  • Page 1 SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 38 OWNER'S MANUAL High Performance Slim Digital Grand Piano SGP-500 N e w f e e l , n e w l o o k a n d n e w s o u n d...

  • Page 2: Precaution

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 1 Precaution INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS. WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK...
  • Page 3 SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 2 Precaution PLEASE READ CAREFULLY BEFORE PROCEEDING Please keep these precautions in a safe place for future reference. WARNING Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from electrical shock, short-circuiting, damages, fire or other hazards.
  • Page 4 SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 3 Precaution ㆍBefore moving the piano, remove all connected immediately turn off the power and remove cables. electric plug from outlet. Then have the instrument inspected by qualified service ㆍWhen cleaning the piano, use a soft, dry cloth. personnel.

  • Page 5: Welcome

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 4 Welcome Welcome Thank you and congratulations on your purchase of the SLIM DIGITAL GRAND PIANO. Your new SLIM DIGITAL GRAND PIANO is a state-of-the-art musical instrument which incorporates the latest electronics technology to make its operation as easy as possible. Your versatile DIGITAL PIANO is ideal for beginners or experienced musicians.

  • Page 6: Table Of Contents

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 5 Contents Contents 목 Precaution Welcome Contents Care of Your Digital Piano Unpacking Setting Up Your Piano External Appearance Controls Voice Key Map Function Key Map Terminals Using the Pedals Adjusting the Volume Selecting Voice Layer...

  • Page 7: Care Of Your Digital Piano

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 6 Care of your Digital Piano Care of your Digital Piano ● Avoid heat, humidity or direct sunlight. ● Take care not to drop the unit and avoid strong impact. ●...

  • Page 8: Unpacking

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 7 Unpacking Unpacking Carefully take out the Digital Piano and its accessories from the packing box. The Digital Piano set consists of the following items. Main Unit (a) Owner’s Manual Pedal (e) 2 Lyres (f) Left Leg (b)

  • Page 9: Setting Up Your Piano

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 8 Setting Up Your Piano Setting Up Your Piano 1. Attaching the Legs Attach the Left Leg (b), Right Leg (c) and Rear Leg (d) to Main Unit (a) by using 12 Bolts for leg and pedal (g).
  • Page 10 SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 9 Setting Up Your Piano 4. Pedal Stability For pedal stability, rotate the adjusters on the bottom of the pedal assembly unit they comes in firm, contact with the floor surface. 5.

  • Page 11: Turning On The Power

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 10 Setting Up Your Piano Turning on the Power ① Connect the AC POWER CABLE. Insert AC plug at the end of AC cord into the piano and AC plug at the other end of AC cord into a standard AC outlet.

  • Page 12: External Appearance

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 11 External Appearance External Appearance 1. Fall Board 2. Control Panel 3. Keyboard 4. Pedal 5. Leg...

  • Page 13: Controls

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 12 Controls / Voice Key Map Controls ⓐ MASTER VOLUME ⓐ Page 17 ⓑ LAYER Button Page 18 ⓒ SPLIT Button Page 19 ⓑ ⓒ ⓓ 3D Button Page 20 ⓓ...

  • Page 14: Function Key Map

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 13 Function Key Map Function Key Map...

  • Page 15: Terminals

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 14 Terminals Terminals ⓐ ⓑ ⓒ ⓓ CONNECTING AUDIO DEVICES ⓐ AUX in jacks(RCA jacks of L and R) The stereo outputs from another instrument can be connected to these jacks, allowing the sound of an external instrument to be reproduced via the instrument's speakers.
  • Page 16 SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 15 Terminals CONNECTING OTHER DEVICES ⓒ Connecting the external MIDI devices (MIDI Terminals) Use the built-in MIDI terminals and standard MIDI cables to connect external MIDI devices. MIDI IN Receives MIDI messages from an external MIDI device. MIDI OUT Transmits MIDI messages generated by the instrument.

  • Page 17: Using The Pedals

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 16 Using the Pedals Using the Pedals The piano has three pedals. ③ ② ① ① Damper Pedal (Right) The damper pedal performs the same function as the damper pedal on an actual acoustic piano, letting you sustain the sound of the voices even after releasing your fingers from the keys.

  • Page 18: Adjusting The Volume

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 17 Adjusting the Volume / Selecting Voice Adjusting the Volume The piano has one volume on the panel for adjusting the volume. MASTER VOLUME This determines the entire volume of the piano. ☞...

  • Page 19: Layer

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 18 LAYER Layer The layer mode of the piano allows you to select and play two different voices simultaneously in a layer. This makes it easy to create exceptionally rich and thick tonal textures.

  • Page 20: Split

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 19 Split Split The split mode of the piano allows you to select and play two different voices with your left and right hands. For example, play bass with the left and piano with the right. PLAYING WITH THE SPLIT VOICE ①...

  • Page 21: Spatial Effect)

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 20 3D (Spatial Effect) 3D (Spatial Effect) The 3D effects widen the stereo image and the listener through two speakers or stereo headphones feels like placed in 3 dimensional spaces. PLAYING WITH THE 3D EFFECT ①...

  • Page 22: Twin Piano

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 21 Twin Piano / Default All Twin Piano Splitting the piano Keyboard into two sections for twin piano performance. The keyboard can be divided into two separate sections, allowing two people to perform in the same octave.

  • Page 23: Reverb

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 22 Reverb Reverb Reverb is an effect that recreates the decaying reflections of a sound in a performance space, and reproduces the special ambience of a concert hall. ① Press the REVERB button. ☞...

  • Page 24: Effect

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 23 Effect Effect The effect adds more breadth to the selected keyboard voice. ① Press the EFFECT button. ☞ The effect turns on and lamp lights. ☞ When turning on power, the effect is off. (Default is off.) ②...

  • Page 25: Tune

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 24 Tune Tune The Tune function lets you make fine adjustments to the pitch, allowing you to accurately match the tuning with that of other instruments. ① Press and hold the SETUP button. ☞...

  • Page 26: Transpose

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 25 Transpose Transpose The Transpose function makes it possible to shift the pitch of the keyboard in semitone units, allowing you to match the pitch of the keyboard to the range of other instruments or singers, or letting you easily play in a different key without having to change your fingering.

  • Page 27: Touch

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 26 Touch Touch Touch determines how your playing strength (velocity) affects the volume of the voices. Four types are available for tailoring the keyboard response to the selected voice, type of song, or your own playing preference.

  • Page 28: Using Metronome

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 27 Using Metronome Using Metronome The piano features a convenient metronome that is ideal for practicing. ① START/STOP of Metronome To start the metronome, simply press the METRONOME button. The lamp lights. Press the METRONOME button again to stop the metronome sound.

  • Page 29: Recording

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 28 Recording Recording This piano is equipped with a real time recorder, able to store a song or performance. It will record all notes as they are played. ① Select Record mode. Press the RECORD button.

  • Page 30: Gm Voice & Drum Table

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 29 GM Voice & Drum Table GM Voice & Drum Table GM # Voice GM # Voice 0 0 1 Piano1 0 6 5 Soprano Saxophone 0 0 2 Piano2 0 6 6 Alto Saxophone 0 0 3...
  • Page 31 SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 30 GM Voice & Drum Table Prog 1 Prog 9 Prog 17 Prog 25 Prog 26 Standard Drum Room Drum Rock Drum Elec. Drum Analog Drum 27 - D#1 High Q 28 - E1 Slap 29 - F1...
  • Page 32 SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 31 GM Voice & Drum Table Prog 33 Prog 41 Prog 49 Remark Jazz Drum Brush Drum Orchestra 27 - D#1 Closed Hi Hat 28 - E1 Pedal Hi-Hat 29 - F1 Open Hi Hat 30 - F#1 Ride Cymbal...

  • Page 33: Midi Implementation Chart

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 32 MIDI Implementation Chart MIDI Implementation Chart Function Recognized Transmitted Remark Basic Channel Default 1 - 3 Mode Default OMNI OFF, POLY OMNI OFF, POLY Note ON/OFF 9nH kk vv #kk:note ON (0-127) #vv:velocity (1-127) Pitch Bender...

  • Page 34: Troubleshooting

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 33 Troubleshooting Troubleshooting ※ Be sure to check the following table whenever you encounter problems with the DIGITAL PIANO operation. PROBLEM CAUSE SOLUTION No sound 1. Power supply problem. 1. Check whether the power cord is properly in AC outlet.

  • Page 35: Specifications

    SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 34 Specifications Specifications PRODUCT SLIM DIGITAL GRAND PIANO KEYBOARD 88 HAMMER ACTION KEYBOARD - 7 1/4 OCTAVES MAX. POLYPHONY 128 NOTES SOUND 25 Voices and 1 DRUM KIT FUNCTIONS LAYER SPLIT TWIN PIANO TUNE...
  • Page 36 SGP500 영영 영영영 Rev1_SGP500 영영영 (영영).qxd 2012-05-23 영영 5:00 Page 37 D Y N A T O N E C O R P . w w w . d y n a t o n e . b i z Part No.
