1080p Mini-Bullet Camera (ADC-VC727P) - Installation Guide
English
Pre-installation checklist
• ADC-VC727P
• AC power adapter (required for non-PoE connections) (sold separately)
• Router with broadband Internet connection
• (Cable, DSL, or Fiber Optic) and an open Ethernet port
• A computer or mobile device with Internet access
• An Ethernet / Cat5e cable
• Username and password for the Alarm.com account to which the camera is added
Overview
1. LED indicator
2. Camera label with MAC address
3. MicroSD card slot
4. Reset button
5. Ball joint mount
https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/1080p_Mini-Bullet_Camera_(ADC-VC72...
Updated: Sat, 18 May 2024 05:55:48 GMT
1
Advertisement
Related Manuals for Alarm.Com ADC-VC727P
Summary of Contents for Alarm.Com ADC-VC727P
- Page 1 • (Cable, DSL, or Fiber Optic) and an open Ethernet port • A computer or mobile device with Internet access • An Ethernet / Cat5e cable • Username and password for the Alarm.com account to which the camera is added Overview 1. LED indicator 2.
- Page 2 6. 12 VDC power connector 7. RJ45 ethernet interface LED reference Description Power off Solid green Connected to Alarm.com Local network connection Blinking green https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/1080p_Mini-Bullet_Camera_(ADC-VC72… Updated: Sat, 18 May 2024 05:55:48 GMT...
- Page 3 Power on, camera booting Solid red No local or Internet connection Installation Service provider technician - MobileTech installation 1. Log in to the Partner MobileTech app. 2. Select the customer account. 3. Tap https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/1080p_Mini-Bullet_Camera_(ADC-VC72… Updated: Sat, 18 May 2024 05:55:48 GMT...
- Page 4 4. Add the device to the account by either selecting the account using the Partner MobileTech app or by using a web browser and entering the following URL: www.alarm.com/addcamera (you will need the customer username and password).
- Page 5 MAC address is located on the bottom of the device or on the packaging. 6. Follow the on-screen instructions to finish adding the camera. You can now power down the camera. Weather resistant RJ45 cap assembly Camera mounting overview https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/1080p_Mini-Bullet_Camera_(ADC-VC72… Updated: Sat, 18 May 2024 05:55:48 GMT...
- Page 6 Green and Red (about 15 seconds), then release the button. The camera will reboot with factory defaults. • If the camera was previously installed to another Alarm.com account, it will need to be deleted before it can be installed again.
- Page 7 • Un cable Ethernet o Cat5e • Nombre de usuario y contraseña de la cuenta de Alarm.com a la que agregará la cámara Descripción general 1. Indicador LED 2. Etiqueta de la cámara con la dirección MAC 3. Ranura para tarjeta MicroSD 4.
- Page 8 Referencia de LED Description Sin iluminar Apagada Verde continuo Conectada a Alarm.com Verde intermitente Conexión de red local https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/1080p_Mini-Bullet_Camera_(ADC-VC72… Updated: Sat, 18 May 2024 05:55:48 GMT...
- Page 9 (vendido por separado) y enchufe el adaptador en una toma de corriente no conmutada. 3. Espere 2 minutos para que la cámara se inicie y conéctese a Internet. El LED iluminará en verde continuo cuando se complete el proceso. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/1080p_Mini-Bullet_Camera_(ADC-VC72… Updated: Sat, 18 May 2024 05:55:48 GMT...
- Page 10 4. Agregue el dispositivo a la cuenta seleccionando la cuenta en MobileTech o utilizando un navegador web e ingresando la siguiente URL: www.alarm.com/addcamera (necesitará el nombre de usuario del cliente y la contraseña). 5. Seleccione la cámara de la lista de dispositivos de video o ingrese su dirección MAC para comenzar a agregar la cámara.
- Page 11 Artículo 250 del Código eléctrico nacional (NEC, por sus siglas en inglés). Si es necesario retirar la cámara en el futuro, asegúrese de https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/1080p_Mini-Bullet_Camera_(ADC-VC72… Updated: Sat, 18 May 2024 05:55:48 GMT...
- Page 12 LED ilumine en verde y rojo de forma intermitente (alrededor de 15 segundos), luego suelte el botón. La cámara se reiniciará con los valores predeterminados de fábrica. Si la cámara se instaló previamente en una cuenta de Alarm.com, será necesario eliminarla antes de poder volver a instalarla.
- Page 13 2. Etiqueta com o endereço MAC câmera 3. Entrada para cartão microSD 4. Botão Reset 5. Suporte esférico articulável 6. Conector de alimentação de 12 VCC 7. Interface Ethernet RJ45 Legenda do LED Description Apagado Dispositivo desligado https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/1080p_Mini-Bullet_Camera_(ADC-VC72… Updated: Sat, 18 May 2024 05:55:48 GMT...
- Page 14 Description Permanece aceso em verde Conexão à Alarm.com Pisca em verde Conexão à rede local Pisca alternando verde e vermelho Restauração dos padrões de fábrica Pisca em vermelho Dispositivo ligado; inicialização da câmera Permanece aceso em vermelho Sem conexão à rede local nem à internet Instalação...
- Page 15 3. Aguarde 2 minutos para que a câmera inicialize e se conecte à internet. O LED permanecerá aceso em verde quando o processo estiver concluído. 4. Selecione a conta no MobileTech ou use o navegador para acessar www.alarm.com/addcamera e adicionar o dispositivo à conta. Você precisará informar o nome de usuário e a senha.
- Page 16 Artículo 250 del Código eléctrico nacional (NEC, por sus siglas en inglés). Si es necesario retirar la cámara en el futuro, asegúrese de https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/1080p_Mini-Bullet_Camera_(ADC-VC72… Updated: Sat, 18 May 2024 05:55:48 GMT...
- Page 17 LED ilumine en verde y rojo de forma intermitente (alrededor de 15 segundos), luego suelte el botón. La cámara se reiniciará con los valores predeterminados de fábrica. Si la cámara se instaló previamente en una cuenta de Alarm.com, será necesario eliminarla antes de poder volver a instalarla.
