1080p Outdoor Wi-Fi Camera with Two-Way Audio (ADC-V724/724X) -

Installation Guide

English

Pre-installation checklist

To watch a video about the pre-installation process, see

• ADC-V724/724X camera (included)

• AC power adapter (included)

• Wi-Fi (2.4 or 5 GHz) connection to broadband Internet (Cable, DSL, or Fiber Optic) Internet. For information about

bandwidth requirements, see

devices?

• A computer, tablet, or smartphone with Wi-Fi is required if the router does not have the Wi-Fi Protected Setup

(WPS) feature

There are two options for connecting the ADC-V724/724X to the Wi-Fi network: Access Point (AP) mode or Wi-Fi

Protected Setup (WPS) mode. Use WPS mode if you have easy access to the customer's router and the router has the

WPS feature enabled.

Note: Some Internet Service Providers disable the WPS feature on customer routers. AP mode is the most reliable

method for installing this device.

https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/1080p_Outdoor_Wi-Fi_Camera_with_Tw...

ADC-V724/724X Pre-Installation

What are the internet service and bandwidth requirements for Alarm.com video

Steps.

Updated: Tue, 09 Jul 2024 14:43:59 GMT

Table of Contents

Need help?

Do you have a question about the ADC-V724 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alarm.Com ADC-V724

Page 1 (WPS) feature There are two options for connecting the ADC-V724/724X to the Wi-Fi network: Access Point (AP) mode or Wi-Fi Protected Setup (WPS) mode. Use WPS mode if you have easy access to the customer’s router and the router has the WPS feature enabled.
Page 2 In the box ADC-V724/724X camera https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/1080p_Outdoor_Wi-Fi_Camera_with_Tw… Updated: Tue, 09 Jul 2024 14:43:59 GMT...
Page 3 Power adapter https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/1080p_Outdoor_Wi-Fi_Camera_with_Tw… Updated: Tue, 09 Jul 2024 14:43:59 GMT...
Page 4 Installation guide https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/1080p_Outdoor_Wi-Fi_Camera_with_Tw… Updated: Tue, 09 Jul 2024 14:43:59 GMT...
Page 5 Wall anchors & screws (3) Overview 1. Status LED 2. SD card door 3. SD card slot 4. Speaker 5. Microphone 6. WPS/Reset button https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/1080p_Outdoor_Wi-Fi_Camera_with_Tw… Updated: Tue, 09 Jul 2024 14:43:59 GMT...
Page 6: Rubber Plug
Rubber plug A rubber plug has been included with your ADC-V724/ 724X at the base of the mount. This rubber plug should only be used if you are mounting it directly over a hole in the wall. The rubber plug will provide a seal to prevent water from entering the hole in the wall behind the camera.
Page 7: Installation
3. On an Internet-enabled device, connect to the Wi-Fi network ADC-V724/724X (XX:XX:XX) where XX:XX:XX is the last six characters of the ADC-V724/724X’s MAC address, which is located on the camera or on the packaging. 4. On the same device, open a web browser and enter http://v724install or 192.168.1.1 in the URL field. Follow the on-screen instructions to add the ADC-V724/724X to the Wi-Fi network.
Page 8 4. Add the device to the account by either selecting the account in the MobileTech app or by using a web browser and entering the following web address: www.alarm.com/addcamera (you will need the customer user name and password).
Page 9 Camera mounting overview https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/1080p_Outdoor_Wi-Fi_Camera_with_Tw… Updated: Tue, 09 Jul 2024 14:43:59 GMT...
Page 10 To mount the ADC-V724/724x when routing the power cable through the wall 1. The camera should be mounted 8 feet or more above the ground, on a flat surface (e.g., a wall or ceiling). Install the rubber plug. 2. Verify that there are no obstructions near the camera. Obstructions can lead to poor night vision performance.
Page 11 (#10 drywall screws or 3/16" Tapcon screws are also acceptable). 6. (Optional) Install the ADC-VACC-724-BC base cover (sold separately). For more information about installing the base cover for the ADC-V724/724x, see How does the ADC-V724/724X Base Cover work?.
Page 12 To mount the ADC-V724/724x when routing the power cable along the wall 1. The camera should be mounted 8 feet or more above the ground, on a flat surface (e.g., a wall or ceiling). Remove the rubber plug. 2. Verify that there are no obstructions near the camera. Obstructions can lead to poor night vision performance.
Page 13 (#10 drywall screws or 3/16" Tapcon screws are also acceptable). Route the cable through the cut-out in the mounting plate 6. (Optional) Install the ADC-VACC-724-BC base cover (sold separately). For more information about installing the base cover for the ADC-V724/724x, see How does the ADC-V724/724X Base Cover work?.
Page 14: Troubleshooting
(about 15 seconds), then release the button. The camera will reboot to factory default. If the camera was previously installed on a different Alarm.com account, it will need to be deleted before it can be installed again.
