all make contact with the floor.
If more height is needed, rotate the leveler foot counterclockwise to raise the
base of the machine.
If less height is needed, rotate the leveler clockwise to lower the base of the
machine.
The levelers should be set to the minimum height where all feet make contact with the ground.
Adjusting the feet too high can cause them to detach or unscrew from the machine, potentially
causing injury or damage.
3.
Tighten the locking nuts on all level feet, then test if the machine is now stable. Repeat as needed until the
issue is resolved [15655.B].
4.
If the issue persists, we will continue checking assembly hardware in the next section.
Check hardware installed during assembly
Tools Required:
about:blank
BowFlex IC Bike SE:  Machine rocks or has loose hardware
4mm and 6mm Allen wrenches, 15mm open-ended wrench
Approximately 15 minutes - two people may be required when tightening
Estimated Time to Complete:
Less than 5 minutes
Estimated Time to Complete:
Service Manual Procedure:
Leveling the Machine
Service Manual Procedure:
ID: 15655.1
Steps 2 & 3

1/3

Advertisement

loading
Need help?

Need help?

Do you have a question about the IC Bike SE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bowflex IC Bike SE

  • Page 1 5/21/24, 11:41 AM BowFlex IC Bike SE:  Machine rocks or has loose hardware BowFlex IC Bike SE:  Machine rocks or has loose hardware ID: 15655.1 Common issue descriptions: Unit rocks back and forth during use Machine does not sit level on the ground...
  • Page 2 Once tightened, pedal your bike to test if the noise persists [15655.C]. Tighten both Pedals Step 1 The pedals are installed onto the crank arms of your IC Bike SE during the assembly process. The Right Pedal is threaded normally; rotate the pedal clockwise to tighten the pedal.
  • Page 3 5/21/24, 11:41 AM BowFlex IC Bike SE:  Machine rocks or has loose hardware If the issue was not resolved in the steps listed, contact the Tech Team or send an Advanced Troubleshooting case.  with  Submit a Case case type Advanced Troubleshooting...
