Schwinn Roadster S6740 - Bicycle Manual

Schwinn Roadster Assembly Instructions

Tools needed:
13mm (1/2") wrench, or 10mm crescent (adjustable) wrench, Phillips screwdriver

Parts list:

Main frame
Rear frame assembly - rear frame, standing deck, rear wheels and fenders
Saddle assembly – saddle, carriage bolt, saddle-adjustment knob
Fork assembly – front fork, front wheel, front fender
Handlebar assembly – handlebar, grips, stem clamp

Before beginning assembly, unpack and inspect all parts listed above. If any parts are missing or damaged, DO NOT RETURN TRICYCLE TO DEALER. Please call 1-800-626-2811 for replacement or missing parts.

Attach main frame to rear deck. Assemble by aligning the rear axle against the "C" shaped support at the end of the main frame, then rotate rear deck assembly so that the attachment bolt protrudes through the frame. Secure frame with washer and locknut, and insert the two flanking screws.
Position saddle on frame with carriage bolt protruding through center hole in frame. Tighten knob onto carriage bolt to lock saddle in position. Fore and aft saddle adjustment can be accomplished by removing the saddle adjustment knob and re-tightening the knob and saddle in desired hole.
Insert fork assembly through head tube of frame assembly. Be sure that fork is completely inserted through frame to allow approximately 22mm (7/8") of fork steer tube to show through top of head tube. Push stem clamp onto fork steer tube. Stem clamp must fully seat onto fork steer tube. There should be no space between head tube and stem clamp. Insert handlebar into fork steer. Be sure to insert far enough to cover "Minimum Insertion" mark on handlebar. Align handlebar and front wheel, tighten stem clamp with 13mm (1/2") wrench.
Inspect all wheels to be sure that they turn freely. If any wheel does not turn freely, check that fender is not rubbing on the tire. If it is, flex fender to the opposite side that it is rubbing on, until it is centered (see illustration). While holding front wheel, check that handlebar cannot be turned independently from wheel. Check that saddle carriage bolt and tightening knob are holding saddle securely. If necessary, tighten saddle adjustment knob further.

Schwinn Roadster Parts Diagram

Parts Diagram - Part 1
Parts Diagram - Part 2

A Special Note for Parents

In the interest of safety, make certain that you read and understand all information and instructions included with and pertaining to this product.
This toy is intended for use by small children. As a parent or guardian, you bear the responsibility of ensuring the safety of your child. To make sure this toy is used safely, a responsible adult must supervise any child playing with it. This includes allowing it to be used only where and when it is clearly safe for a small child to do so and making certain that it is in good repair and secure operating condition.

Rules for Children

To avoid accidents, teach children good riding skills with an emphasis on safety from an early age.

Rider should always wear a properly fitted helmet that complies with the US Consumer Product Safety Commission (CPSC) standard 16 CFR 1203.
Continuous adult supervision required.
Allow only one rider.
Excessive weight may cause a hazardous or unstable condition.
Do not play in driveways or the road.
Do not ride on busy streets.
Do not ride at night.
Obey all traffic laws, especially stop signs and red lights.
Be aware of other road vehicles behind and nearby.
Don't ride barefoot - closed shoes better than sandals.
Wear brightly colored clothing.
Never take your hands off the handelbars, or your feet off the pedals when riding downhill.

warning The Consumer Protection Safety Commission advises that the riding of small wheel diameter toys at excessive speeds can lead to instability and is not recommended.
Children should be made aware of all possible riding hazards and correct riding behavior before they take to the streets

Do not leave it up to trial and error.

Personal Care from PACIFICCYCLE
Our Service Department is dedicated to your satisfaction with Pacific Cycle and its products.
For questions regarding performance, assembly, operation, parts or returns, contact the experts at Pacific Cycle directly by calling toll free 1-800-626-2811
8:00am - 5:00pm Central Time
Monday thru Friday
Or by email at
customerservice@pacific-cycle.com
DO NOT RETURN THIS ITEM TO THE STORE. PLEASE CALL PACIFIC CYCLE FOR ASSISTANCE.

4730 East Radio Tower Lane
PO Box 344
Olney, IL 62450
Call Toll Free 1-800-626-2811
Monday -Friday 8:00 a.m. to 5:00 p.m. Central Time Customerservice@pacific-cycle.com
