70mai A800S Series - Dash Cam Manual

Product Overview

Please read this manual carefully before using the product and keep it in a safe place.

1. Function Buttons
2. Display
3. Speaker
4. Mounting Slot
5. Camera
6. Ventilation Holes
7. Indicator
8. Microphone
9. Power Button
10. Power Port
11. Rear Camera Port
12. Memory Card Slot

Note: Illustrations of the product. accessories, and user interface in the user manual are for reference purposes only. The actual product and functions may vary due to product enhancements.

Installation

1. Installing the electrostatic sticker.
   Clean your windshield and put the electrostatic sticker on the recommended area as shown in the figure below Avoid the edge of the windshield and select the flat and smooth area for the installation.
   Make sure you remove air bubbles between the sticker and the glass.

2. Installing the memory card.
   Insert the memory card into the card slot with its contacts facing up until you hear a click. The memory card is well-installed.

3. Installing the mount.
   Attach the mount into the slot and slide up, as shown in the figure below, You will hear a snap when it is in place Make sure the mount is securely installed to the dash cam.

4. Mounting the dash cam.
   Peel off the protective film from the adhesive sticker on the base of the mount, and paste the dash cam onto the electrostatic sticker in the dotted area.

5. Connecting the power supply.
   As shown in the figure below, run the power cord along the top of the windshield, down the A-pillar, and around the glove compartment, so that the power connector is near the cigarette lighter. Connect the power cord to the car charger, then plug the charger into the cigarette lighter socket.

   Note:
   • Use the Included crowbar to hide the power cord underneath the vehicle's headliner and rubber seal along the A-pillar.
   • Depending on the vehicle, the cigarette lighter socket may be located in a different position The above figure is for reference only.
6. Adjusting the dash cam angle.
   Turn on the dash cam and adjust the camera angle based on the preview screen to ensure that the camera is facing the front of the vehicle.


Accessories

(optional)
The rear recording function of this product needs to be used with the rear cameras Scan the QR code below to obtain the operation guide for rear camera.

Note: To avoide the rear camera malfunction due to device incompatibility, it is recommended to use a rear camera from 70mai brand.

Download 70mai App

This product may be used in conjunction with the 70mai App. Please search for "70mai" in the App Stare or scan the following QR code to download and install the App.

Note: Android 44 & iOS 91) or above is required to connect to the dash camis Wi-Fi hotspot with a mobile phone.

Packing List

1. Dash Cam x 1
2. Mount x 1
3. Power Cord x 1
4. Dual car Chargerx 1
5. Wiring Crowbar x 1
6. Electrostatic Sticker x 2
7. Adhesive Sticker x 2 (with 1 pre-applied to the mount)
8. User Manual x 1

Memory Card Instructions

• A memory card (sold separately) must be installed in the dash cam before use.
• The dash cam supports standard MicroSD cards Please use memory cards with the minimum capacity of 32 GB and rating of U1 (UHS-1) or above.
• The default file partition format of the memory card may be inconsistent with the format supported by the dash cam. When inserting the memory card for the first time, please format it in the dash cam before use. Formatting the memory card will delete all files on the card. Please back up important data to another device beforehand.
• The memory card may become damaged or deteriorated after repeated cycles of overwriting, and this may affect its ability to save video and image files. If this occurs, immediately replace it with a new memory card.
• Please use a high-quality memory card purchased from a reputable vendor Inferior memory cards may have issues such as actual reading/writing speeds that do not match the stated speeds, and an actual storage capacity that does not match the stated storage capacity. We shall not be held liable for lost or damaged videos caused by the use of a low-quality memory card.
• In order to avoid reading and writing speeds decreasing after prolonged use, it is recommended to format the memory card in the dash cam every two weeks.
• Do not insert or remove a memory card while the dash cam is turned on.

Precautions

Before using this dash cam, please read all the precautions and the online guide to ensure correct and safe use.

• This dash cam is intended to assist drivers with the purpose of recording the environment outside the vehicle The dash cam does not guarantee the user's driving safety We shall not be held liable for any accident, damage, or loss of information caused by operating the dash cam while driving.
• Due to differences in vehicle conditions, driving style, driving environment, etc., some functions may not work properly. A power failure, usage in environments outside the normal operating temperature or humidity range, a collision, or a damaged memory card may cause the dash cam to function abnormally. There is no guarantee that this dash carn will function normally under all circumstances. Videos recorded by this dash carn are for reference only.
• Please install this dash cam correctly, and do not block the driver's line of sight, nor block the vehicle's airbag, in order to avoid product failure or personal injury
• Please use the included car charger, power cord, and other accessories in order to avoid product failure due to non-conformance. We shall not be held liable for any loss or damage caused by the use of a non-genuine car charger or power cord
• If the battery becomes deformed, swollen, or starts leaking during use or storage, stop using the dash cam Immediately in order to avoid safety issues, and contact after-sales service
• Please keep this dash cam away from any strong magnetic fields, as they may cause damage to the dash cam.
• Do not use this dash cam in environments with temperatures over 60°C or below -10°C.
• Please only use this dash cam within the scope permitted by law.

Specifications

Product: Dash Cam
Model: A800S
Input: 5V ⎓ 2A
Resolution: 3840 x 2160
Lens: FOV140°/F1.8
Power Supply: Car cigarette lighter socket
Battery Type: Lithium polymer battery
Wireless Connectivity: Wi-Fi IEEE 802.11 b/g/n 2.4 GHZ and 5Ghz
Battery Capacity: 500 mAh

Safety Information

Battery abuse or mishandling can cause overheat, liquid leakage, or an explosion. To avoid possible injury, do the following:

• Do not open, disassemble, or service any battery.
• Do not attempt to replace the internal rechargeable lithium batteries.
• Do not crush or puncture the battery.
• Do not short-circuit the battery, or expose it to water or other liquids.
• Keep the battery away from children.
• Keep the battery away from fire.
• Do not leave the battery in an extremely high-temperature environment or an extremely low air pressure environment.
• Stop using the battery ir it is damaged, or if you notice any discharge or the buildup or foreign materials on the battery leads. We recommend that the batteries be charged about once every three months to prevent overcharge.
• Do not put the battery in trash that is disposed of in landfills. When disposing of the battery, comply with local laws or regulations.

Service: help@70mai.com
For further information, please go to www.70mai.com
Manufacturer: 70mai Co., Ltd.
Address: Room 2220, Building 2, No. 588, Zixing Road, Minhang District, Shanghai, China
