Models:
57130 - 3-1/2" Non-Vacuum
57131 - 3-1/2" Basic-Vacuum
57132 - 3-1/2" Deluxe-Vacuum
57133 - 3-1/2" Vac-Ready
57134 - 3-1/2" Central Vac-Ready
57135 - 5" Non-Vacuum
57136 - 5" Basic-Vacuum
57137 - 5" Deluxe-Vacuum
57138 - 5" Vac-Ready
57139 - 5" Central Vac-Ready
57140 - 5" Basic-Vac w/ Overskirt
57141 - 5" Deluxe-Vac w/ Overskirt
57142 - 5" Vac-Ready w/ Overskirt
!
WARNING
KEY
Adhesive:
A
A
= Loctite #271
2
A
= Loctite #567
8
Torque: N•m x 8.85 = In. - lbs.
T
Oil: O
= Air Lube
O
1
Index Key
No. Part
Description
1
95630 Snap Ring
2
57069 Balancer Shaft
3
95628 Bearing Shield
4
56053 Bearing Seal
5
56052 Balancer Bearing
6
Motor Shaft Balancer
57159 3"
57159 3-1/2"
57160 5"
57162 6"
7
56047 Rotor Key
8
57059 Lock Ring
9
95973 Washer
10
57055 Front Ring
11
57088 Bearing
12
57057 Front Bearing Plate
13
57113 Blade/Rotor Set
14
57058 Cylinder Assembly
(Incl. 95971 Line-up Pin)
15
95971 Line-up Pin
16
57056 Rear Bearing Plate
17
01206 Bearing
18
57054 Rear ring
19
95626 Snap Ring
20
95979 Pin
21
57161 Lever
22
01464 Seal
23
01472 Tip Valve
24
01468 Conical Spring
25
01494 Inlet Bushing
26
01025 O-Ring (2)
27
95697 Snap Ring
28
01477 Valve Stem
29
57064 Speed Regulator Assy.
or
57053 Recessed Speed Reg.
57143 - 5" Cntrl. Vac-Ready w/ Overskirt
57144 - 6" Non-Vacuum
57145 - 6" Basic-Vacuum
57146 - 6" Deluxe-Vacuum
57147 - 6" Vac-Ready
57148 - 6" Central Vac-Ready
57149 - 6" Basic-Vac w/ Overskirt
57150 - 6" Deluxe-Vac w/ Overskirt
57151 - 6" Vac-Ready w/ Overskirt
57152 - 6" Cntrl. Vac-Ready w/ Overskirt
57153 - 3" Non-Vacuum
57154 - 3" Vac-Ready
57157 - 3" Central Vac-Ready
Always operate, inspect and maintain this tool in accordance with the Safety Code for portable air tools
(ANSI B186.1) and any other applicable safety codes and regulations. Please refer to Dynabrade's
Warning/Safety Operating Instructions for more complete safety information.
19
15
13
O
1
28 N•m
7
A
2
A
2
Note: To order replacement parts specify the model and serial number of your machine.
Standard Grip
Dynorbital
See page 2 for Machine Exhaust Assemblies.
21
20
18
17
16
14
26
12
27
28
11
29
10
9
8
T
6
5
4
3
2
1
Parts Page Reorder No. PD00•73
Effective September, 2000
Supercedes PD97•22
®
Supreme
3/32" Dia.Orbit, 10,000 RPM
Random Orbital Sander
22
23
24
23 N•m
Housing & Models Used On
57036 - 3-1/2" Non-Vac
57037 - 3-1/2" Basic-Vac, Deluxe-Vac
Vac-Ready
57038 - 3-1/2" Central Vac-Ready
w/ Overskirt
57170 - 5" Non-Vac
57167 - 5" Basic-Vac, Deluxe-Vac
Vac-Ready
57168 - 5" Central Vac-Ready
57169 - 5" Basic-Vac, Deluxe-Vac
Vac-Ready w/ Overskirt
57171 - 5" Central Vac-Ready
w/ Overskirt
57172 - 6" Non-Vac
57173 - 6" Basic-Vac, Deluxe-Vac
Vac-Ready
57174 - 6" Central Vac-Ready
57175 - 6" Basic-Vac, Deluxe-Vac
Vac-Ready w/ Overskirt
57176 - 6" Central Vac-Ready
w/ Overskirt
57295 - 3" Non-Vac
57296 - 3" Vac-Ready
57297 - 3" Central Vac-Ready
Lip-Seal Shroud (Non-Vac only)
54458 — 3" Models
54458 — 3-1/2" models
56051 — 5" and 6" Models
Sanding Pads - see page 7.
Vacuum Lip-Seal Shroud
57089 — 5" and 6" Models
Vacuum Overskirts
57084 — 3" Models
57084 — 3-1/2" Models
57086 — 5" Models
57087 — 6" Models
50679 26mm Wrench
25
A
8
O
T
