Manual de instalare
BP-50M26/50M31/50M36BP-50M45/50M55/50M65BP-
70M31/70M36/70M45BP-70M55/70M65
Considerente generale privind instalarea echipamentelor de printing:
- Manipularea echipamentelor se face respectand procedurile de
transport si punere in locatie tinand cont de gabaritul echipamentului si
a spatiului destinat acestuia
- Respectarea normelor privind conectarea la reteaua electrica, folosirea
de prize cu impamantare este obligatorie
- Fixarea corecta a echipamentului pe standul acestuia
- Verificarea cu atentie si eliberarea tuturor blocajelor folosite la transport
(inclusiv cel pentru scanner, unitati developare, cilindrii, etc)
- Montarea corecta a tonerelor in echipament dupa agitarea prealabila
(atentie unele echipamente nu au tonerul in echipament ci separat)
- Manipularea cu atentie a cilindrilor evitand pe cat posibil expunerea
prelungita a acestora la lumina.
- Manipularea cu atentie a cuptorului tinand cont de temperatura
acestuia
- Temperatura ambientală unde se folosesc aparatele şi echipamentele
trebuie să fie între 18 şi 30 grade celsius, cu grad minim de praf şi
umiditate.
pentru
multifunctionale
SHARP
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sharp BP-50M26
Summary of Contents for Sharp BP-50M26
- Page 1 Manual de instalare pentru multifunctionale SHARP BP-50M26/50M31/50M36BP-50M45/50M55/50M65BP- 70M31/70M36/70M45BP-70M55/70M65 Considerente generale privind instalarea echipamentelor de printing: - Manipularea echipamentelor se face respectand procedurile de transport si punere in locatie tinand cont de gabaritul echipamentului si a spatiului destinat acestuia - Respectarea normelor privind conectarea la reteaua electrica, folosirea...
-
Page 2: Table Of Contents
INSTALLATION MANUAL CODE: 00ZBP70M65I2E DIGITAL MULTIFUNCTIONAL SYSTEM BP-50M26/50M31/50M36 BP-50M45/50M55/50M65 BP-70M31/70M36/70M45 BP-70M55/70M65 MODEL CONTENTS Transit, Installation (Using) Environment, Note CONFIGURATION [1] MAIN UNIT ....... . 1-1 [2] BP-DE12/DE13/DE14 (STAND/550/2x550/3x550 SHEET PAPER DRAWER) . -
Page 3: Configuration
BP-70M65 CONFIGURATION 1. System diagram BP-70M65 CONFIGURATION – iv... -
Page 4: Option List
2. Option list BP-50M26 BP-70M31 BP-50M31 BP-70M36 BP-50M36 Model name Description BP-70M45 Remarks BP-50M45 BP-70M55 BP-50M55 BP-70M65 BP-50M65 Document Feed System REVERSING SINGLE PASS FEEDER DUPLEX SINGLE PASS FEEDER Paper Feed System BP-DE12 STAND/550 SHEET PAPER DRAWER BP-DE13 STAND/2x550 SHEET PAPER DRAWER... -
Page 5: Function Of Each Key
BP-70M65 [6] SIMULATION Service Manual General and purpose The simulation mode has the following functions, to display the machine operating status, identify the trouble position and causes in an earlier stage and to efficiently setup and adjust the machine for improved serviceability. -
Page 6: Main Unit
BP-70M65 [1] MAIN UNIT Unpacking B. Packed items check A. Removal of the fixing tape and protection material Parts name Quantity Operation manual Caution label for DSPF model Protection sheet Screw (For option desk) BP-70M65 MAIN UNIT 1 – 1... -
Page 7: Installation
Installation (3) Removal of the protection material. Open the right door and remove the protection material from <Note before installation> transfer roller. * When connecting the main unit with the optional paper drawer, first unpack and install the paper drawer, then unpack the main unit and securely place the main unit on the paper drawer before installing the main unit. - Page 8 Remove the connector. Remove two screws. Remove the cover. Slide the lever to the unlocked position. While supplying developer from the developer supply port of the developing unit, turn the MC gear counterclockwise by using UKOG-0341FCZZ to supply all developer to the developing unit. * Before opening the developer bag, shake the bag to mix toner and developer in the bag, and then supply developer to the developing unit.
-
Page 9: Install Toner Cartridge
C. Toner density reference control level setting Attach the cover. * Check to confirm that the pawl is securely engaged. NOTE: Execute Toner density reference control level setting without installing the toner cartridge. NOTE: Message displays on the screen about scanner lock release confirmation after power on. - Page 10 Open the front cover, and insert the toner cartridge. (2) Tray size setup Pull out the paper tray. Gently pull the tray out until it stops. If paper remains in the tray, remove it. * Do not forcibly insert the toner cartridge. Keep holding the cartridge and completely insert it.
-
Page 11: Image Quality Check
G. Image quality check Tap [EXECUTE] key. The copy density and gradation adjustment is performed automat- When there are defects in a image carry out the following contents and ically, and the adjustment pattern is printed. confirm image. If there is any streak or unclear print on the printed check pattern, Item check the print engine for any problems. - Page 12 Set the gray patch image (adjustment pattern) printed in the pro- The initial setting menu of the halftone image correction is dis- cedure 5) on the document table. played. Place the gray patch image so that the fine lines are on the left Tap [OK] key.
- Page 13 H. Caution label attachment (2) Print image position adjustment Before executing this adjustment, be sure to check the following Choose a language and attach the caution label. items. * There must be a tray with A4 (LT) paper in it. Execute Sim.
-
Page 14: Sheet Paper Drawer)
BP-70M65 [3] BP-DE15 (STAND/550&2100 SHEET PAPER DRAWER) Unpacking Turn each adjuster to fix the desk unit. If the connector is removed first, it may be damaged during the instal- lation procedures. Therefore, keep it packed while un-boxing. and unpack it only when connecting the connector to the machine. A. - Page 15 Remove the tray 1 and the tray 2. Take off the small cover of right and left sides of the main body rear. And fix them with the fixing screws (Packed item No.2). Return small covers. Raise the linkage plates on the right and left sides of the front side of the desk unit, and fix them with the fixing screws (Packed item C.
-
Page 16: Connector Connection
Pull out each tandem tray. Turn and remove the fixing material, Connect the connector. and remove the caution sheet. Attach the removed fixing material to the position shown in the fig- ure for storage. Close the tray which was pulled out. Separate the base of the cover in nippers. -
Page 17: Tray Size Setting
F. Tray setup b. Tray 3 (A4/LT) Pull out the Tandem paper feed tray. (1) System Settings Remove the Tandem tray regulation plate while pressing a hook. Tap [Initial Installation Settings] key on the touch panel. Tap [Tray Settings] for respective setting.Set up paper type, paper size and Feeding Approved Job for each tray.Touch [Tray Set- tings] key to display the list of tray and current settings. -
Page 18: Size Setting
Lay B5 rear edge regulation plate to set for A4/LT size.Erect the c. Tray 4 (A4/LT/B5) regulation plate to set for B5 size. Pull out the Tandem paper feed tray. Remove the Tandem tray regulation plate while pressing a hook. Insert Adjust plate boss to the holes on the Tandem tray regula- Push the Tandem paper feed tray. - Page 19 Calculation and input procedures of adjustment values (Example) Lead edge void amount (1) Measure by visual inspection. Measurement result: 4.5mm (2) Calculate the shift amount. The target value is the specification value (center value) of 3mm. * For the F side void amount, the target is 2mm. [4 –...
-
Page 20: Bp-Lc10 (Large Capacity Tray)
BP-70M65 [4] BP-LC10 (LARGE CAPACITY TRAY) Installation Unpacking Before installation, be sure to turn both the operation and main power If the connector is removed first, it may be damaged during the instal- switches off and disconnect the power plug from the power outlet. lation procedures. - Page 21 B. Main unit and large capacity tray connection Attach the mounting plate upper (Packed item No.2) to the right side of main unit with the fixing screw A (Packed item No.4). When installing, put the rubber section ( ) of the mounting plate upper on the lower side.
-
Page 22: Height Adjustment
Temporarily fix the fixing screw B (Packed item No.5) midway. Fix the fixing screw, and attach the screw cap back to the main unit. Insert the temporarily fixed screw B into the key hole in the con- 10) While lifting the section marked with insert the connection unit nection unit and temporarily fix the connection unit. - Page 23 Check to insure that the height adjustment check rib of the large In the case of a shift to the right, press the front upper section and capacity tray and the axis line of the mounting plate upper fit the height adjustment check rib so that it is in the same line with mounted to the main unit are in the same line.
-
Page 24: Paper Size Switch
D. Connector connection E. Paper size switch Remove the connector cover. Remove Rear cover. Do not use the connector cover removed. Remove fixing screw (4 pcs of blue screw) on upper and lower side of Side plate F and Side plate R. Connect the connector. - Page 25 Insert Size guide according to the engraved mark. Tighten upper and lower side using the fixing screws being removed (A4). (LT) (B5) Switching Rear edge plate Remove the blue screws fixing the upper and lower Rear edge plate respectively. BP-70M65 BP-LC10 (LARGE CAPACITY TRAY) 4 – 6...
- Page 26 Attach Rear cover. F. Turn ON the power of the main unit Connect the power plug of the machine to the power outlet, and turn ON the main power switch and the operation panel power switch. G. Size setting Execute SIM 26-2 "Size setting" with the key operations of the main Calculation and input procedures of adjustment values unit.
-
Page 27: Mechanical Adjustment
(2) Mechanical adjustment Since the off-center adjustment is performed when shipping, there is basically no need to perform this adjustment. If the center is shifted, however, the simulation is normally used. If the shift is not removed, perform the following adjustment procedures. a. -
Page 28: Mx-Lt10 (Long Paper Feeding Tray)
BP-70M65 [5] MX-LT10 (LONG PAPER FEEDING TRAY) Unpacking Hook the Long paper feeding tray to the guide of the machine. A. Packed items check Name Quantity Long paper feeding tray Insert the guide of the machine. Installation Do not insert the finger in the hook part of the tray. This tray can only be used for long paper feeding.
