Thank you, and congratulations on your choice of the UM-3EX USB MIDI Interface.
201a
Before using this unit, carefully read the sections entitled: "USING THE UNIT
SAFELY" and "IMPORTANT NOTES" (p. 2; p. 4). These sections provide
important information concerning the proper operation of the unit. Additionally,
in order to feel assured that you have gained a good grasp of every feature
provided by your new unit, Owner's manual should be read in its entirety. The
manual should be saved and kept on hand as a convenient reference.
202
Copyright © 2005 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form
without the written permission of ROLAND CORPORATION.
Mode d'emploi
Manuale d'uso

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UM-3EX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Roland UM-3EX

Summary of Contents for Roland UM-3EX

  • Page 1 Mode d’emploi Manuale d’uso Manual del usuario Thank you, and congratulations on your choice of the UM-3EX USB MIDI Interface. 201a Before using this unit, carefully read the sections entitled: “USING THE UNIT SAFELY” and “IMPORTANT NOTES” (p. 2; p. 4). These sections provide important information concerning the proper operation of the unit.
  • Page 2 • Subject to high levels of vibration. directing you to do so). Refer all servicing ....................to your retailer, the nearest Roland • This unit should be used only with a rack Service Center, or an authorized Roland mount adaptor (RAF-70) that is recom- distributor, as listed on the “Information”...
  • Page 3 • When using the unit with a rack or stand • In households with small children, an recommended by Roland, the rack or adult should provide supervision until stand must be carefully placed so it is the child is capable of following all the level and sure to remain stable.
  • Page 4 IMPORTANT NOTES 291a In addition to the items listed under “USING THE UNIT SAFELY” on page p. 2, please read and observe the following: Power Supply Maintenance 401a • Before connecting this unit to other devices, turn • For everyday cleaning wipe the unit with a soft, off the power to all units.
  • Page 5 Handling CD-ROMs * Microsoft and Windows are registered trademarks of Microsoft Corporation. • Avoid touching or scratching the shiny underside 206e (encoded surface) of the disc. Damaged or dirty * The screen shots in this document are used in com- CD-ROM discs may not be read properly.

  • Page 6: Table Of Contents

    Transmitting MIDI Messages from the sequencer software to a MIDI sound module or digital piano ..39 Transmitting MIDI messages from a MIDI Keyboard or other device to a MIDI sound module..40 Appendices ........................42 Connecting multiple UM-3EX units ..................42 Installing the Driver ............................43 Connection examples ............................44 Troubleshooting ........................
  • Page 7 Anschlüsse herstellen und Treiber installieren (Macintosh) ........66 Vor dem Installieren des Treibers ..................... 66 Installation und Einstellungen des Treibers ................67 Mac OS X-Anwender ............................67 Anhang ..........................72 Anschluss mehrerer UM-3EX Geräte ..................72 Français Description......................... 74 Face avant ............................. 74 Face arrière ........................... 76 Connexion et installation des pilotes (Windows)............
  • Page 8 Conexión e instalación de los controladores (Macintosh).......... 114 Antes de instalar el controlador ....................114 Instalación del controlador y ajustes ..................115 Usuarios de Mac OS X ..........................115 Apéndices ........................120 Conexión de varias unidades UM-3EX .................. 120 Index ..........................122...
  • Page 9 Contents of the Package The UM-3EX includes the following items. When you open the package, first make sure that all items are included. If any are missing, contact the dealer where you purchased the UM-3EX. USB MIDI Interface UM-3EX fig.um-3-front.eps_50 CD-ROM This contains drivers for use with the UM-3EX.

  • Page 10: Names Of Things And What They Do

    Names of Things and What They Do Front Panel fig.front.eps_25 MIDI IN Connectors Connect these to the MIDI OUT connectors of the devices (such as a MIDI keyboard) that will be transmitting MIDI messages to your computer. MIDI OUT/THRU Connectors Connect these to the MIDI IN connectors of sound modules or other devices to which you’ll be sending MIDI messages from your computer for playback.
  • Page 11 This will light when you’ve connected the UM-3EX to your computer and your computer has detected the UM-3EX. In order for your computer to detect the UM-3EX, you must install the driver and make settings. (➔“Getting Connected and Installing Drivers (Windows)” (p. 14), “Getting Connected and...

  • Page 12: Rear Panel

    Connect this to the USB connector of your computer. MODE select switch The UM-3EX can be set to function as either the master or a slave device by means of this switch. Select the MASTER setting if you’re using a single UM-3EX When using a single UM-3EX unit unit.
  • Page 13 UM-3EX connectors Use these when connecting multiple UM-3EX units. * Do not connect any device other than a UM-3EX to the UM-3EX connector. Doing so may cause the UM- 3EX to malfunction. * Connection of multiple units is supported only in Windows XP and Mac OS X. For details, refer to...

  • Page 14: Getting Connected And Installing Drivers (Windows)

    UNIT number select switch Set to 1. * Don’t change the setting of the MODE select switch or UNIT number select switch while the UM-3EX is connected to your computer. You must first disconnect the UM-3EX from your computer. Then, after you’ve...

  • Page 15: Installing The Driver

    1. With the UM-3EX left unconnected, start up Windows. Do not connect the UM-3EX to the computer until you reach Step 14 ( p. 17). * Disconnect all USB cables except for a USB keyboard and USB mouse (if used).
  • Page 16 3. Click the Hardware tab, then click [Driver Signing]. The Driver Signing Options dialog box will open. 4. In the Driver Signing Options dialog box, select “Ignore,” then click [OK]. If the current setting is “Warn” or “Block,” change this to “Ignore.” Then, when you’ve finished installing the driver, change it back to the original setting.
  • Page 17 Operation of the UM-3EX A message of “Found New Hardware” will appear. Please wait. * This unit is equipped with a protection circuit. A brief interval (a few seconds) after connecting the UM-3EX is required before the unit will operate normally.
  • Page 18 ■ Giving priority to Background Services To ensure that MIDI data is handled smoothly, proceed as follows to make this setting. Windows XP users: 1. Open the System Properties dialog box. 1. From the Windows start menu, choose Control Panel. 2.
  • Page 19 Windows 2000 users: 1. Click the Windows Start button, and from the menu that appears, select Settings | Control Panel. 2. In Control Panel, double-click the System icon. 3. Click the Advanced tab. 4. At the right of the Performance field, click [Performance Options]. The Performance Options dialog box will appear.

  • Page 20: Windows Me/98 Users

    Operation of the UM-3EX A message of “Found New Hardware” will appear. Please wait. * This unit is equipped with a protection circuit. A brief interval (a few seconds) after connecting the UM-3EX is required before the unit will operate normally.

  • Page 21: Setting The Driver

    Setting the Driver The following describes the settings needed to use the UM-3EX with Media Player or other sequencer software using Windows standard device settings. If you are using sequencer software that does not utilize Windows standard device settings, make the device settings within the sequencer software.

  • Page 22: Windows 2000/Me Users

    MIDI device from the list that appears. If you select “EDIROL UM-3 MIDI 1,” a sound module connected to the UM-3EX’s MIDI 1 OUT/THRU connector can be played from sequencer software (such as Media Player) that uses Windows standard device settings.

  • Page 23: Windows 98 Users

    3. Select [Single instrument], and select the MIDI device from the list that appears. If you select “EDIROL UM-3 MIDI 1,” a sound module connected to the UM-3EX’s MIDI 1 OUT/THRU connector can be played from sequencer software (such as Media Player) that uses Windows standard device settings.

  • Page 24: Getting Connected And Installing Drivers (Macintosh)

    Before you install the driver Here’s the procedure for installing a single UM-3EX. If you’re using Mac OS X, you can simultaneously connect up to three UM-3EX units to a single Macintosh via USB. * Connection of multiple units is supported only in Mac OS X. For details, refer to “Connecting multiple UM-3EX units”...

  • Page 25: Driver Installation And Settings

    Driver Installation and Settings What is a driver? A “driver” is software that transfers data between the UM-3EX and application software running on your Macintosh, when your Macintosh and the UM-3EX are connected. The driver sends data from your application to the UM-3EX, and from the UM-3EX to your application.

  • Page 26: Mac Os X Users

    * What you actually see on your Macintosh screen may be different, depending on your computing environment and the operating system you’re using. 1. With the UM-3EX left unconnected, start up Macintosh. * Disconnect all USB cables other than those for your keyboard and mouse, and restart your Macintosh.
  • Page 27 UNIT number select switch. * If “1: UM-3” does not appear or if it is grayed out, it means that the UM-3EX is not being recognized properly. Click Rescan MIDI. Also try disconnecting and reconnecting the UM-3EX.
  • Page 28 Third external device 1: UM-3 3 * Enter the UNIT number of the UM-3EX as the first number “1:.” 9. Use the mouse to drag the ▼ and ▲ symbols that indicate the inputs and outputs of the 1: UM-3 icon and the new external device icons so that they are connected as follows.
  • Page 29 • Do not disconnect the UM-3EX from your Macintosh while your sequencer software is running. Quit your sequencer software before you disconnect the UM-3EX from your Macintosh. • The UM-3EX will not operate in the Mac OS X Classic environment. Use the UM-3EX when the Classic environment is not running.

  • Page 30: Mac Os 9 Users

    * If you install OMS after installing the UM-3 driver, you must install the UM-3 driver once again. If a UM-3EX is already connected to your Macintosh when you install the driver, a message like the following will appear when the Macintosh is started up. Perform the steps described below as appropriate for the message that is displayed.
  • Page 31 fig.os9-6e.eps 6. If a message like the following is displayed, click [Continue]. The other currently running software will exit, and installation will continue. 7. A dialog box will indicate Installation was successful. Click [Restart] to restart your Macintosh. Next, make the driver settings. •...
  • Page 32 * Connect the cable to the USB connector of the Macintosh itself, not to the USB connector of the keyboard. * This unit is equipped with a protection circuit. A brief interval (a few seconds) after connecting the UM-3EX is required before the unit will operate normally.
  • Page 33 fig.oms-7e.eps_35 7. The Create a New Studio Setup dialog box will appear. Click [Cancel]. If you accidentally clicked [OK], click [Cancel] in the next screen. fig.oms-8e.eps_35 8. Choose Open from the File menu. From the OMS Setting folder that you copied in step 4, select the UM-3 file, and click [Open].
  • Page 34 fig.oms-9e.eps_35 9. From the Edit menu, select OMS MIDI Setup. In the OMS MIDI Setup dialog box that appears, check Run MIDI in background, and click [OK]. fig.oms-10e.eps_35 A diamond mark ( ) indicates the settings are enabled. 10. From the File menu, choose Make Current. If you are unable to select Make Current, it has already been applied, and you may continue to the next step.
  • Page 35 Click the MIDI connector icon shown in the illustration. If the corresponding MIDI OUT indicator of the UM-3EX blinks, the settings are correct. 13. Exit OMS Setup. From the File menu, choose Exit. If the AppleTalk confirmation dialog box appears, click [OK] to...
  • Page 36 * Connect the cable to the USB connector of the Macintosh itself, not to the USB connector of the keyboard. * This unit is equipped with a protection circuit. A brief interval (a few seconds) after connecting the UM-3EX is required before the unit will operate normally.
  • Page 37 fig.freemidi-10.eps_35 10. The mouse cursor will change to the shape of a keyboard. Click the icon shown in the illustration. If the corresponding MIDI OUT indicator of the UM- 3EX blinks, the settings are correct. 11. Once again choose the MIDI menu command Check Connections to end the test. 12.

  • Page 38: Basic Use

    MIDI messages from the MIDI device (e.g, MIDI keyboard, digital piano) connected to the UM-3EX’s MIDI IN connector are transmitted to the computer. * Don’t change the setting of the THRU switch while you’re using the UM-3EX. Doing so will cause MIDI errors.

  • Page 39: Transmitting Midi Messages From The Sequencer Software To A Midi Sound Module Or Digital Piano

    MIDI messages from the computer are transmitted to the MIDI device (e.g., MIDI sound module, digital piano) connected to the UM-3EX’s MIDI OUT/THRU connector. * Don’t change the setting of the THRU switch while you’re using the UM-3EX. Doing so will cause MIDI errors.

  • Page 40: Transmitting Midi Messages From A Midi Keyboard Or Other Device To A Midi Sound Module

    MIDI messages from the MIDI keyboard or digital piano connected to the UM-3EX’s MIDI IN connector will be sent to the MIDI sound module connected to the UM-3EX’s MIDI OUT/THRU connector. Even if the UM-3EX is connected to a computer, no MIDI messages will be sent to the computer.
  • Page 41 ■ ON/OFF Settings of the THRU Switches You can use the THRU switches to select the transmission destinations for MIDI messages from the devices (MIDI keyboard, digital piano, etc.) connected to the MIDI IN connectors. There is no need to change any cable connections. Switch Setting MIDI Message Destination Device MIDI messages are transmitted to your computer (sequencer software).

  • Page 42: Appendices

    Connecting multiple UM-3EX units If you’re using Windows XP or Mac OS X, you can simultaneously connect up to three UM-3EX units via USB to a single computer. Depending on your system, the second or subsequent unit may not be usable depending on the limitations imposed by the CPU processing speed, hard disk, memory, and the performance of your software.

  • Page 43: Installing The Driver

    1. On the second and third UM-3EX units, set the MODE select switch to SLAVE. 2. On the second and third UM-3EX units, set the UNIT number select switch to 2 or 3. 3. Connect the second and third UM-3EX units to the UM-3EX connector of the first unit.

  • Page 44: Connection Examples

    • Set the second unit to 2. * Don’t change the setting of the MODE select switch or UNIT number select switch while the UM-3EX is connected to your computer. You must first disconnect the UM-3EX from your computer. Then, after you’ve...
  • Page 45 • Set the third unit to 3. * Don’t change the setting of the MODE select switch or UNIT number select switch while the UM-3EX is connected to your computer. You must first disconnect the UM-3EX from your computer. Then, after you’ve...
  • Page 46 Don’t make connections like the following. UM-3EX set to SLAVE and connected to a computer fig.ng-double-e.eps_70 Set this to Set this to MASTER. SLAVE. First unit UM-3EX set to MASTER and connected to a UM-3EX connector fig.ng-double2-e.eps_70 Set this to Set this to SLAVE. MASTER.

  • Page 47: Troubleshooting

    Be sure to close all other programs before installation. Is the CD-ROM correctly inserted into your CD-ROM drive? Installation is not possible unless the CD-ROM included with the UM-3EX is inserted in your CD- ROM drive. Make sure that the CD-ROM is correctly inserted into your CD-ROM drive.
  • Page 48 USB. Check the settings of your computer. • In some cases, the UM-3EX cannot be used with a bus-powered hub (a hub that does not contain a power supply). Please use a self-powered hub (a hub that contains a power supply).
  • Page 49 Did you connect the UM-3EX to a different USB connector than the one you used when installing the driver? If your computer or USB hub has two or more USB connectors, and you connect the UM-3EX to a different USB connector, you may be asked for the driver file even though the driver has already been installed in your computer.
  • Page 50 Check the settings of your computer. • In some cases, the UM-3EX cannot be used with a bus-powered hub (a hub that does not contain a power supply). Please use a self-powered hub (a hub that contains a power supply).
  • Page 51 Macintosh, and then restart it. • In some cases, the UM-3EX will not be detected if you have connected it to the USB connector located on the keyboard of the Macintosh. Please connect it to a USB connector on the...
  • Page 52 Deleting the Driver If you were unable to install the driver according to the procedure given, the UM-3EX may not be recognized correctly by the computer. In this case, use the following procedure to delete the driver, and then follow the procedure to install the driver once again.
  • Page 53 Macintosh (Mac OS X) users 1. Start up Macintosh with the UM-3EX disconnected. Disconnect all USB cables other than a USB keyboard or USB mouse. 2. Prepare the CD-ROM. Insert the CD-ROM into the CD-ROM drive of your Macintosh. 3. In the Driver (Mac OS X) folder of the CD-ROM, double-click “UM3_Uninstaller.”...
  • Page 54 Was a heavy processing load experienced while using the UM-3EX, such as accessing the CD-ROM drive or a network? If an operation involving a heavy processing load is performed while the UM-3EX is in use, it may not operate correctly. If this occurs, stop playback/recording, and then try resuming playback/ recording.
  • Page 55 Operation becomes unstable when the computer is started up with the UM-3EX already connected Please start up your computer with the UM-3EX disconnected, and then connect the UM-3EX. On a computer that uses a USB keyboard, starting up the computer with the UM-3EX already connected may cause operation to become unstable.

  • Page 56: Main Specifications

    Main Specifications ■ UM-3EX: USB MIDI Interface Controllers THRU switch 1 THRU switch 2 THRU switch 3 MODE select switch UNIT number select switch Connectors MIDI IN Connector x 3 (16 MIDI Channels x 3) MIDI OUT/THRU Connector x 3 (16 MIDI Channels x 3)
