H i - C h e c k e r
U s e r M a n u a l
P C S o f t w a r e
Thank you for choosing our company's
commercial air conditioner.To ensure the
correct use of Hi-Checker, please read this
manual and <Hi-Checker User Guide>
carefully before use. Please keep it after
reading. Should you have any question,
please contact the dealer or our company's
service center.
Content
U n i t I n f o r m a t i o n
F i r m w a r e U p d a t e
L o a d M e m o r y C a r d
1
1
2
4
20
22
24
25
27
29

Advertisement

loading
Need help?

Need help?

Do you have a question about the Hi-Checker and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hisense Hi-Checker

  • Page 1: Table Of Contents

    P C S o f t w a r e Thank you for choosing our company's commercial air conditioner.To ensure the correct use of Hi-Checker, please read this manual and <Hi-Checker User Guide> carefully before use. Please keep it after P r e f a c e reading.
  • Page 2: P R E F A C E

    P r e f a c e This product is a general-purpose control product. Product features require air When using medical device and other devices conditioning system support, Connecting that produce electromagnetic waves, the with some certain types of air conditioners transmitting surface of electromagentic wave may void part of the functions indicated in shall not face this product directly to avoid...
  • Page 3: P R E S E T

    I n o p e r a t i o n Waterproof measures should be taken when using Hi-Checker device. Please pay attention to check the dial code before use, and refer to the <Hi-Checker User Guide>. Warning When an abnormality (burnt smell, etc.) occurs, immediately stop the operation and cut off the main power supply.
  • Page 4 If the Grab Communication function is not needed, there is no need to activate Attention the PC software. If the computer cannot recognize the port number of the device, Please search the description file named CDC_Demo.inf in Software installation directory "*** \Hi-Checker\Data",update the device port driver to the description file will do.
  • Page 5: D A T A C O L L E C T I O N

    D a t a C o l l e c t i o n 1 Preparation for data collection First connect the Hi-Checker device and PC via USB, Connect Hi-Checker device and air conditioner through communication line. Wiring is shown in Figure 2. Open...
  • Page 6 D a t a C o l l e c t i o n Enter the data collection setting interface. On this page, user can set the file name, save path, and whether to use the control function. After setting, click the "Sure"...
  • Page 7 1:Display air conditioner search status; 2:Display air conditioner search progress ; In the initialization page of Fig5,Hi-Checker will continue to search for air conditioners. Depending on the number of air-conditioning connections, searching will last for 4-20 minutes. During this period the number or the fixed parameters of air conditioners need to be adjusted, the "Interrupt Initialization"...
  • Page 8 D a t a C o l l e c t i o n Fig7 Schematic Diagram for System Number Selection of Data Collection Please select at least 1 system for data collection, after checking the target system number, click the "Sure" button to enter the next page. Here user can use the "Select All Systems"...
  • Page 9 D a t a C o l l e c t i o n 1:Display the current data storage directory; 2:Set the data storage interval. The shorter the interval, the higher the sampling frequency and the larger the data storage; 3:Set the hard disk storage threshold.
  • Page 10 After the "connection status display" button is clicked, all air-conditioning connection status information searched by the Hi-Checker device will pop up, which is convenient for users to view the system and address numbers of all online indoor and outdoor units.
  • Page 11 D a t a C o l l e c t i o n 2 Data recording function Fig11 Schematic Diagram of the Connection Status Fig12 Schematic diagram of Display settings page...
  • Page 12 D a t a C o l l e c t i o n 3 Data list function Fig13 Data Collection -Schematic diagram of data List Under this function, you can view the current latest operating parameters of all indoor and outdoor units in a system longitudinally, which is convenient for users to compare unit data horizontally.
  • Page 13 3 Data list function Under this function, the water module is an independent type of air conditioning equipment, and its parameters can be displayed separately. At present the types of water modules supported by Hi-Checker are: (1)Split water module; �...
  • Page 14 D a t a C o l l e c t i o n 4 Data Chart Function Under this function, you can view the operating parameter curve of one air conditioner. It is convenient for the user to view the change of the unit parameters.
  • Page 15 D a t a C o l l e c t i o n 4 Data Chart Function 1: Switch setting of Data Curve Display; 2: Color setting of Data curve; Fig17 Schematic Diagram of Curve Display Page In this display page, the displayed parameter curves are all from the parameters checked as "ON"...
  • Page 16 D a t a C o l l e c t i o n 5 Operation Control Function Under this function, the user must check "Use control function" in the initialization interface to enter the operation control page ,three types of controlled objects: outdoor units, indoor units, and water modules.
  • Page 17 D a t a C o l l e c t i o n 5 Operation Control Function Fig19 Operation control -Schematic Diagram of Indoor Unit Fig20 Operation control -Schematic Diagram of Water Module This operation control page will only be displayed when the water module is connected in the Attention system ,and the controlled items of different types of water modules are not completely the same.
  • Page 18 (5)Indoor unit ability attribute selection. (6)Click the "Sure" button, and the cycle diagram will be automatically generated according to the configuration. (7)Click "Auto Update" and the parameters in the data table on the right will change dynamically according to the Hi-Checker device's report.
  • Page 19 D a t a C o l l e c t i o n 6 System Cycle Diagram Function Fig22 Schematic diagram of the system cycle diagram display page (1)Press and hold the middle mouse button to move the whole picture. shortcut (2)Click on the blank space of the cycle diagram and swipe up to enlarge the overall picture.
  • Page 20 D a t a C o l l e c t i o n 7 Change data system function Under this function, user can switch the air conditioning system that is being collected according to the actual usage . After switching, the sub-functions under data collection are displayed according to the number of systems after switching.
  • Page 21: F I L E L O A D I N G

    F i l e L o a d i n g 1 File loading preparation Under this function, you can view and analyze in different ways by loading historical data. You need to prepare a previously collected data file package. By loading the file, you can view it in the form of data records, data lists, data charts, and system cycle diagrams.
  • Page 22 F i l e L o a d i n g 2 Create data report This function is a report generated based on loading historical data. The user needs to fill in project information, unit information, project opinions, and check the parameters that user wants to print.
  • Page 23: C S V C O N V E R S I O N

    C S V C o n v e r s i o n This function can convert the data stored in the PC software into a common CSV format, allowing users to open the data file with software that supports this format. Fig28 Schematic diagram of CSV conversion function page 1:Select the file to be converted;...
  • Page 24 C S V C o n v e r s i o n 1: Display the number of systems that need to be converted; 2: Select the storage directory of the converted file. If not , it will be stored in the working directory by default;...
  • Page 25 L i s t The purpose of this function is to view the list of models supported by the current Hi-Checker software. This function will be upgraded with Hi-Checker software to support more models. Fig31 Schematic diagram of model list page...
  • Page 26 The purpose of this function is to upgrade the firmware version of the Hi- Checker device through the PC software. The prerequisite is that the PC software needs to establish normal communication with the Hi-Checker device. The specific operation steps are shown in the figure below.
  • Page 27 According to the prompts in the software, after the PC software has issued the upgrade package, the successful upgrade of the Hi-Checker device will be prompted in the form of a marquee. The duration is about 30s. In the end, it will automatically reset and execute the new program.
  • Page 28 This function requires the files collected by the Hi-Checker device in the black box mode, please refer to the specific entry method of this mode <Hi-Checker User Guide>. The data of the memory card needs to be copied to the local computer and read by the PC software.
  • Page 29 Before using this function, Hi-Checker should connect with PC Attention software and build communication first. Synchronize the local real- time time of Hi-Checker through the PC computer. Then adjust the Hi-Checker's DSW to enter the black box mode to collect data.
  • Page 30: C O D E I N F O R M A T I O N

    This function is to facilitate the user to view the detailed meaning of fault codes during the entire use of Hi-Checker. According to the function definition of the code, it is divided into four categories, and retrieval is performed on demand.
  • Page 31 Qingdao Hisense Hitachi Air-conditioning Systems Co.,Ltd. The Company is committeed to continuous product improvement. We reserve T00389Q 09. 2022 V01 the right, therefore, to alter the product information at any time and without prior announcement.
