Summary of Contents for Hisense KFR-3208GW
- Page 1 KFR-3208GW/AE KFR-3208GW/AE SPLIT TYPE AIR CONDITIONER SPLIT TYPE AIR CONDITIONER INSTRUCTION INSTRUCTION INSTALLATION INSTALLATION Hisense Corporation MANUAL MANUAL...
-
Page 2: Features
This air conditioner provides with cooling, heating, and drying functions. Details of the functions are below; refer to these descriptions when using the air conditioner. Compact Size This model is smaller than its predecessors and yet offers the same capabilities. -
Page 3: Table Of Contents
! The plug must be easily accessible after installation. ! The waste battery shall be disposed properly. ! The breaker of the air conditioner should be all-pole switch;and the distance between its two contacts should be no less than 3mm. Such means for disconnection must be incorporation in the fixed wiring. -
Page 4: Warning
6.There must be at least one ventilation intake in the area where the heat-pump is mounted. 1.Read this manual carefully before using this air conditioner. If you still have 2.The air conditioner is designed to give you comfortable room conditions. -
Page 5: Composition Of The Air Conditioner
1.Diagram of Structure Refrigerant tubes The appearance of the appliance may differ from some pictures. This air conditioner consists of an indoor unit and an outdoor unit. You can NOTE control the air conditioner with the remote control unit. Remote Control Unit... - Page 6 This lamp lights when the air conditioner run efficiently. This button is set for emergent state.Please use the remote control unit to operate the air conditioner in the common state. If you have lost the remote control unit or it has trouble, use this button to turn on/off you air conditioner.(See operation without the remote control...
-
Page 7: Introduction Of Display
3.Introduction of Display Displayed when one-hour OFF timer is enable Displayed when setting timer (1) Operation mode AUTO COOL HEAT MILD DRY (2) Fan speed Automatic operation HIGH MEDIUM T E M P S E T T E M P S E T 1HOUR HOUR Symbols... -
Page 8: Introduction Of Remote Control Unit
When you press the buttons on the remote control unit,the the display to transmit the setting changes to the receiver in the air conditioner. A temperature sensor inside the remote control unit senses the room temperature. - Page 9 TIMER ON button TIMER OFF button TIMER SET/CANCEL button This button is used to set/cancel the time at which you wish the air conditioner to go on or off. MODE selector button Use this button to select AUTO, HEATING, DRY...
-
Page 10: Operation Guide
Air conditioner (Indoor unit) Remote control unit To ensure that the air conditioner operates correctly, DO NOT install the remote control unit in the following places: In direct sunlight Behind a curtain or other places where it is covered More than 8 meters away from the air conditioner... - Page 11 Press the FLAP button and set the airflow direction as desired. STEP 5 To stop the air conditioner, press the ON/OFF operation button again. 1 HR TEMP...
-
Page 12: Adjusting The Fan Speed
A. Automatic Simply set the FAN SPEED selector to the A microprocessor in the air conditioner automatically controls the fan speed when the co nditioner starts operating, the difference between the room temperature and the set temperature is detected by the microprocessor which then automatically switches the fan speed to the most suitable level. -
Page 13: High Power Operation
Night Setback / Simultaneous Use Energy Saving T E M P S E T T E M P S E T 1 HR TEMP SPEED FLAP MODE SLEEP CANCEL A/C SENSOR HIGH POWER Operation 1 HR TEMP SPEED FLAP MODE SLEEP CANCEL A/C SENSOR... - Page 14 STEP 2 A/C SENSOR After the length of time set for TIMER ON elapses, the unit begins operating. The display depicted at left indicates that the air conditioner will begin operating in three hours. Setting Procedures: Press the MODE button and set the desired operation mode and STEP 1 press the ON/OFF operation button.
-
Page 15: Using The 1-Hour Off Timer
Using the 1-Hour OFF Timer 1HOUR 1 Ð ¡ Ê ± 1 HR TEMP SPEED FLAP MODE SLEEP CANCEL A/C SENSOR This function causes the unit to operate for one hour and then stop, regardless of whether the unit is on or off when this button is pressed. indicator in the display indicates that this function is operating. -
Page 16: Special Remarks
Because this air conditioner heats a room by drawing on the heat of the outside air (heat pump system), the heating efficiency will fall off when the outdoor temperature is very low. If sufficient heat cannot be obtained with this air conditioner, use another heating appliance in conjunction with it. -
Page 17: Care And Cleaning
If you have lost the remote control unit or it has trouble, follow the steps below. 1.When the air conditioner is not running If you want to turn on the air conditioner, pressing the ON/OFF button once. 2.When the air conditioner is running If you want to turn off the air conditioner, pressing the ON/OFF button once. - Page 18 Anti-Mold Filter How to remove the anti-mold filter Anti-Mold Filter Cleaning How to replace the anti-mold filter Air Clean Filter (not provided) WARNING How to install the air clean filter Care and Cleaning (continued) The anti-mode filter behind the air intake grille should be checked and cleaned at least once every three weeks.
-
Page 19: Tips For Energy Saving
Tips for Energy Saving Do not Troubleshooting If your air conditioner does not work properly, first check the following points before requesting service. If it still does not work properly, contact your dealer or service center. Trouble Air conditioner does not run at all. -
Page 20: Schematic Diagram
Schematic Diagram 1. Refrigerant Flow Diagram Indoor unit 2. Permitted ambient temperature for the air conditioner is following:-7 ~+43 . 3. Electric Wiring Diagram Outdoor unit Wide tube Wide service valve 4-way valve Narrow service tube Narrow tube INDOOR OUTDOOR... -
Page 21: Appendix: Installation
Appendix: Installation Warning: Carrying out operations displaying this symbol may result in fatal injury. Caution: Carrying out operations displaying this symbol may result in serious injury. This operation manual has explicit information for installation and maintenance in most conditions. Contact the local distributor or after-sales service for further information. - Page 22 Appendix: Installation 2. Location 2-1 Indoor unit WARNING: Maintain the required space around the appliance to prevent overheat. The area for installation of the appliance should not be in an area with the following: Di rect sunlight H eat resource Inflammable gas Thick oil fog The appliance should be installed in an area,...
-
Page 23: Installation Of The Indoor Unit
Appendix: Installation 3. Installation of the indoor unit Remove the wall plate (1)Remove the fixing screws and keep them for future use (not used during installation). (2)Press the two triangular signs on the outer shell and remove the fixing clip. (3)Remove the wall plate. -
Page 24: Installation Of The Outdoor Unit
Appendix: Installation (3)Any part of the drainpipe should be below the outlet of the indoor unit and the joints should be wrapped with waterproof adhesive tape to prevent leakage of condensed water. (4)Bind the tubes, wires and the drainpipe tightly with binding tape, with the drainpipe under the wires. - Page 25 (12)Test run the air conditioner. (13)While the air conditioner is running, apply liquid soap to check for any gas leaks around the service valves or caps. (14)If there is no leakage, stop the air conditioner.
-
Page 26: Packing List
PACKING LIST DRAINAGE ELBOW * REMOTE CONTROL UNIT THE SYMBOL "*" STANDS FOR THE PART TO BE PICKED AND MADE PURCHASE. NAME OUTDOOR UNIT POWER CABLE AIR FRESH FILTER INDOOR UNIT MANUAL BATTERY NAIL SPECIAL AMOUNT...
