Hanna Instruments HI6553P Quick Reference Manual

QUICK REFERENCE GUIDE
HI6553P preconfigured meter complete with pH / ORP / ISE, Conductivity, Dissolved Oxygen kit
Dear Customer, thank you for choosing Hanna Instruments.
For more information about Hanna Instruments and our products, visit
www.hannainst.com or e-mail us at sales@hannainst.com. For technical
support, contact your local Hanna Instruments office or e-mail us at
tech@hannainst.com.
Please scan the QR code or use the link below to
download the user manual.
https://manuals.hannainst.com/HI6000
Package Contents
The HI6553P is a preconfigured meter supplied complete with:
• HI6000 housing unit
• HI6000-2 pH / ORP / ISE hardware module
(installed)
• HI6000-3 EC hardware module (installed)
• HI6000-4 DO hardware module (installed)
• HI1131B pH electrode
• HI7662-TW temperature probe
• HI7631233 EC & resistivity probe
• HI764833 polarographic DO probe
• pH 4.01 buffer solution, 2 sachets
• pH 7.01 buffer solution, 2 sachets
• pH 10.01 buffer solution, 2 sachets
• Electrode cleaning solution, 2 sachets
• pH & ORP electrode storage solution (25 mL)
• 3.5M KCl electrolyte solution (30 mL)
• DO electrolyte solution (30 mL)
• Capillary pipette, 1 piece
• 1413 S/cm standard solution, 2 sachets
µ
• 5000 S/cm standard solution, 2 sachets
µ
• 12880 S/cm standard solution, 2 sachets
µ
• Electrode rinse solution, 2 sachets
• pH electrode cap
• Membrane cap and O-ring, 2 pieces
• Electrode holder with base plate, screw,
cable holder clip (requires mounting)
• 24 VDC power adapter
• USB-C to USB-A cable
• Meter quick reference guide
• Hardware modules quick reference guides and quality certificates
• Probes and meter quality certificates
Hanna Instruments Inc., 584 Park East Drive, Woonsocket, RI 02895 USA
www.hannainst.com
Key Features
• User profiles configuration for quick and direct measurement
• Log files can be transferred to a USB flash drive
• Ethernet and Wi-Fi network data sharing options
Hardware flexibility
Hardware modules and preconfigured meters can be ordered from your
local sales office.
Module Parameter
HI6000-1 pH/ ORP
HI6000-2 pH/ ORP / ISE
HI6000-3 Conductivity
HI6000-4 Dissolved Oxygen
Getting Started
A. Place the meter face down and attach the electrode holder base plate (1).
B. Follow the user manual for electrode and probe preparation.
C. Connect the electrode, probes, external stirrers, and power adapter
to rear panel of the meter.
D. Connect the power plug and press the black ON/OFF power button (2).
2
Note: Remove the transparent film that protects the capacitive touchscreen
prior to operating the meter.
Method-Specific Applications
–
Incremental Methods for ISE applications
USP <645>
Oxygen Uptake Rate (OUR)
Specific Oxygen Uptake Rate (SOUR)
Biological Oxygen Demand (BOD)
Temperature probe
pH / ORP / ISE electrode
Reference electrode
Conductivity probe
Dissolved oxygen probe
Right stirrer connector
Left stirrer connector
Extension
1
