Motor Assembly/Disassembly Instructions – Dynabug
Important: Manufacturer's warranty is void if tool is disassembled before warranty expires.
A Motor Repair Kit (57098) is available which contains special tools for disassembly/assembly. Please refer to parts breakdown for part identification.
To Disassemble:
1. Disconnect tool from power source. Invert machine and secure in vice, using
2. Disconnect sanding pad by removing
3. With a Phillips head screw driver remove
4. Disengage 96116 Clamp by using a screwdriver to unscrew clamp. Remove clamp,
5. Insert 56058 Lock Ring Tool (supplied in
6. Remove rear ring from motor. Upper motor may now be disassembled. Remove
7. Remove the rear plate and the cylinder assembly by securing the cylinder in a bearing separator gripped on the cylinder exhaust and extra pocket area.
Push the motor shaft balancer through the bearing.
8. Remove the rotor, vanes and rotor key from the motor shaft balancer. Remove the front plate using a (#2) arbor press. Support the edges of the front
plate while pressing on the small end of the motor shaft balancer.
9. a.) If, during step 9, the front plate and bearing remain together, press bearing out of the front plate using
b.) If, during step 9, the front plate and
11. Remove 01206 Bearing from the rear plate by using a bearing press tool. Remove lock ring, washer and front ring.
12. Disassemble the balancer assembly as follows:
a.) Place motor shaft assembly into a soft jaw vise. Using a thin screwdriver, pick out the end of
b.) Screw the threaded portion of the
motor shaft balancer to approximately 200° F (approximately 10 seconds with a propane torch). Now, using the slider weight, pull the assembly out.
c.) Press off 56052 Bearing with a bearing separator and remove bearing seal and bearing shield.
13. If during step 12, the 56052 Bearing remains in the motor shaft balancer, it can be removed by heating the shaft balancer again and using either an
inside bearing puller or a blind hole bearing puller.
Tool Disassembly Complete.
To Assemble
Important: Be certain parts are clean and in good repair before assembling.
1. Assemble the balancer assembly as follows:
a.) Install 95630 Snap Ring onto
Note: Be certain seal is pressed completely over shaft step.
b.) Apply 1 drop of Loctite ® #271 (or equivalent) and spread over several places around the inside diameter of the
diameter of the 57069 Balancer Shaft.
c.) Press fit 56052 Bearing with seal side toward hex of balancer shaft up to shaft step. This must be a firm press fit for proper retention of bearing.
2. Place the motor shaft balancer in a soft jaw vise with large end-up.
3. Apply 1 drop of Loctite ® #271 (or equivalent) and spread over several places around the outside diameter of the
assembly into the motor shaft balancer until
complete the assembly. Remove from vise.
4. Press 57088 Bearing onto the motor shaft balancer down to the shoulder. Place lock ring, washer and front ring on motor shaft balancer.
5. Press 57057 Front Bearing Plate onto
6. Place the 57090 Rotor and 56047
Note: Vanes should be lightly lubricated with Dynabrade Air Lube P/N
7. Place 57058 Cylinder Assembly over rotor. The "short" line-up pin goes toward the front plate.
8. Place 57056 Rear Bearing Plate (with bearing pressed into place) over shaft and "long" end of line-up pin and press fit in place. Insert
9. Place 57054 Rear Ring over the rear plate and line-up pin. Make sure that the "legs and fingers" on the front and rear rings line-up.
10. Secure motor housing in vise, using
assembly in housing. Note: Be certain line-up pin enters the pocket in bottom of the housing and the "legs" of the rings stay in line.
11. Tighten lock ring with 56058 Lock Ring Tool torque to 28 N•m/250 in. - lbs.
12. Insert 57823 Pad Mount into boot. Attach boot to housing with exhaust hole facing back and slide clamp over boot.
13. Place 57837 Washer into hex pocket with shoulder down. Line-up holes in pad top with holes in boot and secure with
14. Secure pad top and boot to motor assembly by installing
15. Position pad top to desired angle and tighten clamp to 0.7 N•m/6 in. - lbs. so that the top of the clamp is even with the top of the boot.
16. Attach sanding pad by installing
Valve and Speed Regulator Assemblies:
1. Secure housing in vice using 57092
2. Remove 95697 Snap Ring. Press the speed regulator and valve stem out of the housing. Remove the
3. Place new 01025 O-Rings (2) on the speed regulator and place in housing with valve stem. Install new
4. Place seal in housing. Using tweezers or needle nose pliers, place the tip valve in the housing so that its pin goes into the valve stem hole. Place
01468 Spring into the housing so the small end is toward the tip valve.
5. Spread one drop of Loctite ® #567 (or equivalent) around the first threads of the first inlet bushing and tighten into housing torque to 23 N•m/200 in. - lbs.
Tool Assembly Complete. Please allow 30 minutes for adhesives to cure before operating tool.
Loctite ® is a registered trademark of the Loctite Corp.
Buy parts on line at https://Dynashop.co.uk/ for all things Dynabrade
96258 Screws (4) with a 3.0mm wrench.
96114 Screws (6). Remove
57098 Repair Kit) into corresponding tabs of lock ring and unscrew. Motor may now be lifted out for service.
57088 Bearing remains on the motor shaft balancer, it can be removed with a bearing separator.
56056 Bearing Puller (supplied in
57069 Balancer Shaft. Install 95628
56052 Bearing is firmly seated at bottom. Squeeze
57088 Bearing and check for smooth rotation.
Rotor Key on the motor shaft balancer. Place the
57092 Collar or padded jaws. Spread 2-3 drops of pneumatic tool oil around the housing bore and slide motor
57838 Washer,
96258 Screws (4).
Collar or padded jaws. Remove inlet bushing,
