- Page 1 Installation Instructions 28000-5-TEST Test System for the 28000 Signal Conditioning System November 11, 2020 Rev B Precision Filters, Inc. 240 Cherry Street Ithaca, New York 14850 www.pfinc.com 9001:2008 CERTIFIED QUALITY...
- Page 2 PF 28000 GUI Control Software Copyright © 2020 Precision Filters, Inc., All Rights Reserved. Trademark Information The following terms and names are trademarks of Precision Filters, Inc. in the United States and/or other countries: • Balanced Constant Current and BCC •...
- Page 3 Do not install substitute parts or perform any unauthorized modifica- tion to the product. Return the product to Precision Filters, Inc. for service and repair to ensure that safety features are maintained. See the Support and Service section in this document for information on how to contact Precision Filters, Inc.
- Page 4 Keysight Truevolt Series Digital Multimeters Operating and Service Guide. Safety Guidelines and Warnings Before installing or operating the 28000-5-TEST test system, become thorough- ly familiar with all safety guidelines and warnings regarding the 33509B function generator and the 34465A digital multimeter in the Keysight documentation.
- Page 5 1.1.1 28000-5-TEST Overview........
- Page 6 28000-5-TEST Table of Contents Page iv 2.6.2 Installing Go/No-Go and FAT Test Cables ......... 16 Test Signal Cable .
- Page 7 The GUI can test multiple 28000 systems daisy-chained together with one test system; however, for faster test times and optimal GUI performance, Precision Filters recommends using one 28000-5-TEST test system and one host computer per 28000 system.
- Page 8 28000-5-TEST General Information Page 2 Part of 28000-BIF1-FT Card Control +5 VDC Ref Programmable (Ethernet) BNC Cable Test Bus Keysight 33509B Attenuator To Mainframe Waveform 1, 2, 4, 8, 10, 16, Off Slots J1-J16 “T” Generator 55 Hz Osc. Waveform Generator...
- Page 9 28000-5-TEST General Information Page 3 Test Descriptions The 28000-5-TEST test system provides three levels of tests: • Pretest Verify and Diagnostics • Factory Acceptance Tests (FAT): • BIF Controller Card FAT Tests • Card FAT Tests • Go/No-Go Tests 1.2.1...
- Page 10 28000-5-TEST General Information Page 4 1.2.2 Factory Acceptance Tests The Factory Acceptance Test (FAT), a full parametric test, is normally run at regular mainte- nance intervals. There are two FAT Tests. • Backplane interface (BIF) controller card FAT test • Card FAT tests...
- Page 11 28000-5-TEST General Information Page 5 The following is an overview of the card FAT tests. For detailed information about these tests and their operation, see the 28000-4A-TEST manual, Section 3.3, Card FAT. • Filter Frequency Response (Amplitude and Match) The Filter test consists of two elements: a filter frequency response test and a composite match test.
- Page 12 28000-5-TEST General Information Page 6 • IEPE Operation The IEPE Operation test measures the accuracy of the IEPE current on cards equipped with IEPE current sources. • IEPE Gain The IEPE Gain test measures the gain of a channel in IEPE mode for cards equipped with IEPE current sources.
- Page 13 Test System Hardware 28000-5-TEST System The Precision 28000-5-TEST test system consists of a high-performance digital multimeter, a waveform generator, a cable set, and rack mount adapters for the devices. The 28000 GUI software controls the function of both the digital multimeter and the waveform generator via an Ethernet interface.
- Page 14 20 inches long 9-pin D-shell to banana plug cable • Monitor Cable CB-DE9D/BAN-MONBUS-4 48 inches long 9-pin D-shell to banana plug cable (1 ea. included with 28000-5-TEST) Test System Monitor Cables for Multi-Chassis Tests Test system monitor cables for multi-chassis tests are 9-pin D-shell to 9-pin D-shell cables for daisy-chaining the monitor bus using the additional System Monitor connectors on the rear of the 28000 chassis.
- Page 15 28000-5-TEST General Information Page 9 Reference Cables Reference cables are used by 28000 cards that support channel composite match FAT testing. The 28000-M3 and the 28000-M5 chassis, and also the 28316C card, require different ref- erence cables. See Table 1 for assistance in selecting the correct reference cable for your test setup.
- Page 16 28000-5-TEST General Information Page 10 • 28302B-CHARGE-ADAPTER Supports traceable calibration of the internal shunt capacitor on 28302B cards. • 28304/28324-FAT-ADAPTER Supports NIST-traceable calibration of the internal shunt capacitor on 28304 or 28324 cards. Includes 1,000 pF 0.1% calibration capacitor, Combo-D to (two) BNC adapter, and BNC shorting plugs.
- Page 17 28000-5-TEST General Information Page 11 Table 1 Test Adapter and Cable Requirements by 28000 Card Model Card M3 Chassis M5 Chassis Required Test Adapter(s) Test Adapter Function Notes Model Reference Cable Reference Cable for Frequency for Frequency Response Match Response Match...
- Page 18 28000-5-TEST General Information Page 12 This page intentionally left blank. 28000-5-TEST Installation Instructions Precision Filters, Inc. Rev. B...
- Page 19 Page 13 28000-5-TEST Installation Introduction This section provides site preparation and installation instructions for the 28000-5-TEST test system. Before installing the test system, refer to the System 28000 Operation and Maintenance Instructions manual to ensure that the 28000 system is correctly installed.
- Page 20 Test Equipment Inspection Make a visual check of the test equipment to ensure that there are no broken controls, handles, or connectors and that panel surfaces are free of dents and scratches. 28000-5-TEST Installation Instructions Precision Filters, Inc. Rev. B...
- Page 21 Precision Filters. The environmental conditions described in Table 2 must be maintained. Service and Repair In the event that a system component must be returned to Precision Filters for repair or service, obtain a Return Authorization Number from Precision Filters. See Section 3, Support and Service, for details.
- Page 22 28000-5-TEST Installation Page 16 Installation The primary description of 28000-5-TEST control is based on the premise that the instruments are being controlled via Ethernet connections. 2.6.1 Ethernet Installation The 28000 GUI control software is preconfigured to communicate with the 28000-5-TEST instruments.
- Page 23 Front Panel or Rear Panel P1 (Red) Keysight 34465A Volt/Ohm HI + Multimeter P2 (Black) LO – Ethernet Ground (Green) Ethernet Controller PC with Ethernet Connection Figure 4 28000-5-TEST Connection with a Single 28000 System Precision Filters, Inc. 28000-5-TEST Installation Instructions Rev. B...
- Page 24 System Monitor Connector J502 J500 J115 J114 J113 J112 J111 J110 J109 J108 J107 J106 J105 J104 J103 J102 J101 J100 28016-M3 Mainframe Figure 6 System Monitor Cable Connected to a 28016-M5 System 28000-5-TEST Installation Instructions Precision Filters, Inc. Rev. B...
- Page 25 The host computer is connected to each system using multiple Ethernet connections using an Ethernet hub. Precision Filters provides the following monitor 9-pin D-shell to 9-pin D-shell cables for col- lecting two or more mainframes together: • CB-DE9P/DE9P-2XMONBUS-1.7: 20 inches •...
- Page 26 Output connector on the front of the BIF Controller card, remove the BNC T connectors and additional cables. To test each mainframe, connect the scope or other measuring device directly to the BNC Monitor Output connector. 28000-5-TEST Installation Instructions Precision Filters, Inc. Rev. B...
- Page 27 12 and channel 0 of that card is the reference channel. Figure 9 shows the reference cable connected to J300 and the System Input connector J500. Precision Filters, Inc. 28000-5-TEST Installation Instructions Rev. B...
- Page 28 M5, and J400 through J4037 on the 28004-M3/M5. The 9-pin D connector connects to the System Input connector J500. The reference channel is channel 0 of the card that the reference cable is installed. 28000-5-TEST Installation Instructions Precision Filters, Inc. Rev. B...
- Page 29 Apply Power Verify that the test system components are operating by applying power to the waveform generator, digital multimeter, 28000 system, and system PC controller. Precision Filters, Inc. 28000-5-TEST Installation Instructions Rev. B...
- Page 30 28000-5-TEST Installation Page 24 This page intentionally left blank. 28000-5-TEST Installation Instructions Precision Filters, Inc. Rev. B...
- Page 31 Customer Service E-Mail: customer-service@pfinc.com Fax: 607-277-4466 Service and Repair If equipment is being returned to Precision Filters for service or repair, contact the factory for a Return Authorization Number. To obtain a Return Authorization Number, contact Precision Filters: Phone: (607) 277-3550...
- Page 32 Support and Service Page 26 This page intentionally left blank. 28000-5-TEST Installation Instructions Precision Filters, Inc. Rev. B...
