- Page 1 BODY BIKE SMART/SMART+ Installation and Maintenance Guide ATTENTION Please read this guide if you are technical staff, instructor or club manager.
-
Page 2: Tool Description
TOOL DESCRIPTION EQUIPMENT AND TORQUE WRENCH Equipment required Drill Use the drill bit T25 in order to tighten the bolts in steps 3 and Drill bit Torque wrench Drill bit socket Drill bit socket 5 mm Pedal wrench 15 mm Allen wrench 5 mm In order to change direction,... - Page 3 UNPACKING ASSEMBLE CAUTION Please read all the instructions in this guide before installing the equipment. Inappropriate use or maintenance can void the warranty. Please keep this guide at hand for future reference.
- Page 4 ASSEMBLE PROCEDURE This task requires 2 people Make sure the bottom frames are aligned before placing the bike Place the bike slowly on the bottom frames Unscrew 1 bike at the time using a drill Place the washers with the teeths facing up and the drill bit T25 Tigthen the bolts using the torque wrench and the drill bit sockets T25...
- Page 5 ASSEMBLE PROCEDURE Start mount by hand to ensure correct fit Screw on by turning counterclockwise Make sure that the pedal is inserted correctly, before using any tools Mount the handlebar correctly with the handles pointing forward Tighten with the pedal wrench 15mm To ensure the best cycling experience re-tighten the pedals after the first 1 week...
- Page 6 Place 2 O-rings on the bottleholder as illustrated Insert the washers and bolts as illustrated Tigthen the bolts using the torque wrench and Mount the bottleholder by gently presssing the drill bit sockets T25 it towards the two holes 12 Nm Tighten the bolts to...
- Page 7 MOVING PROCEDURE Place your foot in front of the bottom To move the bike, grab the handlebar in frame and slowly place the bike on the the areas illustrated floor again Place your foot in front of the bottom frame and pull towards yourself...
- Page 8 CAUTION We recommend minimum 40 cm between each bike. This ensures a comfortable workout for the user and minimizes the risk of interference between wireless devices.
-
Page 9: Maintenance
MAINTENANCE CAUTION Please read all the instructions in this guide before installing the equipment. Inappropriate use or maintenance can void the warranty. Please keep this guide at hand for future reference. - Page 10 MAINTENANCE PROCEDURE Push the sled forward to acces the bolts Push the sled backwards to acces the bolts Use the pedal wrench 15 mm to unscrew Tighten the bolts gently using the allen Tighten the bolts gently using the allen wrench 5 mm wrench 5 mm Tighten the bolts gently using the allen...
- Page 11 IN USE CAUTION Please read all the instructions in this guide before installing the equipment. Inappropriate use or maintenance can void the warranty. Please keep this guide at hand for future reference.
- Page 12 IN USE PROCEDURE Important Please release tension on all smart handels and the brake unit after every use in order to minimize wear.
- Page 13 MORE INFORMATION CLICK ON THE VIDEOS ASSEMBLE MAINTENANCE PROCEDURE PROCEDURE Check out our website www. body-bike.com...
