Connect to the ne×t device with SDI input.
Preview Output Option Slots
The preview module supports 2 H.264 output and 1 HDMI output.
H.264
3 Connect to the ne×t device with RJ45 input.
HDMI
Connect to the display device, video processor or matri× with HDMI input.
Genlock Connectors
It includes 1 BNC connector and 1 HDMI-A connector
4 BNC connector receive sync signal from the controller or signal generator
HDMI-A receive sync signal from computer.

Control Connectors

It includes 1 LAN port, 1 U-LINK IN, 1 U-LINK OUT, 1 DIP switch and 1 antenna
port.
Ethernet
Connect to TCP/IP network for remote control by windows software.
U-LINK IN
Connect to the U-LINK output of the ne×t X2, adopt 3.5mm jack audio interface, for
multiple cascade.
5
U-LINK OUT
Connect to the U-LINK input of the ne × t X2, adopt 3.5mm jack audio interface, for
multiple cascade.
DIP Switch
To set the device address, identifying the processor when multiple devices are linked
Antenna
SMA F for standard antenas (Wifi module sold seperatly)

Power Connection

Power Input
6
Main power input AC 100-240V MAX 205W.
