Operation/Indicators
LED Name
Description
Module is powered and initialization is completed.
PWR
(PWR LED blinks when an error occurs)
A phase pulse input (V)
ØA
B phase pulse input (V)
ØB
Count is decreasing
D
External preset terminal input (V)
P
Enable count terminal input (V)
F
Output Compare
O1, O2
11
