NuWave BRAVO PRO 20835, 20835C, 20835K, 20835M, 20835R Manual

PARTS & ACCESSORIES

Never use the Bravo with loose, damaged, or missing parts.

1. Base

2. Heavy-Duty Cooking Rack
   Part #: BVA10
3. Baking Pan
   Part #: BVA9
4. Air Fry Basket
   Part #: BVA11
5. Crumb Tray
   Part #: BVA2

Replacement parts can be ordered directly by visiting www.nuwavenow.com.

ASSEMBLY GUIDE

1. Place the Bravo on a level, even, and stable heat-resistant surface.
2. Slide the Cooking Rack into either Slot 1 or 2 of the Bravo.

3. Place Baking Pan on Cooking Rack.
4. Place Crumb Tray into position by sliding it into slot at bottom of oven. To remove, pull out.
5. Plug the Bravo into a standard wall socket. The power plug is located in the rear of the Bravo.

Note:
DO NOT cover or block the intake air vents located in the back and sides of the Bravo, as doing so can prevent proper ventilation.

Oven Rack and Pan Positions

Position 1: For chicken or other large items (with Baking Pan) as shown.

Position 2

Position 3

Position 4: Dehydrating only

MENU

INSTRUCTIONS

Getting Started

ON/OFF

1. Turns the Bravo ON and OFF. This also stops any cooking function.

NOTE:

• TEMP, TIME, FAN, TOP/BTM will show in the display.

START/PAUSE
The default is 350°F for 15 minutes

1. Press START/PAUSE to begin cooking.
2. Press again to pause cooking.
3. Turn the START/PAUSE dial to adjust the TEMP or TIME, TOP/BTM, and to select MENU items.
4. When the Bravo has finished cooking, it will beep 3 times and "End" will be shown on the display.

MUTE/UNMUTE

1. Press and hold START/PAUSE until 2 beep are heard.
2. Repeat to unmute.

TEMP
Allows you to view or adjust the cooking temperature. Default is 350°F. Range 50°F-450°F.

1. Press TEMP and make any adjustments to the cooking temperature by turning the START/ PAUSE dial.
2. Press START/PAUSE to begin cooking at the set temperature.
   • The cooking temperature can be adjusted at any point before or during the cooking process. The Bravo will continue to cook at the new temperature.

TIME
View or adjust the cooking time. Default is 15 minutes. Range is 00:01-99:99

1. Press TIME and make any adjustments by turning the START/PAUSE dial.
2. The Bravo will continue to cook at the new time setting.

Time range Chart

• 50F~275F: 00:00-99:99 (0-min. to 99hrs., 99-min.)
• 280F~400F: 00:00-24:00 (0-min. to 24hrs.)
• 405F~450F: 00:00-01:00 (0-min. to 1-hr.)

FAN

1. Press FAN to adjust the fan speed. FAN3 is the default and the fastest setting.
2. Press FAN to lower the fan speed. Each button press will lower the speed setting. FAN2, then FAN1, until the fan is off on setting FAN0.
3. Press FAN again to return to the default FAN3.

WARM
The default for Warm is 140ºF for 1 hour. Range: 50°F-200°F, 1 minute to 3 hours (00:01-03:00).

1. After setting your cooking temperature and time, press WARM to keep your food warm after the Bravo is done cooking.
2. Turn the START/PAUSE dial to make adjustments to the warming temperature and time.
3. Press START/PAUSE to start cooking. The Bravo will go through the regular cooking cycle. Once completed the Bravo will go to Warm at the set temperature and time.

Using Warm as an Independent Function

1. Press and hold WARM for 1 second (until you hear a beep). The Bravo will begin the warming function at the default settings.
2. Turn the START/PAUSE dial to make adjustments to the warming temperature and time.
3. When the warming time runs out, the display will show "End" and the Bravo will beep 3 times.

Notes:

• Warm can be used with the Menu options as well: Choose the menu option and press WARM. Adjust warm temperature and time, then press START/PAUSE.
• To cancel the Warm function at any time press WARM. WARM will no longer be lit in the display.

MENU
There are 12 menu options for you to choose from.

1. Press MENU. Turn the START/PAUSE dial or continue to press MENU to scroll through the menu options.
2. Once you make your menu selection, press START/PAUSE to begin cooking using the default settings shown in "MENU" section. The colon (:) on the screen will be flashing, indicating that the Bravo is now cooking.
3. The cooking temperature and time can be adjusted by turning the START/PAUSE dial.

TOP/BTM
This allows you to adjust the heat distribution between the top and bottom of the unit. The default settings are 50% Top, 50% Bottom. The percentages always add up to 100%.

1. Press TOP/BTM. TOP will be shown on the display allowing you to adjust the heating percentage in 10% increments by turning the dial.
2. Press TOP/BTM again to see the Bottom heat percentage and adjust if necessary. As a reminder, the combined top and bottom percentages will always add up to 100%.
3. Once the distribution is set, press START/PAUSE to begin cooking.

Helpful Tips

1. To add more time during current cooking cycle, with time showing turn START/PAUSE dial clockwise. Monitor food to ensure it does not overcook.
2. Some moisture may appear on the door during certain cooking cycles.
3. When air-frying, food can be lightly coated with oil to boost crispiness and browning.

CLEANING & MAINTENANCE

Before First Use

Wash all removable parts in warm, soapy water or in the dishwasher, top rack only.

1. Remove all the packaging materials.
2. Remove the glue, tape and labels on the appliance.
3. Clean the Cooking Rack, Baking Pan, Air Fry Basket and Crumb Tray thoroughly with hot water, a nonabrasive sponge, and mild dish detergent, or in the dishwasher, top rack only.

• Wipe the inside and outside of the Bravo with a damp dishcloth or wet cloth and dry thoroughly.
• To remove the new appliance smell before cooking.
• Start the appliance without any food, at the default temperature for 25 minutes, then cool for 15 minutes. Repeat if necessary.
• If problem persists: Contact Customer Service at help@nuwavenow.com.

DO NOT immerse the Bravo in water.

Clean After Each Use

1. Allow the Bravo to cool completely before cleaning.
2. Always unplug the Bravo from the electrical outlet. NEVER clean the Bravo while it is plugged in.
3. Never use harsh abrasive or corrosive product cleaners, as they may damage the finish or oven surface. Wipe the exterior with a clean, damp cloth and dry thoroughly.
4. Apply the cleaning agent directly to a cloth towel, not directly to the Bravo, before cleaning.
5. To clean interior, use a damp cloth, mild liquid soap solution, and a clean cloth towel.
6. Never use steel wool pads, etc., on interior or exterior of oven.
7. When the glass window is completely cool, spray glass cleaner on a clean cloth towel. Clean both inside and outside of window with cloth. Use a damp cloth to rinse the window then dry completely with a clean dry towel.
8. To remove crumbs, slide out the Crumb Tray and discard crumbs. Wipe clean and replace. Crumb Tray should be emptied and cleaned after each use.
9. To remove baked-on grease, soak Baking Pan, Air Fry Basket, and Crumb Tray in hot, soapy water. DO NOT soak for more than 10 minutes at a time. Never operate the oven without the Crumb Tray in place.

Storage

• Unplug the Bravo and let the Bravo cool down completely.
• Make sure that all parts are cleaned and dry.
• Never wrap the cord around the Bravo.

TROUBLESHOOTING GUIDE

The Bravo is engineered with an automatic shut-off feature to prevent overheating during use. If the Bravo shuts off to cool itself down, an odor may be detected. Unplug the Bravo and wait for it to completely cool down. To prevent the Bravo from overheating, do not cook foods at higher temperatures or longer times than recommended.

IMPORTANT SAFEGUARDS

HOUSEHOLD USE ONLY • READ ALL INSTRUCTIONS BEFORE USE

When using electrical appliances, basic safety precautions should always be followed including the following:

1. Read all instructions.
2. DO NOT touch hot surfaces. Use handles or knobs.
3. To protect against electrical shock do not immerse cord, plugs in water or other liquid.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts.
6. DO NOT operate any appliance with a damaged cord or plug or after the appliance malfunctions or has been damaged in any manner. Any service MUST be done by Nuwave LLC or authorized by the manufacturer for repairs.
7. The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.
8. DO NOT use outdoors.
9. DO NOT let cord hang over edge of table or counter or touch hot surfaces.
10. DO NOT place on or near a hot gas or electric burner, or in a heated oven.
11. Extreme caution must be used when moving an appliance containing hot oil or other hot liquids.
12. To disconnect, turn any control to "off", then remove plug from wall outlet.
13. DO NOT use appliance for other than intended use.
14. Save these instructions.

ADDITONAL SAFEGUARDS

15. While cooking,ALWAYS use oven mitts and allow accessories to cool before washing.
16. Ensure the Bravo Pro and all parts are clean and dry before each use.
17. Discard the protective plastic covering.
18. This appliance is not intended for use by persons with reduced physical, sensory or mental capabilities, children, or persons with a lack of experience or knowledge, unless supervised or instructed in the use of the appliance by one responsible for their safety.
19. Use only on a clean, stable, dry, and level surface.
20. DO NOT cover or block the intake air vents located in the back and sides of the Bravo Pro, as doing so can prevent proper ventilation. There should be at least 5 inches of free space behind, to the sides of, and on top of the Bravo Pro.
21. Use aluminum foil to wrap foods that produce oil or juice when operating the Drip/Baking Pan to catch drippings and prevent fire.
22. To prevent fire, do not allow any foil to touch the heating elements.
23. Avoid placing your face near the glass door during use.
24. NEVER touch the insides of the BravoPro while it is operating.
25. NEVER leave the Bravo Pro unattended during use.
26. DO NOT disassemble the Bravo Pro.
27. Allow the Bravo Pro to cool before putting in or pulling out items or before cleaning.
28. DO NOT place objects on top of the Bravo.

Toaster Oven Warnings (UL Standard 1026, Section 71.7):

1.
   Oversize foods or metal utensils must not be inserted in a toaster oven as they may create a fire or risk of electric shock.
2. A fire may occur if the toaster-oven is covered or touching flammable material, including curtains, draperies, walls, and the like, when in operation. DO NOT store any item on top of the appliance when in operation.
3. DO NOT clean with metal scouring pads. Pieces can break off the pad and touch electrical parts creating a risk of electric shock.
4. Extreme caution should be exercised when using containers constructed of materials other than metal or glass.
5. DO NOT store any materials, other than the manufacturers recommended accessories, in this oven when not in use.
6. DO NOT place any of the following materials in the oven: paper, cardboard, plastic, cloth, wood, flammable materials, sealed containers, and the like.
7. DO NOT cover the crumb tray or any part of the oven with metal foil. This will cause overheating of the oven.
8. Turn off the Toaster Oven by pressing the On/Off Button before unplugging the unit from the wall socket.

Power-Supply Cords
A short power-supply cord (or detachable power-supply cord) is provided to reduce the risk of becoming entangled in, or tripping over, a longer cord. Longer detachable power-supply cords or extension cords are available and may be used if care is exercised in their use. If a longer detachable power-supply cord or extension cord is used:

1. The marked electrical rating of the extension cord should be at least as great as the electrical rating of the appliance.
2. The longer cord should be arranged so that it will not drape over any countertop or tabletop where it could be pulled on or tripped over unintentionally.
3. The Toaster Oven should be operated on a separate electrical outlet from other operating appliances due to wattage limitations.

DO NOT place the unit on or near a hot gas burner, electric burner, or in a heated oven or a stovetop.

NOTICE
It's perfectly normal for your new unit to produce a heated plastic smell when used for the first time. This will go away after the first few uses.

Register Today!
Use your smartphone or device to scan the QR code located on the back of your unit to register your product, or visit Nuwavenow.com/register.

Connect with Us!

#nuwavenow

Visit nuwavenow.com to see other great products and accessories.

Scan the code to find recipes, how-to videos and more!

Questions or Concerns?
Customer Service: support@nuwavenow.com
1-888-502-7805
Mon-Fri 7:30am-4:30pm CST

FOR HOUSEHOLD USE ONLY
120V, 60Hz, 1800 Watts

Model:
20835
20835B
20835C
20835K
20835M
20835R

Designed & Developed in USA
Nuwave LLC
560 Bunker Ct.
Vernon Hills, IL 60061, U.S.A.

www.nuwavenow.com
