Models:
57000 - 3-1/2" Non-Vacuum
57001 - 3-1/2" Basic Vacuum
57002 - 3-1/2" Deluxe Vacuum
57003 - 3-1/2" Vac-Ready
57004 - 3-1/2" Central Vac-Ready
57015 - 5" Non-Vacuum
57016 - 5" Basic Vacuum
57017 - 5" Deluxe Vacuum
57018 - 5" Vac-Ready
57019 - 5" Central Vac-Ready
57021 - 5" Basic Vac w/overskirt
57022 - 5" Deluxe Vac w/overskirt
!
WARNING
95626 Snap Ring
57054 Rear Ring
01206 Bearing
57056 Rear Bearing Plate
95971 Line-up Pin
57058 Cylinder Assembly
(Includes 95971 Line-up Pin)
57113 Blade (5) and
Rotor set
O
57057 Front Bearing Plate
57088 Bearing
57055 Front Ring
95973 Washer
57059 Lock Ring Seal
T
3
56047 Rotor Key
Motor Shaft Balancer
57060 — 3-1/2"
57061 — 5"
57062 — 6"
56052 Balancer Bearing
L
2
56053 Bearing Seal
95628 Bearing Shield
57069 Balancer Shaft
95630 Snap Ring
57023 - 5" Vac-Ready w/overskirt
57024 - 5" Central Vac-Ready w/overskirt
57026 - 6" Non-Vacuum
57027 - 6" Basic Vacuum
57028 - 6" Deluxe Vacuum
57029 - 6" Vac-Ready
57030 - 6" Central Vac-Ready
57032 - 6" Basic Vacuum w/overskirt
57033 - 6" Deluxe Vacuum w/overskirt
57034 - 6" Vac-Ready w/overskirt
57035 - 6" Central Vac-Ready w/overskirt
Always operate, inspect and maintain this tool in accordance with the Safety Code for portable air tools (ANSI
B186.1) and any other applicable safety codes and regulations. Please refer to Dynabrade's Warning/Safety
Operating Instructions for more complete safety information.
95979 Pin
57063 Lever
95697 Snap Ring
01025 O-Ring (2)
01477 Valve Stem
57064 Speed Regulator
or
57053 Recessed Speed
Regulator
Note: To order replacement parts specify the model and serial number of your machine.
Random Orbital Sander, 3/16" Dia. Orbit.
See page 2 for Machine Exhaust Assemblies.
01464 Seal
01472 Tip Valve
Housing
57071 - 3-1/2" Non-Vac
57072 - 3-1/2" Vac
57073 - 3-1/2" Central-Vac
57077 - 5" Non-Vac
57078 - 5" Vac
57079 - 5" Central-Vac
57094 - 5" Vac w/overskirt
O
L
T
50679 26mm Wrench
Parts Page Reorder No. PD97•21
Effective March, 1997
Supercedes PD96•01
Dynorbital
Supreme
01494 Inlet Bushing
01468 Spring
57095 - 5" Central-Vac w/overskirt
57080 - 6" Non-Vac
57081 - 6" Vac
57082 - 6" Central-Vac
57096 - 6" Vac w/overskirt
57097 - 6" Central-Vac w/overskirt
KEY
Oil
Grease
G
Loctite/Hernon: L
= Loctite #271
2
Torque: N•m x 8.85 = In. - lbs.
T
= 23 N•m, T
= 28 N•m
2
3
Lip-Seal Shroud (Non-Vac only)
54458 — 3-1/2" models
56051 — 5" and 6" Models
Sanding Pads - see page 7.
Vacuum Lip-Seal Shroud
57089 — 5" and 6" Models
Vacuum Overskirts
57084 — 3-1/2" Models
57086 — 5" Models
57087 — 6" Models
®
T
L
2
2
