Operating Guide Termix Compact 28 VMTD-FI
Mount the station as far to the left on the rail as possible.
Lift the station's instantaneous domestic hot water part.
Mount the instantaneous domestic hot water part on the
right-hand side of the fittings.
Push the two parts together. The two mounting plates must click
together in the overlap.
