  • Page 1 OCEAN MACHINE II Premium Dual Delay, Reverb and Looper Pedal Owner’s Manual...

  • Page 2: Table Of Contents

    CONTENT PRECAUTIONS ............................1 FEATURES ..............................2 TOP PANEL ............................... 2 BACK PANEL ............................. 4 SETUP ..............................4 Mono setup ............................4 Mono input and stereo output setup ....................5 Stereo input and stereo output setup ....................5 FX LOOP setup ............................. 6 EFFECT TYPES............................
  • Page 3 LOOPER Mode ........................... 15 Footswitch and control functions ....................15 Menu control ..........................15 REC / PLAY /STOP (Reverb footswitch) ..................15 HALF SPEED (DelayB footswitch) ....................15 REVERSE (DelayA footswitch) ....................15 Looper positioning ........................16 SETTINGS MENU ............................ 16 F4 Pairing ............................

  • Page 4: Precautions

     Please do not modify the unit without authorization.  Should repairs be required, please contact the MOOER support team for more information. Storage and usage locations To avoid deformation, discoloration or other serious damage, do not expose this device to any of the following conditions: ...

  • Page 5: Features

    Supports external parameter control via expression pedal  Upgraded MIDI control with clock sync, allowing the pedal to sync with other MIDI devices  Supports external control with MOOER F4 wireless footswitch controller  USB-C port for firmware updates TOP PANEL 1.
  • Page 6 12 o'clock for flat EQ; clockwise (1-5 o'clock) low pass filter (20 Hz ~ 500 Hz); counterclockwise (11-7 o'clock) high pass filter (20 kHz ~ 3 kHz) 5. R. Mix: Rotate to adjust the dry/wet ratio of the reverb effect. 6.

  • Page 7: Back Panel

    BACK PANEL 1. EXP: 1/4" stereo audio jack, connection to external expression pedal (please use a TRS cable for the connection) 2. LEFT INPUT: 1/4" mono audio jack, input for the left channel 3. RIGHT INPUT: 1/4" mono audio jack, input for the right channel 4.

  • Page 8: Mono Input And Stereo Output Setup

    Mono input and stereo output setup Guitar connects to the LEFT/MONO input jack LEFT/MONO output jack connects to the INPUT of the amplifier RIGHT output jack connects to the INPUT of another amplifier Stereo input and stereo output setup Guitar connects to the INPUT of a stereo pedal LEFT output jack of the stereo pedal connects to the LEFT/MONO input jack RIGHT output jack of the stereo pedal connects to the RIGHT input jack LEFT/MONO output jack connects to the INPUT of the amplifier...

  • Page 9: Fx Loop Setup

    FX LOOP setup Guitar connects to the INPUT of the amplifier LEFT/MONO input jack connects to the SEND of the amplifier LEFT/MONO output jack connects to the RETURN of the amplifier EFFECT TYPES Reverb Room: Small room reverb with a short decay Hall: Large spacious reverb with a long decay Plate: Based on a traditional mechanical plate reverb Ds-Verb*: Distorted reverb...

  • Page 10: Delayb

    DelayB Digital: High fidelity delay with clean repeats Analog: Vintage BB style delay with warm degrading repeats Tape: Based on a classic reel to reel tape echo Real: Clear delay with natural sounding repeats Dyna: Dynamic delay Galaxy: Delay with swelled repeats and a light modulation Mod*: Delay with modulated repeats Tri-Mod*: 80’s style delay with thick modulated repeats Mod-Inv*: Reverse delay with modulation...

  • Page 11: Operation

    OPERATION Plug your guitar into the INPUT of the OceanMachine II and use audio cables to connect to your amplifier. (See section SETUP). Connect the power adapter (9 VDC, 500 mA, center negative) to the DC IN jack. The main interface shows arrow graphics to indicate input and output levels. The color of the arrows indicates the signal status: ...

  • Page 12: Play Mode

    (See section When the main interface (Play or Patch Mode) is displayed, rotate the Menu control to adjust the master output effect mix of the Ocean Machine II (ratio of the effect signal / dry signal).

  • Page 13: Footswitch Functions

    Footswitch functions Reverb / DelayB / DelayA Pressing any of the footswitches once will turn the respective effect ON or OFF. If one of the effects is active, it will show its selected effect type in the display and the respective footswitch LED is lit and, in case of the delays, blinking to indicate the selected tempo.

  • Page 14: Looper Mode

    Master Mix When the main interface (Play or Patch Mode) is displayed, rotate the Menu control to adjust the master output effect mix of the Ocean Machine II (ratio of the effect signal / dry signal). Parameter screen The parameter screen is opened by selecting a module by pushing the Menu control once, then rotating it to highlight the desired module and then pushing the Menu control again to open the module.

  • Page 15: Pingpong Effect

    Return to the main screen by pressing the Home button. PingPong effect The PingPong effect will alternate the delay repeats between the right and left side in a stereo panorama.  Use the Menu control to select the PingPong field in the bottom row of the main menu screen and push Menu to open the PingPong screen.

  • Page 16: Patch Mode

    Patch Mode In this mode, the Ocean Machine II recalls saved presets. The OMII features 8 banks with 3 presets each for a total of 24 presets. All main effect parameter values correspond to the values saved in the preset, not to the physical values indicated on the respective knobs.

  • Page 17: Preset Selection Screen

    and in the patch control screen (Effect type / OFF). The On/Off status of each individual effect is stored separately for each preset. Press Reverb + DelayB footswitches simultaneously to toggle between the preset selection screen and the patch control screen. Press DelayB + DelayA footswitches simultaneously to enter/exit the Looper mode.

  • Page 18: Looper Mode

    LOOPER Mode The Ocean Machine II pedal features a Looper with up to 120 seconds of recording time, overdubbing, independent level control and full featured half speed + reverse effects. Press footswitches DelayB + DelayA simultaneously to access the Looper mode.

  • Page 19: Looper Positioning

    Press the Menu control to access parameter screens, enter parameters and set states. F4 Pairing Use this setting to pair your Ocean Machine II with an optional wireless MOOER F4 series footswitch. Switch the footswitch to pairing mode (see footswitch manual) and press the Menu control to activate pairing.

  • Page 20: Bypass & Trail

    Bypass & Trail Use this screen to select the bypass type (DSP or True bypass). Note: When the INPUT has only LEFT/MONO connected, but the OUTPUT has both LEFT/MONO and RIGHT connected, the system will automatically switch to DSP bypass. The user can select between DSP and True bypass if both inputs are connected or if only one input and one output are connected.

  • Page 21: Calibrate

    Global EQ The Ocean Machine II is equipped with a Global EQ section which will affect both your dry guitar signal and the sound of the effects. This can be switched on or off. The Global EQ can be used for quick adjustments to the sound conditions at the venue.

  • Page 22: Midi

    If MIDI SYNC is active, the Master Tap Tempo of the OMII will be synched with the connected MIDI device. Reset This will perform a factory reset of your Ocean Machine II.  Rotate the Menu control to select YES.

  • Page 23: Expression Pedal

    Please calibrate your expression pedal before you use it for the first time on your OMII. (See section Calibrate in the Settings menu) WIRELESS FOOTSWITCH The Ocean Machine II supports wireless footswitches of the MOOER F4 series (to be purchased separately). Please consult the manual for the F4 footswitch for battery specs and charging requirements.
  • Page 24 Function Value Range Preset Midi program No. Reverb On/Off 0-127 (OFF < 64 < ON) Midi program #1 Reverb type Midi program #2 Pre-Dly Midi program #3 Decay 0-127 Midi program #4 0-127 (Low pass: ≥ 73; Midi program #5 R.Tone Flat: 55-72;...

  • Page 25: Firmware Update

    FIRMWARE UPDATE From time to time, MOOER will release new firmware updates for your Ocean Machine II which will include new features or bug fixes based on user feedback. The current firmware version of the OMII is shown in the Reset screen. (See Reset in the Settings menu) Note: A firmware update will reset all settings and stored presets to factory settings! You will need a USB Type C to USB Type A cable to complete the firmware update.

  • Page 26: Specifications

    SPECIFICATIONS Input: 6.35 mm (1/4") TS audio interface, impedance 1 MΩ Output: 6.35 mm (1/4") TS audio interface, impedance 100 Ω External expression pedal: TRS device, impedance 10 kΩ ~ 50 kΩ Sampling rate: 44.1 k Sampling accuracy: 24 bit Power supply: 9 VDC, 500 mA power adapter (center negative) USB:...
