- Page 1 User Manual Inverter Split Type Room Air Conditioner HAIR09C HAIR12C HAIR24C HAIR30C Thank you very much for purchasing a air conditioner, please read this User Manual carefully before installing and using this appliance and keep this manual for future reference.
-
Page 2: Table Of Contents
Contents Preparation before use Safety Precautions Identification of parts Indoor unit Outdoor unit Operating and display Remote controller Operation instructions Operation modes Air flow direction control Smart mode Timer mode Sleep mode Super mode Maintenance Protection Troubleshooting Installation instructions Installation diagram of air conditioner Select the installation locations Indoor unit installation Outdoor unit installation... -
Page 3: Preparation Before Use
Preparation before use Before using the air conditioner, be sure to check and preset the following. Remote Controller presetting The remote controller is NOT preset as Cooling Only Air Conditioner or Heat Pump by manufacturer. Each time after the remote controller replaces batteries or is energized, the Cooling indicator Heating indicator will flash alternately on the LCD of the remote controller. -
Page 4: Safety Precautions
Safety precautions Symbols in this Use and Care Manual are interpreted as shown below. Do not do. Be sure to follow this instruction. The feature of the appliance, Grounding is essential. instead of a fault. Warning: Incorrect handling could Pay attention to such a situation. cause a serious hazard, such as death, serious injury, etc. -
Page 5: Identification Of Parts
Identification of parts Indoor unit Air Intake Front Panel Display Panel Emergency Button Air Outlet Vertical Adjustment Louver Horizontal Adjustment Louver Air Filter Remote Controller Air Intake Outdoor unit Pipes and Power Connection Cord Drain Hose Note: Condensate water drains at COOLING or DRY operation. -
Page 6: Operating And Display
Identification of parts UL series operating and display Sleep indicator Temperature display Timer Indicator Lights up when the sleep mode Lights up during the is being set and within 10s after Display set temperature. set time. the sleep mode has been set . Display trouble symbol.. -
Page 7: Remote Controller
Remote controller Remote controller The remote controller transmits signals to the system. ON/OFF BUTTON The appliance will start turn on when energized or will turn off when it is in operation, if you press this button. MODE BUTTON Press this button to select the operation mode. FAN BUTTON Used to select fan speed in sequence auto, high, medium or low. - Page 8 Remote controller Remote controller How to Insert the Batteries Remove the battery cover according to the arrow direction. Insert new batteries making sure that the (+) and (-) of battery are matched correctly. Reattach the cover by sliding it back into position. Note: Use 2 LR03 AAA(1.5volt) batteries.
-
Page 9: Operation Instructions
Operation instructions Operation modes Selecting mode Each time MODE button is pressed, the operation mode is changed in sequence: COOLING FAN ONLY HEATING Heating mode is NOT available for cooling only air conditioner. FAN mode Each time the "FAN" button is pressed, the fan speed is changed in sequence: Auto High... -
Page 10: Airflow Direction Control
Operation instructions Airflow direction control Airflow direction control Vertical airflow is automatically adjusted to a certain angle in accordance with the operation mode after turning on the unit. The direction of airflow can be Operation mode Direction of airflow also adjusted to your own MODE requirement by pressing the horizontal... -
Page 11: Smart Mode
Operation instructions SMART mode Press the SMART button, the unit enters into SMART mode(fuzzy logic operation) directly regardless if the unit is on or off. In this mode, temperature and fan speed are automatically set based on the actual room temperature. Operation mode and temperature are determined by indoor temperature Heat pump models Indoor temperature... -
Page 12: Timer Mode
Operation instructions Timer mode It is convenient to set the timer on with the TIMER ON/OFF buttons when you leave your home and to achieve a comfortable room temperature at the time you get home. You can also set the timer off at night to enjoy a good sleep. -
Page 13: Sleep Mode
Operation instructions SLEEP mode SLEEP mode SLEEP mode can be set in COOLING, HEATING or DRYING operation mode. This function gives you a more comfortable environment for sleep. In SLEEP mode, The appliance will stop operation automatically after operating for 8 hours. Fan speed is automatically set at low speed. -
Page 14: Maintenance
Maintenance Front panel maintenance Air filter maintenance Cut off the power supply Please clean the air filter after using it for about 100 hours. Turn off the appliance first before disconnecting Clean as follows: from the power supply. Switch off the appliance and remove the air filter. -
Page 15: Protection
Protection Noise pollution Operating condition The protective circuitry device may trip and stop Install the air conditioner in a place that the appliance in the cases listed below. can bear its weight to ensure quite operation. Outdoor air temperature is over 24 C Install the outdoor unit in a place where HEATING Outdoor air temperature is below -7 C... -
Page 16: Troubleshooting
Troubleshooting The following cases may not always be a malfunction, please check before asking for service. Trouble Analysis If the protector trip or fuse is blown. Please wait for 3 minutes and start again, Does not run protector device may be preventing unit to work. If batteries in the remote controller exhausted. -
Page 17: Installation Instructions
Installation instructions Installation diagram Distance from ceiling should be over 50 mm Distance from wall should be over 50mm Distance from the wall should be over 50mm Distance from floor should be over 2300mm Air intake distance from the wall should be over 250mm Air intake distance from the wall should be... -
Page 18: Select The Installation Locations
Installation instructions Select the best location Installation of this appliance must be performed by a licensed and qualified installation contractor. Location for Installing Indoor Unit Where there is no obstacle near the air outlet and air can be easily blown to every corner. Indoor unit Where piping and wall hole can be easily arranged. -
Page 19: Indoor Unit Installation
Installation instructions Indoor unit installation 1. Installing the Mounting Plate Decide an installing location for the mounting plate according to the indoor unit location and piping direction. Keep the mounting plate horizontally with a horizontal ruler or dropping line. Drill holes of 32mm in depth on the wall for fixing the plate. Insert the plastic plugs to the hole, fix the mounting plate with tapping screws. - Page 20 Installation instructions Piping Joints Thermal Insulation: Wrap the piping joints with thermal insulation materials and then wrap with a vinyl tape. wrapped with vinyl type Thermal insulation Piping Thermal Insulation: Large pipe a. Place the drain hose under the piping. Thermal insulation tube b.
- Page 21 Installation instructions 4. Connecting of the Cable Front panel Terminal (inside) Indoor Unit Connect the power connecting cord to the indoor unit by connecting the wires to the terminals on the control board individually in accordance with the outdoor unit Cabinet connection.
- Page 22 Installation instructions Wiring Diagram Make sure that the color of wires of the outdoor unit and the terminal No. are the same as those of the indoor unit. 9K,12K Model Indoor unit Outdoor unit Terminal Terminal Power connecting cord Yellow/Green Blue Power supply For 9k,12k models, the power supply are connected from indoor unit, with a plug.
-
Page 23: Outdoor Unit Installation
Installation instructions Outdoor unit installation 1.Install the Drain Port and Drain Hose (for heat-pump model only) The condensation drains from the outdoor unit when the unit operates in heating mode. In order not to disturb your neighbours and protect the environment, install a drain port and a drain hose to direct the condensation water. -
Page 24: Notes
Installation instructions How to Purge Air Tubes: (1). Unscrew and remove caps from 2 and 3-way valves. (2). Unscrew and remove cap from the service valve. (3). Connect the vacuum pump flexible hose to the service valve. (4). Start vacuum pump for 10-15 minutes until reaching a vacuum of 10 mm Hg absolutes. (5). -
Page 26: Hisense Warranty
10. Replacement items are “Like for like” and is not “new for old” and does not indicate in any way that a faulty product will be replaced b. Hisense and/or its Agents will decide if there are any defects in the with a new part or unit. -
Page 27: Warranty Claims Procedure
Please retain this portion for your records 60 MONTHS IN HOME REPAIR WARRANTY Hisense Australia will provide its nearest service centre for repairs under warranty. You will need to ensure that you have already called Hisense Warranty Centre and received a JOB NUMBER.
