Thank you very much for purchasing this Air Conditioner. Please
read this use and installation instructions carefully before installing
and using this appliance and keep this manual for future reference.
Hisense (Guangdong) Air Conditioning Co., Ltd.
No.8 Hisense Road，Advanced Manufacturing
Jiangsha Demonstration Park,Jiangmen City,
Guangdong Province,P.R.China
Advertisement
Table of Contents
Related Manuals for Hisense HPA27C
Summary of Contents for Hisense HPA27C
- Page 1 Thank you very much for purchasing this Air Conditioner. Please read this use and installation instructions carefully before installing and using this appliance and keep this manual for future reference. Hisense (Guangdong) Air Conditioning Co., Ltd. No.8 Hisense Road，Advanced Manufacturing Jiangsha Demonstration Park,Jiangmen City,...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY PRECAUTIONS ..........2 Normal Sounds................25 LOCAL AIR CONDITIONER CARE......... 26 IDENTIFICATION OF PARTS..........10 Draining the Air Conditioner............26 AIR CONDITIONER SAFETY............14 Draining the Air Conditioner( Heating models)...... -
Page 3: Safety Precautions
Safety precautions Precautions for using R290 refrigerant The basic installation work procedures are the same as the conventional refrigerant (R22 or R410A). However, pay attention to the following points: CAUTION 1. Transport of equipment containing flammable refrigerants Compliance with the transport regulations 2. - Page 4 Safety precautions CAUTION 6-5 Presence of fire extinguisher If any hot work is to be conducted on the refrigeration equipment or any associated parts, appropriate fire extinguishing equipment shall be available to hand. Have a dry powder or CO2 fire extinguisher adjacent to the charging area. 6-6 No ignition sources No person carrying out work in relation to a refrigeration system which involves exposing any pipe work that contains or has contained flammable refrigerant...
- Page 5 Safety precautions CAUTION which are inherently resistant to being corroded or are suitably protected against being so corroded. 6-9 Checks to electrical devices Repair and maintenance to electrical components shall include initial safety checks and component inspection procedures. If a fault exists that could compromise safety, then no electrical supply shall be connected to the circuit until it is satisfactorily dealt with.
- Page 6 Safety precautions CAUTION live in the presence of a flammable atmosphere. The test apparatus shall be at the correct rating. Replace components only with parts specified by the manufacturer. Other parts may result in the ignition of refrigerant in the atmosphere from a leak.
- Page 7 Safety precautions CAUTION – Evacuate; – Purge again with inert gas; – Open the circuit by cutting or brazing. The refrigerant charge shall be recovered into the correct recovery cylinders. The system shall be “flushed” with OFN to render the unit safe. This process may need to be repeated several times.
- Page 8 Safety precautions CAUTION c) Before attempting the procedure ensure that: – Mechanical handling equipment is available, if required, for handling refrigerant cylinders; – All personal protective equipment is available and being used correctly; – The recovery process is supervised at all times by a competent person; –...
- Page 9 Safety precautions CAUTION instructions concerning the equipment that is at hand and shall be suitable for the recovery of flammable refrigerants. In addition, a set of calibrated weighing scales shall be available and in good working order. Hoses shall be complete with leak-free disconnect couplings and in good condition.
- Page 10 Safety precautions CAUTION Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certificate from an industry-accredited assessment authority, which authorises their competence to handle refrigerants safely in accordance with an industry recognised assessment specification. Servicing shall only be performed as recommended by the equipment manufacturer.
-
Page 11: Identification Of Parts
Front Cool air outlet Signal receptor Remote control Control panel Evaporator air intake Transport handle Secondary drain port Air outlet hose Condenser air intake Primary drain port Back Power supply (May differ from the one shown) The figures in this manual are based on the external view of a standard model. They may differ from that of the air conditioner you have selected. - Page 12 Front Cool air outlet Signal receptor Remote control Control panel Evaporator air intake Transport handle Secondary drain port Air outlet hose Condenser air intake Primary drain port Back Power supply (May differ from the one shown) The figures in this manual are based on the external view of a standard model. They may differ from that of the air conditioner you have selected.
- Page 13 Front Cool air outlet Signal receptor Remote control Control panel Evaporator air intake Transport handle Secondary drain port Air outlet hose Condenser air intake Primary drain port Back Power supply (May differ from the one shown) The figures in this manual are based on the external view of a standard model. They may differ from that of the air conditioner you have selected.
- Page 14 Front Cool air outlet Signal receptor Remote control Control panel Evaporator air intake Transport handle Secondary drain port Air outlet hose Condenser air intake Primary drain port Back Power supply (May differ from the one shown) The figures in this manual are based on the external view of a standard model. They may differ from that of the air conditioner you have selected.
-
Page 15: Air Conditioner Safety
AIR CONDITIONER SAFETY You safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. -
Page 16: Location Requirements
Location Requirements NOTES: ■ The flexible exhaust hose allows placement of the air Horizontal Slide Window conditioner between 60 cm and 170 cm from window or door. For appliances with supplementary heaters, the minimum clearance from the appliances to combustible surfaces is 100cm. ■... -
Page 17: Install Local Air Conditioner(On The Window)
Install Local Air Conditioner( on the window) Install Exhaust Hose and Adapter 1. Roll the air conditioner to selected location. see “Location Requirements.” 2. Attach the d to the flexible exhaust hose. Turn ummy coupling anticlockwise until securely locked into place. 3. - Page 18 Rain cover--Horizontal Installation NOTE: For casement window installation, the window slider kit may be installed vertically with the window slider kit opening at the bottom. A. Window exhaust adapter D. Bolts inserted into unused holes in Window slider kit B. Rain cover C.
-
Page 19: Complete Installation
Complete Installation 1. Place the window-lock bracket on top of the lower window and against the upper window sash. WARNING 2. Use 1/8” drill bit to drill a starter hole through the hole in the bracket. 3. Attach the window-lock bracket to the window sash with wood screw(provide 4) to secure the window in place. -
Page 20: Local Air Conditioner Use
LOCAL AIR CONDITIONER USE Operating your local air conditioner properly helps you to ■ If a button is pressed during this time, the compressor will obtain the best possible results. not restart fo another 3 to 5 minutes. This section explains proper air conditioner operation. ■... -
Page 21: Starting Your Local Air Conditioner
Starting Your Local Air Conditioner SILENT NOTE:The symbols may be different from these models, but the functions are similar. Dry-Dries the room. The air conditioner automatically selects 1. Select the mode. See " MODE ". the temperature. The fan runs on Low speed only. 2. -
Page 22: Using The Remote Control
SILENT Temperature Press the PLUS button to raise the temperature. Press the PLUS Press SILENT button to start the silent mode. 1°C. button once to increase the set temperature by SILENT PLUS Press the MINUS button to lower the temperature. Press the MINUS When the SILENT light on the control panel lights, the silent 1°C. - Page 23 Button and Function Remote control Remote control may differ in appearance. NOTE: ON/OFF ON/OFF SLEEP SLEEP IFEEL MODE IFEEL MODE CLOCK CLOCK Timer Off TIMER OFF DOWN Timer On TIMER ON SMART SUPER SMART SUPER ON/OFF SWING DIMMER SWING DIMMER Indication symbols MODE SWING...
- Page 24 ■ Dry-Dries the room. The air conditioner automatically SUPER selects the temperature. The fan runs on Low speed only. NOTE: Dry mode should not be used to cool the room. SUPER button is used to start or stop fast cooling or heating. A decrease or rise of up to 2°C can be set with the...
- Page 25 Temperature NOTE: The temperature and airflow direction may be adjusted during Sleep control. The fan speed is automatically set to Press the UP button to raise the temperature. Press ■ Low speed. After 5 seconds, the lights on the control panel the UP button once to increase the set temperature display will dim again.
-
Page 26: Normal Sounds
Clock function 3. When your desired time displayed on LCD, press the TIMER ON button to confirm it. A “Beep” can be heard, “ON” stops flashing. 1. You can or adjust the real time by pressing CLOCK button The TIMER indicator on the appliance lights up. 4. -
Page 27: Local Air Conditioner Care
LOCAL AIR CONDITIONER CARE WARNING: Please connect the drain hose on heating Draining the Air Conditioner mode, or the unit will stop running after the water the water reaches warning level. 1. Uncover the primary drain port. 2. Attach the drain hose to the primary drain hose. Make sure the connector has no water leak. -
Page 28: Troubleshooting
TROUBLESHOOTING Before calling for service, try the suggestions below to see whether you can solve your problem without outside help. Air conditioner seems to run too much Air conditioner will not operate ■ Is there a door or window open? WARNING Keep doors and windows closed. - Page 29 Portable air conditioners are designed as supplemental Air conditioner runs, but does not cool cooling to local areas within a room. The filter is dirty or obstructed by debris. The filter is dirty or obstructed by debris. ■ ■ Clean the filter. Clean the filter.
