- Page 1 KFR 2601GW/BPE KFR 2601GW/BPE KFR 2801GW/BPE KFR 2801GW/BPE SPLIT TYPE AIR CONDITIONER SPLIT TYPE AIR CONDITIONER INSTRUCTION MANUAL INSTRUCTION Hisense Corporation MANUAL...
-
Page 2: Features
This air conditioner provides with cooling, heating, and drying functions. Details of the functions are below; refer to these descriptions when using the air conditioner. Compact Size This model is smaller than its predecessors and yet offers the same capabilities. -
Page 3: Table Of Contents
Contents Pardon not to inform you if the contents of the manual changes. Alert symbol Caution statements Composition of the air conditioner Operation guide Care and cleaning Tips for energy saving Troubleshooting Schematic diagram Alert Symbols The symbol refers to a hazard or an unsafe practice which can result in WARNING severe personal injury or death. -
Page 4: Caution Statements
4.Consider the capacity of the electric current of your electrical kilowatt- hour meter wires and socket before installation. 1.Read this manual carefully before using this air conditioner. If you still have any diffculties or problems, consult your dealer for help. -
Page 5: Composition Of The Air Conditioner
OUTDOOR UNIT This air conditioner consists of an indoor unit and an outdoor unit. You can control the air conditioner with the remote control unit. Air from the room is drawn into this section and passes Air Intake through air filters which remove dust. - Page 6 (transmitter) receiver This lamp lights when the air conditioner is in the operation mode.(But the compressor may not run at this time.) This lamp lights when the system is being controlled by the timer. This lamp lights when the outdoor unit is electrified.
-
Page 7: Introduction Of Display
3.Introduction of Display Simultaneous use energy saving Displayed when one-hour OFF timer is enable Displayed when setting timer (1) Operation mode AUTO COOL HEAT MILD DRY (2) Fan speed Automatic operation HIGH MEDIUM (3) Set temperature 16-30¡æ When set to 28¡æ Current temperature indication SET TEMP... -
Page 8: Introduction Of Remote Control Unit
When you press the buttons on the remote control unit,the the display to transmit the setting changes to the receiver in the air conditioner. A temperature sensor inside the remote control unit senses the room temperature. - Page 9 TIMER OFF button TIMER SET/CANCEL button This button is used to set/cancel the time at which you wish the air conditioner to go on or off. MODE selector button Use this button to select AUTO, HEAT, DRY, COOLING or FAN mode.
-
Page 10: Operation Guide
Air conditioner (indoor unit) Remote control unit To ensure that the air conditioner operates correctly, DO NOT install the remote control unit in the following places: In direct sunlight. Behind a curtain or other places where it is covered; More than 8 meters away from the air conditioner;... - Page 11 Press the FLAP button and set the airflow desired as desired. STEP 5 To stop the air conditioner, press the ON/OFF operation button again. AUTO AUTO TEMP...
-
Page 12: Adjusting The Fan Speed
Simply set the FAN SPEED selector to the A microcomputer in the air conditioner will automatically control the fan speed when the co nditioner starts operating, the difference between the room temperature (RT) and the set temperature (T) is detected by the microcomputer which then automatically switches the fan speed to the most suitable level. -
Page 13: Adjusting The Airflow Direction
Adjusting the Airflow Direction 1. Horizontal CAUTION 2. Vertical A.Sweep function The flap starts moving up and down to deliver air over the sweep range. ¡ñThe flap automatically closes when the unit is off. NOTE ¡ñ Use the FLAP button on the remote control to adjust the position of the flap. CAUTION If you move the flap by hand, the flap position according to the remote control and the actual flap position may no longer match.If this happens,shut off the... - Page 14 This function loses is automation or airflow mode. B.In Cooling and DRY Mode: When the night setback mode is sescted, the air conditioner automatically raises the temperature, setting 1¡æ when 60 minutes have passed, and at last stops operating automatically after lasting about 6 hours at this temperature, regardless of the indoor temperature when night setback was selected.
- Page 15 BATTERY A/C SENSOR After the length of timer set for TIMER ON elapses, the unit begins operating. The display depicted at left lindicates that the air conditioner will begin operating in three hours. Setting Procedures: Press the MODE button and set the desired operation mode and STEP 1 press the ON/OFF operation button.
-
Page 16: High Power Operation
Using the 1-Hour OFF Timer 1HOUR 1HOUR AUTO AUTO TEMP ON/OFF HIGH POWER FLAP MODE SPEED SOFT SLEEP BATTERY A/C SENSOR HIGH POWER Operation 1HOUR 1HOUR AUTO AUTO TEMP ON/OFF HIGH POWER FLAP MODE SPEED SOFT SLEEP BATTERY A/C SENSOR This function causes the system to operate for one hour and then stop, regardless of whether the unit is on or off when this button is pressed. -
Page 17: Special Remarks
Remote Control Unit ¡ñ Because this air conditioner heats a room by drawing on the heat of the outside air (Heat pump system), the heating efficiency will fall off when the outdoor temperature is very low. If sufficient heat cannot be obtained with this air conditioner, use another heating appliance in conjunction with it. -
Page 18: Care And Cleaning
If you have lost the remote control unit or it has trouble, follow the steps below. 1.When the air conditioner is not running If you want to turn on the air conditioner, switch the operation selector to the OFF position, and then to the ON position. - Page 19 Anti-Mold Filter How to remove the anti-mold filter Anti-Mold Filter Cleaning How to replace the anti-mold filter Air Clean Filter (not provided) WARNING How to install the air clean filter Care and Cleaning (continued) The anti-mode filter behind the air intake grille should be cheched and cleaned at least once every three weeks.
-
Page 20: Tips For Energy Saving
Do not Troubleshooting If your air conditioner does not work properly, first check the following points before requesting service. If it still does not work properly, contact your dealer or service center. Trouble Air conditioner does not run at all. -
Page 21: Schematic Diagram
Schematic Diagram 1. The air conditioner is operable within the temperature ranges from-7 c~43 c. 2. Main specifications of the product type Rated voltage Frequency voltage range power consumptionof input(cooling/heating) power (cooling/heating) Air flow (high) Refrigeration dose/consumption Weight (indoor unit/outdoor unit) -
Page 22: Electric Wiring Diagrams
4. ELECTRIC WIRING DIAGRAMS INDOOR UNIT TRANSFORMER OUTDOOR UNIT TO INDOOR 1 2 3 4 ACOUT1 ACIN1 E SI ACIN2 CONTROL BOARD (WHT) (BLK) COIL PLUG YLW/GRN SENSOR SENSOR COIL ROOM CONTROL BOARD PULSE IN BRN BLK YLW WHT BLK RED SWITCH ASSY MOTOR RECTIFIER...
