CONTENTS / INFORMATION Information ....................2 Safety Rules ....................2-3 Technical data ....................4 Installation, Checking, Operation ..............4-7 Maintenance, storage ................... 8 Declaration of Conformity ................8 Warranty ....................... 9 The symbol "danger" is used for remarks, the non- observance of which may cause danger to life The symbol "danger"...
6. Ability to control the operation of several pumps supplying the system. Applications IVR-10 can be used to pressurize water in a variety of installations such as residential homes, service outlets, industry, water treatment plants, agriculture, etc. - Easy to install and use. No need for a qualified service technician to connect the device - Advanced technology, PID algorithm control, technology addressed to pump drive control - Reliable and reliable.
SAFETY RULES Safety Rules - Install on metal or other non-combustible materials. There is a risk of fire. - Use away from combustible materials. There is a risk of fire - Use away from explosives. There is a risk of explosion. - Check that the grounding is correct and effective.
PARAMETER DIMENSIONS TYPE 0.75KW 1.1KW 1.5KW 2.2KW Input Power Single-phase or three-phase power supply Input voltage 230V or 400V Permitted supply voltage 160V—260V (230V) or 300V—450V (400V) range Supply Current Frequency 50/60Hz Output voltage 1~AC 230V or 3~AC 400V Controllable device Pump Output frequency range 20~50/60Hz...
Page 6
INSTALLATION Inverter installation and check for a single pump Single Pump Installation Diagram For proper operation, the inverter must work with a diaphragm tank with a minimum capacity of 2L. The membrane tank should be inflated to 60% of the water pressure set on the controller. Example: for a pressure set on the controller of 4 bar, the air pressure in the membrane tank (without water) should be 2.4 bar.
Page 7
INSTALLATION Operating instructions and operation Check before turning on the power 1. Check that the input power supply and conditions match the data on the rating plate 2. Check that the inverter is securely installed (permanently attached to the support, support of sufficient strength, ambient temperature and humidity within acceptable limits 3.
INSTALLATION / CONNECTION Installation and connection of a group of several pumps and inverters The design and installation of a group of pumps should be carried out by professionals The IVR10 inverter allows you to connect to 6 pcs. pump + inverter units. In the group, one of the controllers will act as the main controller with which the user will program the group, and the others will only perform a service function in relation to the main inverter.
DECLARATION OF CONFORMITY EU/EC DECLARATION OF CONFORMITY (Module A): 1. Inverter – IVR-10 pump controller 2. PHU Dambat, Gawartowa Wola 38, 05-085 KAMPINOS, POLAND, e-mail: biuro@dambat.pl 3. This declaration of conformity is issued under the sole responsibility of the manufacturer.
WARRANTY WARRANTY CARD: The following warranty card is valid only together with the original purchase document, i.e. invoice or receipt. In addition, it must be confirmed by the seller with a signature and stamp. The warranty card without the original purchase document attached is invalid The guarantor of the device is PHU DAMBAT, service address 05-870 Błonie, Pass 21, Hall B, Park Hillwood For customers who have the original proof of purchase in the form of a fiscal receipt or the original invoice, the warranty period is...
