USER MANUAL
MAPLE MODULAR PLC
High Speed Counter Module
IO-SHSC02
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IO-SHSC02 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Maple Systems IO-SHSC02

  • Page 1 USER MANUAL MAPLE MODULAR PLC High Speed Counter Module IO-SHSC02 • - 1 -...
  • Page 2: Table Of Contents

    Contents General Specifications......... 7 Performance Specifications ......8 Features .............9 Operation Concept ........10 Names of Parts..........11 Dimensions ..........12 Installation ..........13 Pin Arrangement ........14 Wiring ............16 Wiring Sample ..........18 Input Signal Circuit ........22 Product Warranty ........23 - 2 -...
  • Page 3 Reproduction of contents, in whole or part of this manual, without written permission from MAPLE SYSTEMS Inc. is prohibited. Safety symbols are classified into two categories, “WARNING” and “CAUTION”. Warning: This symbol describes situations that could cause major or fatal injury to the user.
  • Page 4 Design Precautions ( Warning) Please install a safety circuit to protect the entire control system in case of an unexpected power shutdown or PLC module malfunction. Such anomalies may severely compromise the integrity of the overall system. External to the PLC, please install circuits and switches to safeguard the system from mechanical damages (ex.
  • Page 5 Precautions for mounting ( Caution) Use the PLC in an environment that meets the general specifications given in this manual. Using this PLC in any environment outside the range of the general specifications could result in electric shock, fire, malfunction, or damage to or deterioration of the product. Please ensure that each module is installed correctly in its place.
  • Page 6 Precautions for wiring of HSC Module ( Caution) Cables for the output signals of the HSC module should be separate from AC power to prevent the influence of surge or induction noise occurring from AC. Select a cable considering ambient temperature and allowable current. AWG 22 (0.3 mm ) or more is recommended.
  • Page 7: General Specifications

    General Specifications Items Specification Standards -10℃–60℃ Op. Temp -25℃–80℃ St. Temp 5–95% RH, Not condensed Op. Hum 5–95% RH, Not condensed St. Hum In case of Intermittent Vibration Frequency Acceleration Amplitude Sweep 5 ≤ f < 9 Hz 3.5 mm 10 times in X, Y, Z 9 ≤...
  • Page 8: Performance Specifications

    Performance Specification Model Item IO-SHSC02 I/O Points 16 points Number of Channels 2 channels Power consumption 90 mA Weight 68.5g Phase 1 Phase input/2 Phase input Count Input Level (фA,фB) 5/12/24 V DC 2—5 mA Signal Types PNP Encoder (-Common)
  • Page 9: Features

    Features High Speed Counter (HSC) module covers a wide range of high-speed pulses. (-2147483648— 2147483647) The counted value is stored in the buffer memory as a signed 32-bit binary value. 2. Different types of operation mode are provided. - 1 Phase input 1 Multiplication (Increasing/decreasing count operated by software setting), - 1 Phase input 2 Multiplication (Increasing/decreasing count operated by software setting), - CW/CCW : 2 Phase input 1 Multiplication...
  • Page 10: Operation Concept

    Operation Concept 1) Count incoming pulse. 2) Preset and enable count operation can be operated by the external signal. 3) Compare the present count value with the compared value and turn Output Compare ON or OFF. (2 points per channel) 4) By using scan program, it’s possible to check the I/O signal and buffer memory.
  • Page 11 Operation/Indicators LED Name Description Module is powered and initialization is completed. (PWR LED blinks when an error occurs) A phase pulse input (V) ØA B phase pulse input (V) ØB Count is decreasing External preset terminal input (V) Enable count terminal input (V) Output Compare O1, O2 - 11 -...
  • Page 12: Dimensions

    Dimensions (Unit: mm) - 12 -...
  • Page 13: Installation

    Installation - 13 -...
  • Page 14 IO-SHSC02 Module Pin Arrangement Channel Signal Pin No. Channel Signal Pin No. A Phase pulse input 24 V A Phase pulse input 24 V A Phase pulse input 12 V A Phase pulse input 12 V A Phase pulse input 5 V A Phase pulse input 5 V A Phase common ◈...
  • Page 15 IO-SHSC02 Module Wiring 1) IO-SHSC02 Pin Number 2) ACC-TB32M Terminal Block Pin Number ACC-TB32M IO-SHSC02 Module - 15 -...
  • Page 16: Wiring

    Wiring Examples 1. When waveform generator outputs 5 V. (IO-SHSC02) 2. When waveform generator outputs 24 V PNP open collector output. (IO-SHSC02) - 16 -...
  • Page 17 Wiring Examples 3. When waveform generator outputs 24 V NPN open collector output. (IO-SHSC02) 4. When waveform generator outputs totem pole output (voltage type). (IO-SHSC02) - 17 -...
  • Page 18 Wiring Examples 5. When waveform generator outputs totem pole output (NPN open collector type). (IO-SHSC02) - 18 -...
  • Page 19 Wiring Examples 7. Preset, enable count input wiring. (IO-SHSC02) 8. Output Compare 1, 2 wiring. (IO-SHSC02) - 19 -...
  • Page 20: Input Signal Circuit

    IO-SHSC02 Input Signal Circuit IO-SHSC02 - 20 -...
  • Page 21: Product Warranty

    Product Warranty Warranty Statements are included with each unit at the time of purchase and are available at www.maplesystems.com. - 21 -...
  • Page 22 MEMO - 22 -...
  • Page 23 MEMO - 23 -...
  • Page 24 808 134th St SW #120 Everett, WA 98204 Web: www.maplesystems.com - 24 -...
