micnode mini – Hardware User Guide
NOTE: Q-SYS designer version 9.10.1 pictures used in this manual are for illustration purposes only.
To make your microphone station operable within the Q-SYS ecosystem, follow the steps which are described in more
detail in the chapters below:
1. Download Q-SYS plugin for micnode mini,
2. Configure the plugin in Q-SYS designer,
3. Set up stream,
4. Configure zone paging buttons.
Q-SYS Plugin – Download & Configuration
To configure the micnode mini microphone station, you will need to install the respective plugin for Q-SYS designer so that
you can then set up the device's properties.
IMPORTANT: Configuration from the Q-SYS designer is auto populated to the nnounce configuration UI and thus your
micnode mini device.
1. nnounce micnode mini plugin for Q-SYS designer can be obtained:
a. Q-SYS designer Asset manager,
b. nnounce web page in the Download center - https://www.nnounce.com/download-center.
2. The downloaded file with the plugin needs to be placed on your computer in the folder:
C:\Users\username\Documents\QSC\Q-Sys Designer\Plugins
3. Open your Q-SYS designer.
4. Find the micnode mini plugin in the right panel below and drag and drop it into your design.
