INSTRUCTIONS PERTAINING TO A RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSONS.
WARNING :
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC
CAUTION TO REDUCE THE RISK OF
ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL
This Symbol is intended to alert the user to the presence of
uninsulated dangerous voltage within the product's enclosure
that may be of sufficient magnitude to constitute a risk of fire
or electric shock.
This Symbol is intended to alert the user to the presence of
important in the literature accompanying this appliance.
All information should be read carefully to avoid misuse of
product.
WARNING :
DO NOT OPEN THE CABINET.
DANGEROUS HIGH VOLTAGE IS PRESENT, SERVICING SHOULD ONLY
BE PERFORMED BY QUALIFIED PERSONNEL.
CAUTION : TO PREVENT ELECTRIC SHOCK. MATCH WIDE BLADE OF PLUG
TO WIDE SLOT, FULLY INSERT.
ATTENTION :
POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS
LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE
ET POUSSER JUSQU AU FOND.
SHOCK
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dynatone DPS350
Summary of Contents for Dynatone DPS350
- Page 1 INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS. WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 13. Do not attempt to service the product beyond that described in the user maintenance instruction. All other servicing should be referred to qualified service personnel. When using electric products, basic precaution should always be followed, including the following: 14. - Page 3 Precaution Thank you and congratulations on your purchase of the DIGITAL PIANO. Welcome/Contents Your new DIGITAL PIANO is a state-of-the-art musical instrument which Care of Your Digital Piano incorporates the latest electronics technology to make its operation as easy as possible.
- Page 4 Avoid heat, humidity or direct sunlight. Take care not to drop the unit and avoid Carefully remove the Digital Piano and its accessories from the packing box. The strong impact. Digital Piano set consists of the following items. Main Unit Right, Left Legs (a, b) Keep the unit free from liquids, dust, etc...
-
Page 5: Assembling The Stand
Attaching the main unit and stand Set the stand upright and gently lower the main unit on the stand, then tighten the main unit with four bolts (g) for main Attaching the both legs and pedal box assembly unit as shown in illustration. Securely combine both legs(a,b) pedal box (c) assembly using four bolts(f) and four caps(e) for pedal box. -
Page 6: Turning On The Power
Turning on the Power Connect the power cord. Insert the plug at the end of the cord into a standard AC outlet. Press POWER switch. The power is turned on and the initial display appears in the Multi Function Display. The voice of Grand Piano is selected automatically at first. - Page 7 VOLUME SECTION FUNCTION SECTION SONG CONTROL SECTION TERMINAL SECTION MASTER VOLUME Page 14 METRONOME Page 26 PLAY/STOP PHONES Page 27 Page 30 Multi Function Display RECORD Page 27 PEDAL JACK Page 30 VOICE SECTION DATA/TEMPO TRACK 1 MIDI IN Page 27 Page 30 LAYER Page 19...
-
Page 8: Master Volume
The piano has one volume on the panel for adjusting the volume. The piano features a total 12 demo pieces. Listen to them all and hear what the piano can MASTER VOLUME Call up the Demo Play mode. This determines the entire volume of the piano. Press DEMO. - Page 9 The piano features a wealth of rich, authentic voices, including piano, strings and brass The piano has six Drum kits and two SFX sets in the Percussion voice group. instruments. It also features a keyboard percussion function that lets you play the When one of the Drum kits, various drum and percussion sounds as assigned realistic drum, percussion sounds, and various effect sounds directly from keyboard.
- Page 10 There are 128 different voices in the piano. When the GM VOICE group is selected, The Layer mode of the piano allows you to select and play two different voices one of 128 GM voices can be assigned. simultaneously in a layer. This makes it easy to create exceptionally rich and thick tonal textures.
- Page 11 The Split mode of the piano allows you to select and play two different voices with your The piano has three pedals. left and right hands - For example, play bass with the left and piano with the right . Select the first voice.
-
Page 12: Reverb On/Off
Reverb is an effect that recreates the decaying reflections of a sound in a performance There are four different effects: Chorus 1, 2, 3, 4. space, and reproduces the special ambience of a concert hall. Reverb ON/OFF Chorus ON/OFF To turn on reverb, press the REVERB button. The lamp lights and reverb is set ON. To turn on Chorus, press the CHORUS button. - Page 13 TOUCH TRANSPOSE Touch determines how your playing strength (velocity) affects the volume of the The Transpose function makes it possible to shift the pitch of the keyboard in voices. Ten(10) types are available for tailoring the keyboard response to the selected semitone units, allowing you to match the pitch of the keyboard to the range of other voice, type of song, or your own playing preference.
- Page 14 The piano features a convenient metronome that is ideal for practicing. The piano features comprehensive song recording functions that allow you to record your own performance. START/STOP of Metronome To start the metronome, simply press the METRONOME button. Select Record mode. Select the desired voice by using the VOICE group and the DATA/TEMPO buttons.
- Page 15 Start recording to Track2. Start playing the keyboard or press the PLAY/STOP button. MIDI? MIDI(Musical Instrument Digital Interface) is the international standard for digital communication of electronic musical instrument data, this means that any equipment which has a MIDI terminal - such as electronic musical instrument or personal computers - can easily exchange the digital data with other MIDI equipment without some complicated conversions or connections.
-
Page 16: Pedal Jack
GM # DISPLAY VOICE GM # DISPLAY VOICE PEDAL Jack MIDI Terminals Used to connect other MIDI instruments MIDI OUT Terminal: Used to transmit data from the piano to other equipment. MIDI IN Terminal: Used to receive data from other equipment. PHONES Jacks To use headphones, connect them to one of the PHONE Jacks (Standard 1/4”... - Page 17 Prog 33: Prog 41: Prog 49: Prog 58: Prog 59: JAZZ SET (7 - 6) BRUSH ORCHESTRA (7 - 7) (7 - 8) 27 - D#1 Closed Hi Hat Slap 28 - E1 Pedal Hi-Hat Conga 29 - F1 Open Hi Hat Short Whistle 30 - F#1 Ride Cymbal...
- Page 18 Be sure to check to following table whenever you encounter problems with the DIGITAL PIANO operation. Basic Channel Default 1 - 3 PROBLEM CAUSE SOLUTION Mode Default OMNI OFF, POLY OMNI OFF, POLY No sound 1. Power supply problem. 1. Check the power cord Note ON/OFF 9nH kk vv #kk:note ON (0-127)
- Page 19 Section Contents PRODUCT DIGITAL PIANO KEYBOARD 88 KEYS (STANDARD) - 7 1/4 OCTAVES TOUCH RESPONSE Off, Hard 1/2/3, Soft 1/2/3, Normal1/2/3 MAX. POLYPHONY 124NOTES SOUND GM 128 VOICES 5 DRUM KITS, 2 SFX SETS FUNCTIONS LAYER, SPLIT, TUNE, TRANSPOSE CHORUS(4), REVERB(4) METRONOME DISPLAY LED MULTI FUNCTION DISPLAY...
