micnode mini – Hardware User Guide
Announcement Triggering
Once the network settings and configuration including zones are set in Q-SYS designer, Live paging can be triggered with
the PTT button.
IMPORTANT: Which mode is used depends on Paging configuration of your micnode mini device in Q-SYS designer.
1. Select on your micnode mini device the zone/s to which your announcement is to be paged by clicking on the
zone selection button/s. The selected button/s will light up.
2. Start your announcement by pressing the Talk/Start button on the microphone side.
Control LED Paging Status
Ready to page
Busy
No Zone selected
Starting PTT button – Waiting
in Queue
Talk - Ready
Stop call
Stopped by higher priority
TM
nnounce by Simpleway
Yellow LED
At least one zone button selected and zones are available
Red LED
At least one zone button selected and one zone at least is selected
LED off
No zone button is selected
Yellow LED, fast blinking
At least one zone button is selected, PTT button is pressed but at least
one zone is occupied by same or higher priority.
Green LED, slow blinking
PTT button pressed and live call is in progress.
Green LED, no blinking
Let go the PTT button, the call is done.
Red LED, first 4times blinking and the busy zone
Your call was interrupted by an other announcement with higher priority
paged in the same zone.
