GENERAL INFO
TROUBLE
SHOOTING
Version 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart and is the answer not in the manual?

Questions and answers

Related Manuals for BODY BIKE Smart

Summary of Contents for BODY BIKE Smart

  • Page 1 GENERAL INFO TROUBLE SHOOTING Version 1.1...
  • Page 2 GENERAL INFO Before beginning any exercise, please consult your physician Wipe off the cycle after EVERY use. If necessary, use water in a spray bottle and a tissue with some washing- up liquid. NEVER use alcohol or chemicals to clean the cycle ALWAYS release tension after use and unlock ALL handles The rubber feet should always be adjusted to ensure that the cycle is in level DO NOT perform stretch exercises on the cycle, pedals or up against the cycle...
  • Page 3 GENERAL INFO Once a month, inspect that the flywheel edge is absolutely smooth. If dirt has gathered on the flywheel edge, clean it with 3M Scotch-Brite™ pad. Pedals should be changed once a year or at least after 1500 hours. At an annual service check vacuum clean inside the cycle and check that the ribs on the Poly-V belt and pulley are clean.
  • Page 4 SMART Release handles are not locking Adjust the handles by tightening the M8 bolt. For more information, see figure 2a and 2b.
  • Page 5 TROUBLE SHOOTING ADJUST VERTICAL HANDLES 6mm Allen Handle unlocked Handle unlocked Loosen Tighten Loosen Tighten Adjust only a quarter of a turn at the time. Figure 2b The belt does not catch hold of the flywheel If the belt does not catch hold of the flywheel, it is time to tighten the belt, see figure 3. TIGHTEN POLY-V BELT 19 mm wrench 1.
  • Page 6 Removal of side cover In the event that it is necessary to remove the side covers, please follow the instructions on figure 4 below REMOVE LEFT SIDECOVER Turn handle counter-clockwise until top nut comes 17 mm Wrench 3 mm Allen 8 mm Allen Hold top nut with wrench...
