Alphanumeric Pager
AT-100 User Manual
•
Do not operate this device in a hazardous atmosphere.
•
Do not replace or change accessories in a hazardous atmosphere. Contact sparking may occur while installing or removing accessories and cause an explosion or fire.
•
Turn a device off before removing or installing a ba�ery or accessory.
•
Do not disassemble this device in any way that exposed the internal electrical circuits of the unit.
•
Make sure to read this manual before using the machine. Please keep it in hand for future reference.
Overview & Basic Operation
1
2
3
5
6
Icon
Pager Status Symbols
OUT OF RANGE INDICATOR
ENABLE AUTO SLEEP MODE
UNDER AUTO SLEEP MODE
ALARM
SET SCROLL
BEEP
VIBRATION
BEEP & VIBRATION
FLASH ONLY
VOLUME
BATTERY CAPACITY
Operation
READ MESSAGE
1. A flashing
unread message/mail drop.
2. Move joys�ck le�/right/up/down to preview the
message/mail drop.
3. Press
message. Press
• If you have set "SET SCROLL" in the menu, the
message will be scrolled automa�cally.
LOCK MESSAGE / DELETE MESSAGE /
MOVE MESSAGE TO MEMO
1. Use joys�ck to move the cursor to a message.
2. Press
3. Press joys�ck, then select
4. Press joys�ck again to confirm.
7
4
8
Func�on Menu Symbols
SET ALERT
SET ALARM
AUTO SLEEP SET
SET TIME
VOLUME
SET SCROLL
ZOOM IN/OUT
PAGER OFF
CAPCODE SET
TECHNICAL
INFORMATION
/
symbol indicates there is an
to read the en�re content of the
again to view the next page.
to read the message.
(LOCK MESSAGE) /
(DELETE) /
(MOVE MESSAGE TO MEMO).
Charging indicator
1
Message Received Indicator
2
LCD
3
9
• The priority message preprogrammed
in the software is displayed with a red
backlight.
Return Bu�on
4
5
Naviga�on Joys�ck
Message Status Symbols
LOCKED MESSAGE
UNREAD MESSAGE
READ MESSAGE
FULL MESSAGE FOLDER
MEMO FOLDER
MAILDROP FOLDER
MAILDROP FOLDER (ALERT ON)
DUPLICATE MESSAGE
762-00101-0
Power on Bu�on
6
• Read message
• Turn on backlight
(hold botton for a second)
Ba�ery Switch
7
Charging Contact
8
(for op�onal charger)
USB Port Type C
9
• Charging & Programming
MEMO MESSAGE INDICATOR
FULL MESSAGE INDICATOR
MAILDROP MESSAGE INDICATOR
DUPLICATE MESSAGE INDICATOR
ERROR MESSAGE INDICATOR
READ ALL MESSAGE
1. Use joys�ck to move the cursor to the
2. Press
to read the message.
3. The
symbol in the top-le� corner of the
message indicates the message has been put into
the full message folder.
DELEAT ALL MESSAGE
1. Move joys�ck to preview a message .
2. Press joys�ck, then select
.
3. Press joys�ck again, then all messages will be
deleted, except the locked & unread messages.
symbol.
