Mooer OCEAN MACHINE II Owner's Manual page 6

12 o'clock for flat EQ; clockwise (1-5 o'clock) low pass filter (20 Hz ~ 500 Hz);
counterclockwise (11-7 o'clock) high pass filter (20 kHz ~ 3 kHz)
5. R. Mix: Rotate to adjust the dry/wet ratio of the reverb effect.
6. FeedbackB: Rotate to adjust the feedback value of the DelayB module (repeats).
7. TimeB: Rotate to adjust the delay time of the DelayB module.
8. SweepB: Default adjustment of the bandpass sweep for the DelayB delay effect. Turned all the way
left, the bandpass filter is turned off. Rotate the control to the right to open up the bandpass sweep
with a center frequency range of 80 Hz - 10 kHz and a Q value range of 0.3 - 5. Press and hold the
Setting knob while you rotate the Sweep control to adjust the Q value.
9. D.MixB: Rotate to adjust the dry/wet ratio of the DelayB module.
10. FeedbackA: Rotate to adjust the feedback value of the DelayA module (repeats).
11. TimeA: Rotate to adjust the delay time of the DelayA module.
12. SweepA: Default adjustment of the bandpass sweep for the DelayA delay effect. Turned all the way
left, the bandpass filter is turned off. Rotate the control to the right to open up the bandpass sweep
with a center frequency range of 80 Hz - 10 kHz and a Q value range of 0.3 - 5. Press and hold the
Setting knob while you rotate the Sweep control to adjust the Q value.
13. D.MixA: Rotate to adjust the dry/wet ratio of the DelayA module.
14. Menu: Rotate/press the knob to select the parameters. (See section Menu control )
During standard operation, rotate the Menu control to adjust the Master Mix.
Press to access the screen menu. Rotate to navigate, press to enter.
15. Reverb: Rotate to select a reverb type. (See section EFFECT TYPES )
16. DelayB: Rotate to select the delay type of DelayB. (See section EFFECT TYPES )
17. DelayA: Rotate to select the delay type of DelayA. (See section EFFECT TYPES )
18. Home: Press to return to the main interface screen.
19. Setting: Press to enter the Settings menu.
20. Store: Press to store the current preset setting.
21. Preset: Press to switch between Play and Patch modes.
The blue LED inside the button is lit when Patch mode is active.
Footswitches:
22. Reverb footswitch:
Play mode : press to turn the Reverb on/off, hold for frozen feedback effect
Patch mode : activates all effects used in the selected preset / bypass for all effects (global bypass)
Looper mode : controls the REC/PLAY/STOP/CLEAR functions of the Looper
23. DelayB footswitch:
Play mode : press the footswitch to turn DelayB on/off, hold for frozen feedback effect
Patch mode : scroll down between presets
Looper mode : 1/2 speed mode on/off
24. DelayA footswitch:
Play mode : press the footswitch to turn DelayA on/off, hold for frozen feedback effect
Patch mode : scroll up between presets
Looper mode : Reverse mode on/off
Tap Tempo Mode
When in Play mode, press Reverb and DelayB footswitches at the same time to enter the Tap Tempo
mode. Then use the Reverb footswitch for Master Tap Tempo or the DelayA / DelayB footswitches
for their respective tap tempos. (See section Tap Tempo)
Looper Mode
Press the DelayB and DelayA footswitches simultaneously to access the Looper functions.
(See section LOOPER Mode )
3
