micnode mini – Hardware User Guide
Auto mode
D. Automatically obtain
from DHCP server:
•
IP address
•
Net Mask
•
Gateway
•
Static routes for
remote networks
that need to be
reached via the
LAN adapter.
•
DNS
server and Search
domains are
assigned by the
DHCP server.
Click on Save
Changes button to
confirm your
configuration.
IMPORTANT: The option OFF disables the port.
Q-SYS ECOSYSTEM INTEGRATION
In the previous chapter you connected your micnode mini microphone station to the network via a standard
ethernet cable. To add your new device to the Q-SYS audio network, it should consist of:
•
Q-SYS Core and further Q-SYS peripherals,
•
Windows-based computer for Q-SYS designer network setup, not required for runtime operation,
•
Gigabit Ethernet Switch with PoE ports.
