Operating Guide Termix Compact 28 VMTD-FI
Attach the station to the wall in the holes on the mounting plate.
Assemble the power connector on the hot water part of the station.
For proper functionality, connectors must be paired by colour.
Install the ball valves.
Mount block A (C if it is the Magna pump) on the left-hand side of
the pump. Attach block E to block A/C, and attach it to the pipe
above the pump by clicking it in place.
