Summary of Contents for Easee Charge Core

  • Page 1 Installer guide Easee Charge Core...

  • Page 2: Warnings And Cautions

    Lithuania, Luxembourg, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, UK: WARNING Charge Core is not MID compliant. In some markets, This product shall only be installed, repaired or serviced MID compliance is not a requirement yet for charging by an authorised electrician. All applicable local, regional...

  • Page 3: Product Overview

    Product overview Front cover Chargeberry Backplate Protects the electronics from (1.4 - 22 kW) (1.4 - 22 kW) external influences. Contains the electronics For attaching and connecting to for charging the vehicle. the charging infrastructure. Installation kit Tool Strain relief Blind plug Sealing plug The blind plugs are pre-installed on the backplate.

  • Page 4: Technical Specifications

    Each master unit operates its secondary units independently. All master units at a site collectively share and load balance the amount of energy set for the site. Dynamic load balancing capabilities are possible with the addition of the Easee Equalizer. Built-in energy meter (±2 %)
  • Page 5 Built-in eSIM (LTE Cat M1) WiFi 2.4 GHz b/g/n connection Easee Link RF Bluetooth BLE 4.2 Control charging via Easee App RFID/NFC reader OCPP 1.6 via our API Type-2 Outlet/Connection Point Protection Integrated overload protection according to EN IEC 61851-1:2019, 13.1.

  • Page 6: Planning The Installation

    Site Key: During installation, a Site Key must — be used to assign the Charging Robots to the correct location in the Easee Cloud. A Site Key will automatically be generated when creating a new charging site using the Easee Installer App or it can...
  • Page 7 (Class II). • No other electrical equipment apart from Easee Charge Core, including lamps and socket outlets, is connected to the circuit. • No other conditions identified by the authorized installer requiring an external RCD.

  • Page 8: Installation Instructions

    Pull the tool until the front cover comes loose and remove the cover. Grasp the Type 2 socket and push upwards with good force until the Chargeberry disconnects. We recommend that you watch the installation videos available on our website: easee.support.
  • Page 9 The installation wall must cover the entire back of the product. If this is not possible to achieve, it is CAUTION possible to use the Easee Mount. The wires must not cross over the screw terminals or the — The area should not be exposed to direct rain, direct Chargeberry slots.
  • Page 10 Backplate Wiring TN/TT 3-phase IT/TT 3-phase (3x 230/400 V) (3x 230 V) Strip each wire, exposing 12 mm of copper on each. If the cable has flexible conductors, then you must use ferrules on stranded wires to make the connection. Use correct tools to press them.
  • Page 11 To achieve the best communication flow, the centre backplate should be configured first. Scan the QR code to download the Easee Installer App and create a free account. NOTE Your phone must support Bluetooth or NFC.
  • Page 12 Turn on the power. The terminals of the backplates Chargeberry Attaching are now electrically live. Remove the PIN code sticker and attach it to the inside of the fuse cabinet, or another safe location for storage. Position the Chargeberry to fit into the slots on the WARNING backplate located in the center of the installation.
  • Page 13 Hang the front cover at the top of the backplate and Front cover Closing let it fall into place. Press the bottom of the front cover until you hear a click. Bend the lower part of the rubber cover down. Screw in the locking screw at the bottom of the Before closing the front cover, it is possible to lock charger to secure the front cover.
  • Page 14 Easee Key. Check our knowledge base at http://support.easee.com more details on how to add and manage your Easee Keys. Type 2 socket: The Type 2 socket is completely universal and allows you to charge any type of electric vehicle using the appropriate charging cable.
  • Page 15 Contact customer support. General error. Unplug the charging cable and replug it to the Red – constant light Charging Robot. If the red light persists, check the Easee App or our knowledge base for further information.
  • Page 16 For further information, please check our knowledge base The Charging Robot is waiting to be configured. Consult an Yellow – flashing light, only at the bottom authorised electrician. Easee public knowledge base can be found at support.easee.com.
  • Page 17 Easee or its subsidiaries in writing. Any permitted use shall always be done in accordance with good practice and ensure that no harm may be caused to Easee or by misleading the consumer. Easee and Easee products, product names, trademarks and slogans, whether registered or not, are Easee’s intellectual...
