Digital Multifunctional
System
BP-1360M/BP-1250M
User's Manual
Main Unit
Sharp Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BP-1360M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sharp BP-1360M

Summary of Contents for Sharp BP-1360M

  • Page 1 Digital Multifunctional System BP-1360M/BP-1250M User's Manual Main Unit Sharp Corporation...
  • Page 2 SHARP is not responsible for any direct or indirect damages arising from or caused by such data loss. SHARP is not responsible for any breakdown of machines due to infection of computer virus or ...

  • Page 3: Before Using The Machine

    Before Using the Machine Device Components Front Component Function Document Cover Holds a document in place. Document Glass Load a document here. Control Panel Consists of operation buttons, LED indicators, and the Touch Panel Display. Toner Cover Open this cover to replace toner. Front Cover Open this cover to clear paper jams or replace the consumables.

  • Page 4: Lan Connection

    Component Function Locking casters Used to move this machine. Lower Left Cover Open this cover to clear paper jams. Paper Tray 5 (Bypass) (optional) Used for loading non-standard paper that cannot be loaded in Trays 1, 2, 3, 4. Paper Tray 5 (Bypass) Top Cover Open this cover to clear paper jams.
  • Page 5 Inside Component Function Lower Right Cover Open this cover to clear paper jams. Waste Toner Container Cover Open this cover to replace the Waste Toner Container. Waste Toner Container Collects waste toner. Fusing Unit Fuses toner on paper. Handle Used to pull out the Transfer Unit. Transfer Unit Transfers toner images on the drum to paper.

  • Page 6: Control Panel

    Control Panel Refer For Control Panel, refer to the “User's Manual - Operations”. Component Function Paper Clip Tray Used for placing paper clips and staples. Power Button The power switches on. Note When “Please wait...” is displayed, the machine is warming up. ...

  • Page 7: Print Area

    Print Area In the case of printing 488 mm Trail edge 4.0 mm Lead edge 4.0 mm 480 mm 4.0 mm 4.0 mm 480 mm Top edge 5.1 mm 10.1 mm Extended printable area = Standard printable area 330.2 mm Guaranteed print area 320 mm 310 mm...

  • Page 8: Storing And Handling Paper

    Changing the extended printable area settings Login to the System Administrator Mode. > [Device] > [App Settings] > [Print Settings] > [Other Settings] > [Print Area] > [Extended]. When printing in the extended printable area via driver, change the settings from [Tray / Output] > [Edge Erase / Print Position] > [Margins] of the PCL printer driver.

  • Page 9: Loading Paper

    Basic Operations of the Machine Loading Paper After loading paper, configure the Paper Tray settings on the Home screen. Important Do not place paper or other objects in the reserved space of the tray. It may cause paper jams or machine malfunction.
  • Page 10 Pinch the guide clip, and adjust to the correct paper size. Fan a stack of paper, face the print surface down, and then load the paper with edges aligned according to the direction of the arrow. Important Do not load paper above the maximum fill line. It may cause paper jams or machine malfunction.
  • Page 11 When loading paper whose size is JIS B4 or larger, pinch the knob and lift the paper rear end guide, and set the guide into the hole for the indicated size. Pinch the two Guide Clips, and adjust to the correct paper size.
  • Page 12 Loadable paper Paper size Standard size SRA3 (320 x 450 mm), 12.6 x 19.2" (320 x 488 mm) Custom size (mm) 100 x 148 to 330 x 488 Single side printing 52 to 350 Paper weight (g/m paper) 280 Maximum number of sheets (sheets) (65 g/m *1: Banner Printing on long paper of up to 330 x 660 mm is available.

  • Page 13: Loading Documents

    Loading Documents Document Feeder Loadable paper Paper size (mm) Standard size A3, 11 x 17" Custom size (mm) 84 x 140 to 297 x 432 Paper weight Single side printing 38 to 200 (g/m Double side printing 50 to 200 Maximum number of sheets (sheets) (65 paper) Open the Document Cover.

  • Page 14: Document Glass

    Open the Document Stopper. Note To prevent a document from being left behind, “Document Feeder Attention Light” is turned on after the Scan job is completed and turned off after approx. 3 sec. Document Glass Loadable paper Paper size (mm) Width Up to 297 Length...

  • Page 15: Outputting Paper

    Outputting Paper Print Surface The print surface refers to the surface printed on in single-sided printing (the first page in double- sided printing). In the case of face down output, paper is output to the Tray with the print surface faced downward, and in the case of face up output, paper is output to the Tray with the print surface faced upward.

  • Page 16: Maintenance

    Consumables Consumables recommended by SHARP are manufactured under the standards suitable for this machine. Using consumables not recommended by SHARP may affect print quality or performance provided by the product. Use consumables that SHARP recommends for this machine. Consumable types...
  • Page 17 Cleaning Main Unit When wiping the main unit with a wet cloth, use a soft, moistened and tightly-squeezed cloth. The  main unit may break down if the moisture remains on it. Do not use chemicals such as benzine or thinner. Doing so may damage the paint or coating on ...
  • Page 18 Wipe off any dirt from the film. Wipe off any dirt from the glass. Close the Side 2 scanner, then close the Document Cover. Document Feeder rollers Clean the Document Feeder rollers about once a month. Pull up the front handle of the Top Cover of the Document Feeder, and open the cover until it stops.

  • Page 19: Paper Jams

    Paper Jams If paper is jammed, the machine stops and an alarm sounds. A message also appears on the control panel. Follow the instructions displayed to remove the jammed paper. Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the machine, remove all the torn pieces making sure that none remain inside the machine.
  • Page 20 Exit Depending on the optional units equipped in the right side of the machine, the method of paper removal differs. Refer For optional units, refer to “User's Manual - Operations”. Paper Trays 1, 2 Pull out the Paper Tray where the paper jam occurred until it stops.

  • Page 21: Transport Unit

    Remove the jammed paper. Push in the Paper Tray. Transport Unit Confirm that the machine is not operating, and open the Front Cover. Pull out the Paper Tray 1. Pull out the Transport Unit. Note When the Transport Unit is pulled out, the Paper Tray 2 is also pulled out.

  • Page 22: Duplex Automatic Document Feeder

    Paper Trays 5 (Bypass Tray) Remove the jammed paper. When a message appears on the control panel to cut the paper, cut the base of paper without pulling the paper out, and then tap [Confirm]. Remove all the paper from the bypass tray, and then load the paper again.

  • Page 23: Transfer Unit

    Open the Document Cover, pull down the handle to open the Side 2 scanner, and then remove the document. Close the Side 2 scanner, then close the Document Cover. Transfer Unit Note Before pulling out the Transfer Unit, check the screen display for any remaining paper in the left and right ...
  • Page 24 If paper is jammed at the upper section of the Transfer Unit or inlet of the fixing unit, remove the paper to the left side. If the paper cannot be removed, push up and open the handle [2d], and remove the jammed paper. Important Do not touch the six claws you can see when pushing up the handle [2d].

  • Page 25: Main Specifications

    The specifications are not intended to guarantee the image quality performance and feeding performance of all papers. Use of our brand paper is recommended. To use other paper, contact your dealer or nearest SHARP Service Department. Refer For specifications of optional units, refer to the chapter of the concerned unit in “User's Manual - ...
  • Page 26 Item Specification Paper size Trays 1 and 2 Standard size A4, Letter JIS B5 Trays 3 and 4 Standard size SRA3 (320 x 450 mm), 12.6 x 19.2" (320 x 488 mm) Custom Size (mm) 140 x 182 to 330 x 488 Bypass Tray Standard size SRA3 (320 x 450 mm),...

  • Page 27: Copying Function

    Copying Function Item Specification Scan resolution (dpi) 600 x 600 Printing Resolution (dpi) 2,400 x 2,400 Halftone 256 gradation Paper size Standard size A3, 12.6 x 19.2" (320 x 488 mm) Custom Size (mm) 100 x 148 to 330 x 488 First copy output time 3.9 seconds (A4) Scan Function...
  • Page 28 SHARP CORPORATION April 2024 Edition 1 GM1973E9-2...
